APC Easy UPS SMV3000CAI 3000VA, 2100W, IEC

Accessories included - Uninterruptible power supply Documentation CD USB cable User manual
Active power - 2100 W
Apparent power - 3000 VA
ARTIKEL1 - EASY UPS SMV 3000VA 230V WITH
ARTIKEL2 - BATTERY BACKUP + SURGE PROTECTIO
Battery - Battery capacity - 9 Ah
Battery - Battery life (max) - 5 year(s)
Battery - Battery recharge time - 4 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 12 V
Battery - Cold start - Yes
Battery - Number of batteries supported - 4
Battery life (max), years - 3 - 5
Battery recharge time, h - 4
Brand - APC
BrandPartCode - SMV3000CAI
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Certification - CE
Charging time - 4 h
Chassis type - Tower
Color - Black
Connections - USB
Data Act - Link
Depth, mm - 455
Description - APC EASY UPS SMV 3000VA 230V
Description - Easy UPS provides power protection in unstable power conditions, ensuring constant and reliable connectivity at the most critical times.
Design - Display type - LCD
Design - Form factor - Tower
Design - International Protection (IP) code - IP20
Design - LED indicators - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 600 mm
dimension height - 420 mm
Dimensions - 455 x 180 x 240 mm
dimension weight - 29000 g
dimension width - 320 mm
ean - 731304346555
EANCode - 0731304346555
Environment requirements - Operating temperature: 0 - 40 °C Relative humidity: 0 - 95 % (non-condensing) Operating altitude: 0 - 3,000 metres Storage temperature: -10 - 40 ° C Storage relative humidity: 0 - 95 % (non-condensing) Storage altitude: 0 - 15,000 metres Audible noise at a distance of 1 metre from the device: 45.0 dBA Protection class: IP20
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Alarm when on battery, Low battery alarm, Overload alarm
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Crest factor - 3:1
Features - Input frequency - 45/65 Hz
Features - Input operation voltage (max) - 303 V
Features - Input operation voltage (min) - 157 V
Features - Maximum current - 25 A
Features - Noise level - 45 dB
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 230 V
Features - Output operation voltage (min) - 230 V
Features - Output power - 2100 W
Features - Output power capacity - 3 kVA
Features - Output voltage regulation - -1 - 1%
Features - Power protection features - Overload, Short circuit
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
Filters / protection - Circuit
Filters / protection - Overload
Filters / protection - Surge
Form factor - Tower
Frequency range, Hz - 50/60
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0731304346555
GTIN - 731304346555
guarantee - 24
guarantee_type - external
Height - 410.000000
Height, mm - 240
HERSTELLER - APC
HSTNUMMER - SMV3000CAI
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
Input connection - IEC-320 C20
Input frequency, Hz - 45 - 65
Input power ports - IEC-C20
Length - 605.000000
Logistics data - Harmonized System (HS) code - 85078000
LongDesc - This APC Single phase Easy UPS is designed for essential power protection needs of small to medium businesses even in the most unstable power conditions. This 3kVA line interactive tower UPS provides pure sine wave power to handle a wide voltage range and inconsistent power conditions. The plug and play SMV comes with IEC 320 C20 input connection and 6x IEC 320 C13 outlets. The line interactive UPS supports communication interfaces like the USB port and RS-232 for monitoring and management. The UPS has an intelligent card slot for an optional network management card (APV9602) that enables network-based UPS monitoring and management. The Easy UPS and built-in lead-acid battery are covered by a 2-year warranty. Ideal for business PC/workstations, small offices, server rooms, audio/video systems, and retail point-of-sale. The UPS is compatible with the replacement battery APCRBCV209.
LongProductName - Easy UPS 1 Ph Line Interactive, 3kVA, Tower, 230V, 6 IEC C13 outlets, AVR, Dry Contact, LCD, W/O Network Card support
LongSummaryDescription - APC Easy UPS 1 Ph Line Interactive, 3kVA, Tower, 230V, 6 IEC C13 outlets, AVR, Dry Contact, LCD, W/O Network Card support. UPS topology: Line-Interactive, Output power capacity: 3 kVA, Output power: 2100 W. AC outlet types: IEC 320, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 12 V. Form factor: Tower, Product colour: Black, Display type: LCD. Certification: CE
Manufacturer - APC
ManufacturerPartNumber - SMV3000CAI
name - UPS SMV3000CAI Easy UPS SMV 3000VA
No. of batteries - 1
Noise level, dB - 45
Nominal input voltage, V - 157 - 303
Number of phases input - 1 (230V)
Operating relative humidity range, % - 0-95
Operating temperature range (T-T), °C - 0-40
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -10 - 40 °C
Other features -
Output interface - 6 x IEC 320 C13
Output power, W - 2100
Output power capacity (VA) - 3000
Output power ports - 6 x IEC-C13
Packaging content - Cables included - USB cable
Packaging content - Manual - Yes
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 6 AC outlet(s)
Ports & interfaces - AC outlet types - IEC 320
Ports & interfaces - USB port - Yes
producer - APC
ProductName - Easy UPS 1 Ph Line Interactive, 3kVA, Tower, 230V, 6 IEC C13 outlets, AVR, Dry Contact, LCD, W/O Network Card support
ShortSummaryDescription - APC Easy UPS 1 Ph Line Interactive, 3kVA, Tower, 230V, 6 IEC C13 outlets, AVR, Dry Contact, LCD, W/O Network Card support, Line-Interactive, 3 kVA, 2100 W, Sine, 157 V, 303 V
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 4
Storage temperature range (T-T), °C - -10-40
Storno - N
The shape of the output voltage - Full sine wave
Title - APC Easy UPS 1 Ph Line Interactive, 3kVA, Tower, 230V, 6 IEC C13 outlets, AVR, Dry Contact, LCD, W/O Network Card support
Transfer time (max) - 6 ms
UPS Architecture - line-interactive
UPS devices and accessories - Yes
URL - https://www.apc.com/
vendpn - SMV3000CAI
Voltage - 48 V
WarrantyInfo -
Weight - 25.2 kg
Weight - 29.120000
Weight & dimensions - Battery depth - 60.1 cm
Weight & dimensions - Battery height - 41 cm
Weight & dimensions - Battery weight - 28.9 kg
Weight & dimensions - Battery width - 32.6 cm
Weight & dimensions - Depth - 455 mm
Weight & dimensions - Height - 240 mm
Weight & dimensions - Weight - 25.2 kg
Weight & dimensions - Width - 180 mm
Weight, kg - 25.2
Width - 320.000000
Width, mm - 180
