Brand - COUGAR
BrandPartCode - 3MMHP1201.0001
Category - Computer Cooling Systems
Design - Fan connector - 4-pin
Design - Illumination colour - Blue, Green, Red
Design - Illumination LED - Yes
Design - LED connector type - 4-pin
Design - Number of fan blades - 9
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
GTIN - 4710483773341
LongDesc - High Performance Radiator FanThrough structural adjustment and precision tuning, MHP 120 fan is suitable for any cooling fan position inside the chassis. In addition, the metallic-reinforced motor hub & metallic bearing shell design drastically increases the stability and cooling performance. MHP120 is the perfect choice for cooling fan upgrades!Extremely Hyper Fan With 2000 RPM(max)Proven with data from certified professional testing labs, MHP 120 delivering 82.48 CFM/ 143.53 m3/h high air flow and 4.24mmH2O high static pressure. Moreover, it features a high fan speed capable of reaching up to 2000 RPM, providing outstanding performance, MHP 120 fan is the fan that dominates!Metal-reinforced Motor Hub & ShellWith the metal-reinforced motor hub and metal bearing shell design, MHP 120 fan generates excellent rotational stability that takes enhanced performance and durability to a whole new level.HDB Bearing & PWM ControlMHP 120 is equipped with HDB bearing (Hydro Dynamic Bearings), that extends the fan’s life span and reduces decibel effectively. Meanwhile, PMW control technology allows for total control on fan speed to reach that perfect balance between machine performance and cooling.Anti-vibration DamperMHP 120 cooling fan is equipped with rubber dampers at four edges of the fan that absorbs vibration. Further reducing noise from mounting gaps and/or resonance in the chassis, adding to the quiet performance of your PC system.Suitable For Radiator / HeatsinkWith the high static pressure level of MHP 120, it is an excellent choice for most of the radiator & heatsink in maximizing their heat dissipation. And of course, MHP 120 is also compatible, and can be mounted to most of the air / water cooler from other brands with ease.
LongProductName - 600 - 2000 RPM, 2.76 W, 4 pin, 82.48 CFM, 34.5 dBA, 120 x 25 x 120 mm, 186 g, Black, 1 pc
LongSummaryDescription - COUGAR CGR-CF-MHP12HB. Type: Fan, Fan diameter: 12 cm, Rotational speed (min): 600 RPM, Rotational speed (max): 2000 RPM, Maximum air pressure: 4.24 mmH2O, Bearing type: Hydraulic. Width: 120 mm, Depth: 120 mm, Height: 25 mm. Product colour: Black
Other features - Country of origin - China
Packaging content - Package type - Hanging box
Performance - Bearing type - Hydraulic
Performance - Fan bearing technology - Hydraulic bearing
Performance - Fan diameter - 12 cm
Performance - Fan noise level (max) - 34.5 dB
Performance - Fan speed (max) - 2000 RPM
Performance - Fan speed (min) - 600 RPM
Performance - Fan static pressure - 4.24 mmH2O
Performance - Maximum airflow - 82.48 cfm
Performance - Maximum air pressure - 4.24 mmH2O
Performance - Noise level (high speed) - 34.5 dB
Performance - Quantity per pack - 1 pc(s)
Performance - Rotational speed (max) - 2000 RPM
Performance - Rotational speed (min) - 600 RPM
Performance - Suitable location - Computer case
Performance - Type - Fan
Power - Fan current - 0.23 A
Power - Fan voltage - 12 V
Power - Power supply - 2.76 W
Power - Rated current - 0.23 A
Power - Rated voltage - 12 V
ProductName - CGR-CF-MHP12HB
ShortSummaryDescription - COUGAR CGR-CF-MHP12HB, Fan, 12 cm, 600 RPM, 2000 RPM, Black
Technical details - Compliance certificates - CE
Title - COUGAR CGR-CF-MHP12HB Computer case Fan 12 cm Black 1 pc(s)
URL - https://cougargaming.com/products/cooling/mhp120-1/
WarrantyInfo -
Weight & dimensions - Depth - 120 mm
Weight & dimensions - Fan thickness - 2.5 cm
Weight & dimensions - Height - 25 mm
Weight & dimensions - Package depth - 135 mm
Weight & dimensions - Package height - 27 mm
Weight & dimensions - Package weight - 276 g
Weight & dimensions - Package width - 169 mm
Weight & dimensions - Weight - 186 g
Weight & dimensions - Width - 120 mm
