Dahua KAMERA IP DAHUA IPC-HDW1839T-A-IL-0280B-S6

Audio - Audio codecs - PCM, G.711a G.711Mu, G.726
Audio - Built-in loudspeaker - No
Audio - Built-in microphone - Yes
Audio - Two-way talk - N
Audio compression - G.711a
Audio compression - G.711u
Audio compression - G.726
Audio compression - PCM
Camera - Adjustment shutter speed - Auto/Manual
Camera - Camera shutter speed - 1/3 - 1/100000 s
Camera - Horizontal rotation angle - 0 - 360°
Camera - Lens viewing angle, horizontal - 110°
Camera - Lens viewing angle, vertical - 58°
Camera - Minimum illumination - 0.008 lx
Camera - Motion detection - Yes
Camera - People detection - Yes
Camera - Vertical rotation angle - 0 - 78°
Camera - Viewing angle, diagonal - 132°
Camera design - Eyeball
Category Code - FNC
Color - White
Colour - White
Connectors - RJ-45
Description - > 8-MP 1/2.7" CMOS image sensor, low luminance, and high definition image. > Outputs max. 8 MP (3840 × 2160) @20 fps, and supports 2688 × 1520@25/30 fps. > H.265 codec, high compression rate, ultra-low bit rate. > Built-in multi-core light, the max. IR distance is 30 m and the max. warm light distance is 30 m. > Rotation mode, DWDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. > ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments. > Built in Mic. > 12 VDC/PoE power supply, easy for installation. > IP67 protection. > Supports human detection. > Focal Length 2.8mm. Field of View 110°
Description - Inteligentne Podwójne Oświetlenie (Smart Dual Light)
Technologia Dahua Smart Dual Light wykorzystuje inteligentny algorytm do wykrywania obiektów. Zazwyczaj w nocy aktywne jest podświetlenie IR (podczerwone). Gdy w monitorowanym obszarze pojawi się obiekt, włącza się białe światło, a kamera rejestruje kolorowe wideo oraz informacje o kluczowych zdarzeniach. Oznacza to, że kamera wykonuje zdjęcia i nagrania z pełną kolorystyką. Gdy obiekt opuści monitorowany obszar, białe światło się wyłącza, a aktywowane zostaje ponownie światło IR, co skutecznie redukuje zanieczyszczenie świetlne. Detekcja Człowieka (Human Detection)
Inteligentne algorytmy Dahua analizują ruchome obiekty na nagraniach wideo, wyodrębniając z nich sylwetki ludzi i odfiltrowując alarmy wywołane przez inne obiekty, co zwiększa dokładność i skuteczność powiadomień alarmowych. Smart H.265+ i Smart H.264+
Dzięki zaawansowanemu algorytmowi adaptacyjnego sterowania bitrateem w zależności od sceny, inteligentna technologia kodowania Dahua zapewnia wyższą wydajność kompresji niż standardowe H.265 i H.264. Pozwala to na uzyskanie wysokiej jakości obrazu przy jednoczesnym obniżeniu kosztów przechowywania i transmisji danych. Obrót Obrazu (Image Flip)
Dla wąskich i długich scen technologia Dahua Image Flip umożliwia obrót obrazu o 90°, 180° lub 270°, co pozwala na lepsze monitorowanie w trybie obrotu.
Design - Form factor - Tube/dome
Design - Housing material - Metal, Plastic
Design - International Protection (IP) code - IP67
Design - Mounting type - Wall/ceiling
Design - Product colour - White
Designation - CE+WEEE
dimensionalWeight - 254
dimension depth - 115 mm
dimension height - 110 mm
Dimensions - 85.6 mm × Φ94.0 mm
Dimensions - 85.6 x 94 x 94 mm
dimension weight - 449 g
dimension width - 115 mm
ean - 6939554931710
Effective pixels - 3840 (H) × 2160 (V)
Electronic Shutter Speed - Auto/Manual 1/3 s–1/100,000 s
Environment - Outdoor
Environment requirements - Temperatura pracy: 40°C do +55°C Temperatura przechowywania: 40°C do +55°C
Focal Length - 2.8mm
Frames per second - 30
guarantee - 36
guarantee_type - normal
Image sensor - Number of sensors - 1
Image sensor - Optical sensor size - 25.4 / 2.7 mm (1 / 2.7")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - HD CMOS
Lens - Typ obiektywu: Stałoogniskowy Mocowanie obiektywu: M12 Ogniskowa: 2,8 mm Maksymalny otwór przysłony: F1.6
Lens Mount - M12
Lens system - Closest focusing distance - 1.5 m
Lens system - Focal length range - 2.8 mm
Lens system - Lens type - Fixed focal length lens
Lens system - Maximum aperture number - 1.6
Lens system - Number of lenses - 1
Management features - Dedicated application - DMSS (Android, iOS)
Management features - Web-based management - Yes
Management features - Web browser - Yes
Memory card reader - No
Microphone - Built-in
Microphone - built-in
Min. Illumination - 0.0008 Lux
Minimum illuminance - 0.0008 lx
Mobile support - Android
Mobile support - iOS
Motion detection - Yes
name - IP camera IPC-HDW1839T-A-IL
Network - 4G LTE - No
Network - Bluetooth - No
Network - Ethernet interface type - 10 Megabit Ethernet
Network - Ethernet interface type - 100 Megabit Ethernet
Network - Networking standards - IEEE 802.3af
Network - Wi-Fi - No
Network Camera Type - HDTV/Megapixel/Outdoor
Network protocols - IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
Night mode - No data
Night vision - LED type - IR / White light LED
Night vision - Night vision - Yes
Night vision - Night vision distance - 30 m
Night vision - Number of illumination LEDs - 1 / 1
Operating temperature range - –40 °C to +55 °C
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -40 - 55 °C
Operational conditions - Storage temperature (T-T) - -40 - 55 °C
Packaging content - Number of cameras - 1
Performance - Connectivity technology - Wired
Performance - Placement supported - Outdoor
Performance - Signal-to-Noise Ratio (SNR) - 56 dB
Performance - Type - IP security camera
Power - DC output voltage - 12
Power - Power consumption (max) - 4.5 W
Power - Power consumption (Power over Ethernet (PoE)) - 3.5 W
Power - Power consumption (typical) - 2.5 W
Power - Power source type - DC, PoE
Power consumption - 5.8 Watts
Power options - 12V/PoE
Power supply - 12 VDC/PoE (802.3af)
Power supply requirements - 12 VDC/PoE (802.3af)
producer - Dahua
producerCode - IPC-HDW1839T-A-IL-0280B-S6
productName - IP CAMERA DAHUA IPC-HDW1839T-A-IL-0280B-S6
Product Net Weight - 0.35 kg
productSize - Normal
Protection class - IP67
Resolution - 4K Ultra HD (3840 x 2160)
Resolution - 8 Mega Pixel
RJ45 Input/Output connectors - 1
Safety warning - Warnings - Avoid direct contact with water to prevent electrical damage.
Safety warning - Warnings - Ensure that the product is properly installed and protected against falling.
Safety warning - Warnings - The product contains electronic components; do not dispose of with the normal household waste.
Security - Cyberbezpieczeństwo Szyfrowanie wideo Szyfrowanie konfiguracji Skrót (Digest) WSSE (Web Services Security zabezpieczenia usług sieciowych) Blokada konta Dzienniki bezpieczeństwa Generowanie i importowanie certyfikatów X.509 HTTPS (szyfrowane połączenie internetowe) Zaufany rozruch (Trusted boot) Zaufane wykonywanie (Trusted execution) Zaufana aktualizacja (Trusted upgrade)
Sensor - 1/2.7" CMOS
Sensor size - 1/2.7"
sizeX - 110
sizeY - 105
sizeZ - 110
Speakers built-in - No
Standards - IPv4
Standards - IPv6
Storage - RAM capacity - 256 MB
Storage - ROM capacity - 128 MB
System requirements - Mobile operating systems supported - Android
System requirements - Mobile operating systems supported - iOS
Two-way transmission - No
type - fixed dome camera
Unit Box Height - 0.105
Unit Box Length - 0.11
Unit Box Width - 0.11
Unit Calculated Volume - 0.00127 cubm
Unit Calculated Weight - 0.458 kg
Units per Pallet - 0
Units per Shipping Box - 1
Vendor Homepage - material.dahuasecurity.com/uploads/cpq/prm-os-srv-res/smart/datasheetzipfiles/IPC-HDW1839T-A-IL_S6_datasheet_20240415.pdf
vendpn - 6939554931710
Video - Frame rate - 20 / 25 / 30 fps
Video - Maximum resolution - 3840 x 2160 pixels
Video - Total megapixels - 8 MP
Video - Video compression formats - H.264
Video - Video compression formats - H.264+
Video - Video compression formats - H.264B
Video - Video compression formats - H.264H
Video - Video compression formats - H.265
Video - Video compression formats - H.265+
Video - Video compression formats - M-JPEG
Video - Video streaming - Yes
Video compression - H.264
Video compression - H.264+
Video compression - H.265
Video compression - H.265+
Viewing angle, horizontal - 110 °
Viewing angle, vertical - 58 °
Visual angle diagonal - 132 °
Warranty - 36 months
warrantyLength - 36
warrantyType - F
Weight - 0.35 kg
weight - 450
Weight & dimensions - Height - 85.6 mm
Weight & dimensions - Product diameter - 94 mm
Weight & dimensions - Weight - 350 g
Wireless communication - No
