Eaton 5P1550IRNG2, 1550VA 1350W, IEC 1U

Accessories included - Zestaw do montażu w szafie rack System blokady przewodów Kabel USB 2 x Przewód IEC-IEC Szybki start Instrukcje dotyczące bezpieczeństwa Karta sieciowa
ACoutletsquantity - 6 AC outlet(s)
AC outlets quantity Ports & interfaces - 6 AC outlet(s)
ACoutlettypes - C13 coupler
AC outlet types Ports & interfaces - C13 coupler
Active power - 1350 W
Apparent power - 1550 VA
ARTIKEL1 - EATON 5P 1550I RACK 1U NETPACK
ARTIKEL2 - G2
Automatic Voltage Regulation (AVR) Features - Yes
AutomaticVoltageRegulationAVR - Yes
Backup time (100% load) - 2 min
Battery -
Battery - Battery capacity - 9 Ah
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 6 V
Battery - Hot-swap battery - Yes
Battery - Number of battery cells - 6
Battery - Typical backup time at half load - 13.5 min
Batterycapacity - 9 Ah
Battery capacity - 9 Ah
Battery capacity Battery - 9 Ah
Batterytechnology - Sealed Lead Acid (VRLA)
Battery technology Battery - Sealed Lead Acid (VRLA)
Batteryvoltage - 6 V
Battery voltage Battery - 6 V
Brand - Eaton
BrandPartCode - 5P1550IRNG2
Breite - 0.58
Cablesincluded - USB cable
Cables included Packaging content - USB cable
Category - Uninterruptible Power Supplies (UPSs)
Category Code - UPW
Certificates - Certification - EMC
IEC/EN 62040-1
IEC/EN 62040-2
IEC/EN 62040-3
UL 1778
CSA-C22.2
CE
UKCA
Cm
Ukr
KCC
cTUVus
BIS
Certificates - Compliance certificates - Low Voltage Directive (LVD), RoHS
Certificates - Waste Electrical and Electronic Equipment (WEEE) compliance - Yes
Certification Certificates - EMC
IEC/EN 62040-1
IEC/EN 62040-2
IEC/EN 62040-3
UL 1778
CSA-C22.2
CE
UKCA
Cm
Ukr
KCC
cTUVus
BIS
Chassis type - Rack
Code - 5P1550IRNG2
Color - Black
Color - Silver
Compliance certificates Certificates - Low Voltage Directive (LVD), RoHS
Data Act - Link
Depth - 555 mm
Depth Weight & dimensions - 555 mm
Description - 5P1550IRNG2 UPS Eaton 5P, 1550 VA, 1350 W, wejście: C14, wyjścia: (6) C13, rack, 1U, karta sieciowa System automatycznej regulacji napięcia (AVR) Ochrona zasilania dla zastosowań o wysokiej gęstości: tylko 1U Energooszczędność, redukcja kosztów energii i chłodzenia Czysta sinusoida na wyjściu Kompatybilność ze środowiskami wirtualnymi (VMware, Hyper-V, Citrix Xen, Redhat) Pełna integracja z oprogramowaniem Eaton Brightlayer Software suite 1 port USB + 1 port szeregowy Technologia zaawansowanego zarządzania bateriami (ABM+) zwiększająca żywotność baterii oraz poprawiająca dokładność przewidywania żywotności Wyświetlacz graficzny LCD nowej generacji Baterie wymienialne podczas pracy urządzenia Zdalny restart i optymalizacja czasu podtrzymania dzięki 2 zarządzanym grupom gniazd Karta sieciowa w zestawie
Design -
Design - Display type - LCD
Design - Form factor - Rackmount
Design - LED indicators - Yes
Design - Product colour - Black, Silver
Design - Rack capacity - 1U
Designation - CE+WEEE
dimension depth - 580 mm
dimension height - 175 mm
Dimensions - 555 x 43.2 x 438 mm
dimension weight - 24000 g
dimension width - 760 mm
Displaytype - LCD
Display type Design - LCD
EAN - 2000001358153
ean - 3553340710414
EANCode - 3553340710414
Efficiency - 98.2%
Efficiency Features - 98.2%
Environment requirements - Wilgotność względna: 0-90%, bez kondensacji
Features -
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Efficiency - 98.2%
Features - Heat dissipation - 654 BTU/h
Features - Input frequency - 47/70 Hz
Features - Input operation voltage (max) - 294 V
Features - Input operation voltage (min) - 150 V
Features - Noise level - 35 dB
Features - Number of input phases - 1
Features - Number of output phases - 1
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 200 V
Features - Output power - 1350 W
Features - Output power capacity - 1.55 kVA
Features - Power factor - 0.9
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
Filters / protection - Automatic Voltage Regulation (AVR)
Filters / protection - Overdischarge
Formfactor - Rackmount
Form factor Design - Rackmount
Gewicht - 24.24
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 3553340710414
guarantee - 24
guarantee_type - external
Heatdissipation - 654 BTU/h
Heat dissipation Features - 654 BTU/h
Height - 43.2 mm
Height Weight & dimensions - 43.2 mm
HERSTELLER - EATON
HighLights -
Hot-swap battery Battery - Yes
Hotswapbattery - Yes
HSTNUMMER - 5P1550IRNG2
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x Terminal
I/O connectors - 1 x USB (Type B)
Inputfrequency - 47/70 Hz
Input frequency Features - 47/70 Hz
Input operation voltage (max) Features - 294 V
Input operation voltage (min) Features - 150 V
Inputoperationvoltagemax - 294 V
Inputoperationvoltagemin - 150 V
Input power ports - IEC-C14
Laenge - 0.76
LED indicators Design - Yes
Link - https://www.eaton.com/za/en-gb/skuPage.5P1550IRNG2.html
LongDesc -
LongProductName - 5P Gen2 UPS, 1550 VA, 1350 W, Input: C14, Outputs: (6) C13, Rack, 1U, Network card
LongSummaryDescription - Eaton 5P1550IRNG2. UPS topology: Line-Interactive, Output power capacity: 1.55 kVA, Output power: 1350 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 6 V. Form factor: Rackmount, Product colour: Black, Silver, Rack capacity: 1U. Compliance certificates: Low Voltage Directive (LVD), RoHS, Certification: EMC IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS
ManufDatasheet - https://www.tdbaltic.ee/leaflets/EATON/5P1550IRNG2.pdf
Model - 5P1550IRNG2
Name - Eaton UPS | 5P1550IRNG2 | 1550 VA | 1350 W
name - UPS 5P 1550i Rack 1U NetpackG2 1550VA/1350W
Name - UPS RACK 5P 1550VA 1350W/5P1550IRNG2 EATON
Networkcardslot - Yes
Network card slot Ports & interfaces - Yes
No. of batteries - 6
Noiselevel - 35 dB
Noise level Features - 35 dB
Numberofbatterycells - 6
Number of battery cells Battery - 6
Numberofinputphases - 1
Number of input phases Features - 1
Numberofoutputphases - 1
Number of output phases Features - 1
Number of phases input - 1 (230V)
Operatingaltitude - 0 - 3000 m
Operating altitude Operational conditions - 0 - 3000 m
Operating relative humidity (H-H) Operational conditions - 0 - 90%
OperatingrelativehumidityHH - 0 - 90%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features -
Other features > Dimensions (WxDxH) - 438 x 555 x 43.2 mm
Outputfrequency - 50/60 Hz
Output frequency Features - 50/60 Hz
Output operation voltage (max) Features - 240 V
Output operation voltage (min) Features - 200 V
Outputoperationvoltagemax - 240 V
Outputoperationvoltagemin - 200 V
Outputpower - 1350 W
Outputpowercapacity - 1.55 kVA
Output power capacity Features - 1.55 kVA
Output power Features - 1350 W
Output power ports - 6 x IEC-C13
Package features > Classification of battery - CL126:PEN:2025-08-18
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 550 mm
Package features > Gross height (mm) - 165 mm
Package features > Gross width (mm) - 595 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 16 pc(s)
Package features > Paper/Pasteboard - 3000 g
Package features > Plastic (No PET) - 960 g
Package features > Tare weight (kg) - 3.96 kg
Package features > TI weight (kg) - 14 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.05399625 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packagingcontent -
Packaging content - Cables included - USB cable
Packaging content - Quick installation guide - Yes
Packaging content - Rack mount kit - Yes
Performance > Capacity - 1550 VA
Performance > UPS topology - Line-Interactive
Ports & interfaces - AC outlets quantity - 6 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Network card slot - Yes
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - Serial interface - Yes
Ports & interfaces - Serial interface type - RS-232
Ports & interfaces - Serial ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port type - USB Type-B
Portsinterfaces -
Power > AC input frequency - 50-60 Hz
Powerfactor - 0.9
Power factor Features - 0.9
Powerplug - C14 coupler
Power plug Ports & interfaces - C14 coupler
ProdDesc - Eaton 5P 1550i Rack 1U Netpack G2
producer - Eaton
Productcolour - Black, Silver
Product colour Design - Black, Silver
Productcondition - Original
ProductHighLights -

• Line-Interactive
• 1.55 kVA 1350 W
• Waveform: Sine
• 6 AC outlet(s)
• Sealed Lead Acid (VRLA) 6 V 9 Ah
• Rackmount Black, Silver

ProductName - 5P1550IRNG2
Product Net Weight ELKO Verified Logistics Data - 18.78 kg
ProductPicture - https://www.tdbaltic.ee/images/products/EATON/5P1550IRNG2_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/EATON/5P1550IRNG2_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/EATON/5P1550IRNG2_3.jpg
ProductPicture3 - https://www.tdbaltic.ee/images/products/EATON/5P1550IRNG2_4.jpg
ProductPicture4 -
ProductPicture5 -
Quickinstallationguide - Yes
Quick installation guide Packaging content - Yes
Rack capacity Design - 1U
Rackmountkit - Yes
Rack mount kit Packaging content - Yes
RS232ports -
Serialinterface - Yes
Serial interface Ports & interfaces - Yes
Serialinterfacetype - RS-232
Serial interface type Ports & interfaces - RS-232
Serialportsquantity - 1
Serial ports quantity Ports & interfaces - 1
Shipping Box Depth ELKO Internal Logistics Data - 76 cm
Shipping Box Height ELKO Internal Logistics Data - 58.5 cm
Shipping Box Weight ELKO Internal Logistics Data - 24 kg
Shipping Box Width ELKO Internal Logistics Data - 17.5 cm
ShortSummaryDescription - Eaton 5P1550IRNG2, Line-Interactive, 1.55 kVA, 1350 W, Sine, 150 V, 294 V
Software - Eaton Brightlayer Software suite
Special functions - Automatyczny test baterii
Stck_Kart - 1
Stck_Pal - 3
Storno - Y
Summary - Eaton 5P1550IRNG2. UPS topology: Line-Interactive, Output power capacity: 1.55 kVA, Output power: 1350 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 9 Ah, Battery voltage: 6 V. Form factor: Rackmount, Product colour: Black, Silver, Rack capacity: 1U. Compliance certificates: Low Voltage Directive (LVD), RoHS, Certification: EMC IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3 UL 1778 CSA-C22.2 CE UKCA Cm Ukr KCC cTUVus BIS
Technical details > Capacity - 1350 W
Technical details > Gross weight - 22.66 kg
Technical details > Net weight - 18.7 kg
Technical details > Producer - Eaton
Technical details > Producer product family - UPS
Technical details > Producer product name - 5P1550IRNG2
The shape of the output voltage - Full sine wave
Title - Eaton 5P1550IRNG2 uninterruptible power supply (UPS) Line-Interactive 1.55 kVA 1350 W 6 AC outlet(s)
Typicalbackuptimeathalfload - 13.5 min
Typical backup time at half load Battery - 13.5 min
Unit Box Height - 0.585
Unit Box Length - 0.76
Unit Box Width - 0.175
Unit Calculated Volume ELKO Internal Logistics Data - 0.0778 cubm
Unit Calculated Weight ELKO Verified Logistics Data - 24 kg
Unit Depth ELKO Verified Logistics Data - 76 cm
Unit Height ELKO Verified Logistics Data - 58.5 cm
Units per Pallet ELKO Verified Logistics Data - 0
Units per Shipping Box ELKO Verified Logistics Data - 1
Unit Width ELKO Verified Logistics Data - 17.5 cm
UPS Architecture - line-interactive
UPStopology - Line-Interactive
UPS topology Features - Line-Interactive
URL - https://www.eaton.com/gr/en-gb/skuPage.5P1550IRNG2.html
USBport - Yes
USB port Ports & interfaces - Yes
USBporttype - USB Type-B
USB port type Ports & interfaces - USB Type-B
Vendor Homepage - https://www.eaton.com/gr/en-gb/skuPage.5P1550IRNG2.html
vendpn - 5P1550IRNG2
Voltage - 6 V
Warranty - 24 months
Warranty - 36
Warranty - 36 month(s)
Warrantyandmisc -
WarrantyInfo - 3 year on electronics, 2 year on battery
Waste Electrical and Electronic Equipment (WEEE) compliance Certificates - Yes
Waveform - Sine
Waveform Features - Sine
Weight - 18.7 kg
Weight - 18.8 kg
Weight & dimensions - Depth - 555 mm
Weight & dimensions - Height - 43.2 mm
Weight & dimensions - Weight - 18.8 kg
Weight & dimensions - Width - 438 mm
Weightdimensions -
Weight Weight & dimensions - 18.8 kg
Width - 438 mm
Width Weight & dimensions - 438 mm
