Cyberpower UT2200EG-FR, 2200VA 1320W

Accessories included -
Active power - 1320 W
Apparent power - 2200 VA
Battery - Battery recharge time - 8 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Charging current - 2.1 A
Battery - Charging voltage - 5 V
Brand - CyberPower
BrandPartCode - UT2200EG-FR
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Compliance certificates - CE, RoHS
Charging time - 8 h
Chassis type - Tower
Color - Black
Data Act - Link and Link
Description - UT2200EG-FR UPS. The CyberPower UT2200EG-FR guarantees power protection for IT equipment such as computers, NAS devices and storage devices. The product is made in Line-Interactive topology with automatic voltage regulation (AVR) to ensure stable AC output. The patented GreenPower UPS energy-saving technology achieves very low power consumption to reduce energy costs and allows a lower operating temperature that extends battery life. An LED indicator shows the unit's status, battery status and UPS emergency status. It is also compatible with generators to extend power continuity. Other features include overload protection, EMI filter and configurable alarm to protect the unit. The tower(Tower) design allows users to place it on desks and also in tight spaces. Energy Saving Technology Generator compatibility USB charging ports Protection against interference and surges Fast Ethernet data transmission PowerPanel management software EMI and RFI filtering Automatic voltage regulation (AVR) LED status indicator Overload protection Protection for telephone, fax, modem, DSL, network USB connection port Configurable alarm
Design - Cable length - 1.5 m
Design - Control type - Buttons
Design - Cooling type - Active
Design - Form factor - Tower
Design - Housing material - Plastic
Design - LED indicators - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 4108
dimension depth - 395 mm
dimension height - 260 mm
Dimensions - 148 x 178 x 298 mm
dimension weight - 11000 g
dimension width - 200 mm
ean - 4711027790954
Environment requirements - Operating Temperature: 32 ~ 104 (°F) Operating temperature: 0 ~ 40 (°C) Relative operating humidity (non-condensing): 0 ~ 90 (%) Operating altitude (feet/meters): 0-10,000 feet (0-3000 meters) Storage temperature : -4 ~ 122 (°F) Storage temperature: -20 ~ 50 (°C) Relative storage humidity (non-condensing): 0 ~ 90 (%) Storage altitude (feet/meters): 0-10,000 feet (0-3000 meters) Online heat dissipation: 34.1 ( BTU/hr ) Audible noise from 1.5 M from the device surface: 50 (dBA)
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Fault, Low battery alarm, Overload alarm
Features - Automatic Voltage Regulation (AVR) - Yes
Features - EMI/RFI noise filtering - Yes
Features - Heat dissipation - 34.1 BTU/h
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 295 V
Features - Input operation voltage (min) - 167 V
Features - Maximum current - 10 A
Features - Noise level - 50 dB
Features - Number of phases - 1
Features - Output operation voltage (max) - 230 V
Features - Output power - 1320 W
Features - Output power capacity - 2.2 kVA
Features - Power protection features - Overload
Features - Power source type - AC
Features - Response time - 4 ms
Features - Surge energy rating - 150 J
Features - Surge protection - Yes
Features - Surge protection features - Modem
Features - Surge protection features - Modem, Network, Telephone
Features - Surge protection features - Network
Features - Surge protection features - Telephone
Features - UPS topology - Line-Interactive
Features - Waveform - Pseudo sine
Filters / protection - Overload
Filters / protection - Suppression
Filters / protection - Surge
GTIN - 4711027790954
guarantee - 24
guarantee_type - external
I/O connectors - 1 x USB (Type B)
I/O connectors - 1 x USB (Type C)
I/O connectors - 1 x USB 2.0
I/O connectors - 2 x RJ-11/RJ-45
Input power ports - Type F Schuko
LongDesc - CyberPower UT2200EG guarantees power protection for computers, networking equipment, and storage devices. The product adopts line-interactive topology with Automatic Voltage Regulation (AVR) function to offer stabilized AC power output. The patented GreenPower UPS™ Bypass design achieves ultra-low power consumption to reduce energy costs, and allows a lower operation temperature which extends battery lifespan.The LED indicator shows the utility, battery and operating status of the UPS. It is also compatible with generators to extend power continuity. Other features include overload protection, EMI filter and configurable alarm to safeguard your devices. Its tower design allows users to place it easily on desks or other tight spaces.
LongProductName - Line-interactive, 2200VA, 1320W, AVR, 4 x Outlets, Tower
LongSummaryDescription - CyberPower UT2200EG. UPS topology: Line-Interactive, Output power capacity: 2.2 kVA, Output power: 1320 W. AC outlet types: Type E, AC outlets quantity: 4 AC outlet(s), USB port type: USB Type A/USB Type-C. Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 8 h, Charging current: 2.1 A. Form factor: Tower, Product colour: Black, Housing material: Plastic. Compliance certificates: CE, RoHS
name - UPS UT2200EG-FR 2200VA/1320W 4ms/AVR/4xFR/RJ11/RJ45
Number of phases input - 1 (230V)
Operational conditions - Non-operating altitude - 0 - 3000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 50 °C
Other features -
Output power ports - 4 x C/E type
Packaging content - Manual - Yes
Packaging content - Quick installation guide - Yes
Packaging data - Manual - Yes
Packaging data - Package depth - 397 mm
Packaging data - Package height - 202 mm
Packaging data - Package weight - 11.1 kg
Packaging data - Package width - 271 mm
Packaging data - Quick installation guide - Yes
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - Type E
Ports & interfaces - Cabling technology - 10/100/1000Base-T(X)
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - Modem (RJ-11) ports - 2
Ports & interfaces - Number of RJ11/RJ45 input ports - 1
Ports & interfaces - Number of RJ11/RJ45 output ports - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port type - USB Type A/USB Type-C
producer - CyberPower
producerCode - UT2200EG-FR
productName - CyberPower UT2200EG-FR UPS
ProductName - UT2200EG
productSize - Normal
ShortSummaryDescription - CyberPower UT2200EG, Line-Interactive, 2.2 kVA, 1320 W, Pseudo sine, 167 V, 295 V
sizeX - 200
sizeY - 395
sizeZ - 260
Software - PowerPanel Personal
Special functions -
Sustainability - Sustainability compliance - Yes
Technical details - Sustainability certificates - CE
Technical details - Sustainability certificates - RoHS
Technical details - Sustainability compliance - Yes
The shape of the output voltage - Modified sine wave
Title - CyberPower UT2200EG uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1320 W 4 AC outlet(s)
Transfer time (max) - 4 ms
UPS Architecture - line-interactive
URL - https://www.cyberpower.com/global/en/product/sku/ut2200eg
vendpn - UT2200EG-FR
WarrantyInfo -
warrantyLength - 24
warrantyType - G
Weight - 10.8 kg
weight - 11200
Weight & dimensions - Depth - 298 mm
Weight & dimensions - Height - 178 mm
Weight & dimensions - Weight - 10.8 kg
Weight & dimensions - Width - 148 mm
