Accessories included -
Active power - 400 W
Apparent power - 650 VA
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Chassis type - Rack
Chassis type - Tower
Color - Black
Connectors - RJ-11
Description - Eaton Ellipse ECO 650 FRThe Eaton Ellipse ECO is a slim-line power protection with built-in high performance surge-protection device (compliant with IEC 61643-1 standard). With an efficient electrical design and the EcoControl function (USB models) the Eaton Ellipse ECO helps you make energy savings of up to 25 per cent compared to previous-generation UPSs.
Full specification: http://powerquality.eaton.com/EL650FR.aspx?CX=101
Designation - CE+WEEE
dimension depth - 140 mm
dimension height - 325 mm
Dimensions - - Height: 263 mm
- Width: 81 mm
- Depth: 235 mm
dimension weight - 4170 g
dimension width - 285 mm
ean - 3553340620614
Eans - 3553340620614
Environment requirements -
Filters / protection - Data line
Filters / protection - Overdischarge
Filters / protection - Surge
guarantee - 24
guarantee_type - external
Input power ports - IEC-C14
Name - Eaton Ellipse ECO 650 FR
name - Ellipse ECO 650 FR EL650FR
Number of phases input - 1 (230V)
Other features - - Input voltage range: 184 - 264V
- 3 output sockets with backup and protection + 1 with protection
- Replaceable sealed lead-acid batteries
- Energy-efficient build
- Time: 50% (9 min), 70% (6 minutes)
Output power ports - 4 x C/E type
producer - Eaton
Producer - Eaton
ProducerCode - EL650FR
ShortDescription - 650 VA / 400 W
Software -
Special functions - - Easy installation in an office environment
- Protecting data line
- Automatic switch
- Indicators LED + audible alarm
- Battery test
- Cold start
UPS Architecture - off-line (standby)
vendpn - EL650FR
Video -
Weight - 3.6 kg
