Power Walker VFI 2000 TG, 2000VA 1800W, IEC

Accessories included -
Active power - 1800 W
Apparent power - 2000 VA
Backup time (100% load) - 3.8 min
Battery - Battery capacity - 9 Ah
Battery - Battery recharge time - 4 h
Battery - Battery voltage - 12 V
Battery - Charging current - 1.5 A
Battery - Number of batteries supported - 4
Battery - Typical backup time at full load - 4.5 min
Battery capacity - 9 Ah
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Charging time - 4 h
Chassis type - Tower
Color - Black
Description - ON-LINE UPS 2000VA
Emergency Power Supply Series PowerWalker VFI TG offers a professional solution for home and office. We can choose 3 power unit 1kVA, 2kVA, 3kVA that have been made in the technology ON-LINE. Power Supplies TG series are designed to work with external battery modules and high-capacity batteries, thanks to built-in powerful charger (6A instead of 1A as in the case of standard models).
VFI TG Series is equipped with a connector UPB-HID, this connector has a built-in drivers for easy power management without installing additional software monitoring. This power supply can be applied everywhere where we can not install third-party software such as photo kiosks, ATMs, advanced system security / monitoring.
- High power factor 0.9
- Made in the technology ON-LINE
- Equipped with USB-HID (Human Interface Device)
- They support a wide range of input voltage (100-300VAC)
- Cooperate with external battery modules
Design - Cooling type - Active
Design - Display type - LCD
Design - Form factor - Tower
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 15322
dimension depth - 490 mm
dimension height - 470 mm
Dimensions - 328 x 190 x 399 mm
dimension weight - 19600 g
dimension width - 330 mm
ean - 4260074978315
Eans - 4260074978315
Environment requirements - - Operating temperature: 0 - 40 °C
- Recommended humidity: 0 - 95%
Features - Crest factor - 3:1
Features - Efficiency - 90%
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 40 - 70 Hz
Features - Input operation voltage (max) - 300 V
Features - Input operation voltage (min) - 80 V
Features - Input power factor - 0.99
Features - Noise level - 50 dB
Features - Output frequency regulation - -0.05 - 0.05 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 1800 W
Features - Output power capacity - 2 kVA
Features - Output power factor - 0.9
Features - Output voltage regulation - -2 - 2%
Features - Response time - 4 ms
Features - UPS topology - Double-conversion (Online)
Filters / protection - Surge
guarantee - 24
guarantee_type - normal
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
Important - Chcesz przedłużyć okres gwarancyjny zasilacza UPS i / lub jego akcesoriów? Żaden problem skontaktuj się z doradcą klienta lub napisz na e-mail ups@ab.pl i wykup odpowiednią usługę!
Input power ports - IEC-C14
Logistics data - Harmonized System (HS) code - 85078000
Name - Power Walker VFI 2000 TG
name - UPS ON-LINE 2000VA TG 4x IEC OUT, USB/RS-232, LCD, TOWER, EPO
No. of batteries - 4
Number of phases input - 1 (230V)
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features -
Output power ports - 4 x IEC-C13
Packaging content - Cables included - Input power cable, USB cable
Packaging content - Manual - Yes
Packaging data - Package height - 324 mm
Packaging data - Package width - 500 mm
Packaging data - Resource CD - Yes
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Emergency Power Off (EPO) connector - Yes
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - USB 2.0 ports quantity - 1
producer - PowerWalker
Producer - Power Walker
producerCode - VFI 2000 TG
ProducerCode - VFI 2000 TG
productName - PowerWalker VFI 2000 TG Double-conversion (Online) 2 kVA 1800 W 4 AC outlet(s)
productSize - Normal
ShortDescription -
sizeX - 495
sizeY - 462
sizeZ - 335
Software - WinPower
Special functions - Emergency Off (EPO)
Transfer time (max) - 0 ms
UPS Architecture - on-line
vendpn - VFI 2000 TG
Voltage - 12 V
warrantyLength - 24
warrantyType - G
Weight - 17.2 kg
weight - 19600
Weight & dimensions - Depth - 399 mm
Weight & dimensions - Height - 328 mm
Weight & dimensions - Weight - 17.2 kg
Weight & dimensions - Width - 190 mm
