Accessories included - - Kabel telefoniczny
- Kabel USB
- Podręcznik użytkownika
Active power - 865 W
Apparent power - 1500 VA
ARTIKEL1 - BACK UPS RS 1500 VA
ARTIKEL2 - IN
Backup time (100% load) - 3.7 min
Battery - Battery recharge time - 8 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Replacement battery cartridge - 1
Brand - APC
BrandPartCode - BR1500G-FR
Breite - 0.4
Category - Root/Smarthome/Electricity/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Charging time - 8 h
Chassis type - Tower
Color - Black
Connectors - RJ-11
Connectors - RJ-45
Description - APC Power Saving Back-UPS Pro 1500, 230V, CEE 7/5
APC Back-UPS Pro, 865 Watts /1500 VA, input 230V /output 230V, Interface Port Optional Simple Signalling RS232 cable, USB, Extended runtime model
Design - Cable length - 1.83 m
Design - Product colour - Black
dimension depth - 400 mm
dimension height - 485 mm
Dimensions - 112 x 380 x 301 mm
dimension weight - 13760 g
dimension width - 245 mm
ean - 731304268734
EANCode - 0731304268734
Eans - 0731304268734
Environment requirements - - Środowisko operacyjne: 0 - 40 °C
- Wilgotność względna podczas pracy: 0 - 95%
- Wysokość n.p.m. podczas pracy: 0-3000 m
- Temperatura (przechowywanie): -15 - 45 °C
- Wilgotność względna (przechowywanie): 0 - 95%
- Wysokość n.p.m. (przechowywanie): 0-15000 m
- Poziom hałasu w odległości 1 m od powierzchni urządzenia: 45.00 dBA
Features - Output power - 865 W
Features - Output power capacity - 1.2 kVA
Features - Surge energy rating - 445 J
Filters / protection - Data line
Filters / protection - Surge
Filters / protection - Voltage drop
Gewicht - 13.44
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304268734
GTIN - 0731304268734
GTIN - 7313042687348
guarantee - 36
guarantee_type - external
HERSTELLER - APC
Hoehe - 0.25
HSTNUMMER - BR1500G-FR
Input power ports - Wtyczka sieciowa
Laenge - 0.49
Logistics data - Harmonized System (HS) code - 85078000
LongDesc - Specific features:Green mode: Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.Audible alarms: Provide notification of changing flywheel conditionsBattery failure notification: Provides early-warning fault analysis on batteries enabling timely preventive maintenancePower-saving outlets: Automatically cuts power to idle equipment to conserve electricity.LCD display: Alpha-Numeric Display which displays system parameters and alarms.Battery-protected and surge-only outlets: Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipmentCold-start capable: Provides temporary battery power when the utility power is out.Hot-swappable batteries: Ensures clean, uninterrupted power to protected equipment while batteries are being replacedAutomatic self-test: Periodic battery self-test ensures early detection of a battery that needs to be replaced.Adjustable voltage sensitivity: Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.Audible alarms: Provides notification of changing utility power and UPS conditions.User-replaceable batteries: Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)USB connectivity: Provides management of the UPS via a USB port (not available on all models).Transformer-block spaced outlets: Protect equipment with input transformer blocks without blocking access to other receptacles.Boost and Trim Automatic Voltage Regulation (AVR): Gives higher application availability by correcting low and high voltage conditions without using the batteryAutomatic Voltage Regulation (AVR): Gives higher application availability by correcting low and high voltage conditions without using the battery.Intelligent battery management: Maximizes battery performance, life, and reliability through intelligent, precision charging.Building Wiring Fault Indicator: This LED informs users of potentially dangerous wiring problems in the wall circuit.Adjustable voltage sensitivity: Provides the ability to adapt the Power Conditioner for optimal performance in specific power environments or generator applications.Automatic Voltage Regulation (AVR): Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.Battery fault detection: Monitors room and individual battery temperature changes for early detection of thermal runaway, shorted cells, open circuit, and bad battery.Battery-protected and surge-only outlets: Reserves power capacity and run time for connected equipment that require battery back-up while providing surge only protection for less critical equipment.Safety-agency approved: Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. Power conditioning: Protects connected loads from surges, spikes, lightning, and other power disturbances. Audible alarms: Provides notification of changing utility power and UPS conditions. Automatic restart of loads after UPS shutdown: Automatically starts up the connected equipment upon the return of utility power. Automatic self-test: Periodic battery self-test ensures early detection of a battery that needs to be replaced.Battery replacement without tools: Allows quick, easy battery replacement. LED status indicators: Quickly understand unit and power status with visual indicators. Cold-start capable: Provides temporary battery power when the utility power is out. Hot-swappable batteries: Ensures clean, uninterrupted power to protected equipment while batteries are being replaced Resettable circuit breakers: Enables a quick recovery from overload events. Transformer-block spaced outlets: Protect equipment with input transformer blocks without blocking access to other receptacles. User-replaceable batteries: Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR) Adjustable voltage sensitivity: Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications. Adjustable voltage-transfer points: Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation. Intelligent battery management: Micro-processor controlled battery charging and diagnostic testing ensures maximum battery life.
LongProductName - 865 Watts / 1200 VA, Input 230V / Output 230V
LongSummaryDescription - APC Power Saving Back-UPS RS 1500 230V CEE 7/5. Output power capacity: 1.2 kVA, Output power: 865 W, Surge energy rating: 445 J. Battery technology: Sealed Lead Acid (VRLA), Battery recharge time: 8 h. Product colour: Black, Cable length: 1.83 m. Width: 112 mm, Depth: 380 mm, Height: 301 mm. Battery type: APCRBC124, Interface: USB, Input connection type: IEC-320 C14
Name - APC Power Saving Back BR1500G-FR
name - BR1500G-FR APC Power Sav Back-UPS Pro 1500
No. of batteries - 1
Number of phases input - 1 (230V)
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 9000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 45 °C
Other features - - Napięcie wyjściowe: 230V
- 3 gniazda - zasilanie zapasowe
- 3 gniazda ochrona przeciprzepięciowa
- Typ przebiegu: schodkowa aproksymacja sinusoidy
- Wbudowany układ obejściowy
- Akumulator: APCRBC124
- Opcjonalny kabel RS232 z prostą sygnalizacją, USB
- Znamionowa energia przepięcia: 441 Dżule
Other features - Battery type - APCRBC124
Other features - Filtering description - UL 1449
Other features - Input connection type - IEC-320 C14
Other features - Interface - USB
Other features - Nominal input voltage - 230 V
Other features - Nominal output voltage - 230 V
Other features - Operating temperature (T-T) - 32 - 104 °F
Other features - Package dimensions (WxDxH) - 238 x 488 x 387 mm
Output power ports - 6 x C/E type
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Modem (RJ-11) ports - 1
producer - APC
Producer - APC
ProducerCode - BR1500G-FR
ProductName - Power Saving Back-UPS RS 1500 230V CEE 7/5
ShortDescription -
ShortSummaryDescription - APC Power Saving Back-UPS RS 1500 230V CEE 7/5, 1.2 kVA, 865 W, 445 J, Sealed Lead Acid (VRLA), 8 h, Black
Software -
Special functions - - Graficzny wyświetlacz LCD
- Beznarzędziowa wymiana akumulatora
- Automatyczna regulacja napięcia (AVR)
- Funkcja korekcji niskich i wysokich napięć
- Tryb ekologiczny
- Powiadomienie o rozłączeniu akumulatora
- Alarmy dźwiękowe
- Automatyczny test
- Gniazda wyjściowe z podtrzymaniem akumulatorowym
- Gniazda z ochroną przeciwprzepięciową
- Możliwość zimnego startu
- Ochrona przeciprzepięciowa analogowej linii telefonicznej
- Akumulatory wymienialne przez użytkownika "na gorąco" bez przerywania pracy systemu
- Powiadomienie o awarii akumulatora
- Złącze USB
- Akumulatory wymienialne przez użytkownika
- Gniazda energooszczędne
- Funkcja zarządzania energią
- Tryb ekologiczny
- Konfigurowalne punkty przełączania napięć
- Konfigurowalne czułość na napięcie
- Inteligentne zarządzanie akumulatorami
- Automatyczny test
- Transformer-block spaced outlets
- Wyłącznik obwodu z możliwością resetu
- Prostwa wymiana akumulatorów
- Wyświetlacz LCD z informacjami o statusie
- Alarmy dźwiękowe
- Powiadomienie o rozłączeniu akumulatora
Stck_Kart - 1
Stck_Pal - 32
Storno - Y
Title - APC Power Saving Back-UPS RS 1500 230V CEE 7/5
UPS Architecture - line-interactive
URL - https://www.apc.com/products/resource/include/techspec_index.cfm?base_sku=BR1200G-FR&total_watts=200
vendpn - BR1500G-FR
WarrantyInfo -
Weight - 12.8 kg
Weight & dimensions - Depth - 380 mm
Weight & dimensions - Height - 301 mm
Weight & dimensions - Package weight - 13.2 kg
Weight & dimensions - Weight - 11.6 kg
Weight & dimensions - Width - 112 mm
