Synology RackStation RS2423RP+, 2U 12-Bay

Accessories included - Main Unit X 1 Accessory Pack X 1 Power cable X 2 Quick Installation Guide X 1
Built-in RAM memory - 8 GB
Category - Root/Electronics/Networks and communication/NAS - file servers
Category 1 - Netzwerk
Category 2 - NAS-Systeme
Category_1 - Network and Servers
Category_2 - NAS
Data Act - Link
Description - Faster performance and responsiveness The RS2423+/RS2423RP+ offers exceptional performance with read/write speeds of more than 155,000/79,000 random read/write operations per second (IOPS) and up to 3,500/1,700 MB/s sequential read/write.1 These are excellent, cost-effective file management and sharing solutions for small and medium-sized businesses, with advanced backup features designed for businesses with growing data needs. Designed with reliability in mind The RS2423+ and RS2423RP+ units are equipped with one 10GbE RJ-45 port and Gigabit Ethernet ports, which can be connected using Link Aggregation to enable automatic network failover and load balancing. Two RS2423+/RS2423RP+ units can be paired using Synology High Availability to create a reliable server cluster with an active-passive architecture, maximising uptime. The RS2423RP+ is further equipped with redundant hot-swappable power supplies to protect service continuity in the event of a single power source problem. Space for expansion The 12-bay, 2U high RS2423+/RS2423RP+ can be easily adapted to your usage environment, whether you need higher performance, faster networking or more storage capacity. Versatile storage for businesses The RS2423+/RS2423RP+ server is ideal for small and medium-sized businesses and branch offices looking for a powerful, reliable and cost-effective storage solution for file management, data backup and surveillance. Data protection across multiple endpoints Design an effective backup strategy to maximise data and system availability with a range of native unlicensed solutions.
Design - Built-in display - No
Design - Built-in speaker(s) - No
Design - Chassis type - Rack (2U)
Design - Cooling type - Active
Design - Fan diameter - 6 cm
Design - LED indicators - Yes
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
Design - Product colour - Grey
Designation - CE+WEEE
dimensionalWeight - 20638
dimension depth - 720 mm
dimension height - 255 mm
Dimensions - 88 x 482 x 578 mm
dimension weight - 16320 g
dimension width - 590 mm
Disk type - HDD
Disk type - SSD
ean - 4711174724901
EAN - 4711174724901
Eans - 4711174724901
EAN_code - 4711174724901
Expansion slots - 1 x PCIe 3.0 x 8
Fan - 6 cm
Form factor (width) - 2,5'' (SFF)
Form factor (width) - 3,5'' (LFF)
guarantee - 36
guarantee_type - normal
HDD interface - SATA
Hot-swapping support - Yes
Housing - Rack 2U
I/O connectors - 2 x USB 3.0
I/O connectors - 3 x RJ-45 LAN
Management, monitoring, configuration -
Manufacturer - Synology
Manufacturer_code - RS2423RP+
Max. number of disks - 12
Max memory size - 32 GB
Memory - ECC - Yes
Memory - Internal memory - 8 GB
Memory - Internal memory type - DDR4
Memory - Maximum RAM supported - 32 GB
Memory - Memory form factor - UDIMM
Memory - Memory slots - 2
Memory type - DDR4
MPN - RS2423RP+
name - Server NAS RS2423RP+ 12x0HDD
Name - Synology NAS Rack Station RS2423RP+ (12 Bay) 2U
Name - Synology RS2423RP+, NAS
Name - Synology RS2423RP+ 12x0HDD
Network - Copper ethernet cabling technology - 10BASE-T
Network - Copper ethernet cabling technology - 10GBASE-T
Network - Copper ethernet cabling technology - 100BASE-TX
Network - Copper ethernet cabling technology - 1000BASE-T
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000
Network - Ethernet LAN data rates - 10000 Mbit/s
Network - Ethernet LAN data rate supported (max) - 10000 Mbit/s
Network - iSCSI support - Yes
Network - Link aggregation - Yes
Network - Wake-on-LAN ready - Yes
Network architecture - GigabitEthernet
Network interface - 1 x 10Gbit/s 10GBase-T
Network interface - 2 x 10/100/1000 Mbit/s
Network protocols - SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Number of available memory slots - 1
Number of fans - 3
Number of HDDs installed - 0
Number of memory slots used - 1
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 35 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other disk parameters -
Other features -
Other features - Certification - FCC
BSMI
VCCI
RCM
UKCA
EAC
CCC
KC
UL
Other features - Compliance certificates - CE
Other features - Compliance certificates - RoHS
Packaging content - Cables included - AC
Packaging content - External power adapter - No
Packaging content - Power cables quantity - 2
Packaging content - Rack mount kit - Yes
Performance - Access Control List (ACL) - Yes
Performance - Backup features - Cloud
Performance - Backup features - iSCSI LUN
Performance - Backup function - Yes
Performance - Browser supported - Google Chrome Firefox Microsoft Edge Safari
Performance - Built-in FTP server - Yes
Performance - Card reader integrated - No
Performance - Device class - Small & Medium Business
Performance - Management protocols - SNMP
Performance - Multilingual support - Yes
Performance - Noise level - 56.2 dB
Performance - On/off switch - Yes
Performance - Security algorithms - AES
Performance - Snapshot - Yes
Performance - System log - Yes
Performance - Type - NAS
Ports & interfaces - Ethernet LAN (RJ-45) ports - 3
Ports & interfaces - PCI Express x8 (Gen 3.x) slots - 1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Ports & interfaces - USB port - Yes
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (typical) - 114.86 W
Power - Power supply location - Built-in
Power - Power supply unit (PSU) capacity - 350 W
Power - Redundant power supply (RPS) support - Yes
Power supply - AC power input voltage: 100V to 240V AC Power frequency: 50/60 Hz, single phase
Processor - AMD Ryzen V1780B 4-core 3.35 (base) / 3.6 (turbo) GHz
Processor - Number of processors supported - 1
Processor - Processor boost frequency - 3.6 GHz
Processor - Processor cores - 4
Processor - Processor family - Ryzen Embedded
Processor - Processor frequency - 3.35 GHz
Processor - Processor generation - AMD Ryzen Embedded V1000 Series
Processor - Processor manufacturer - AMD
Processor - Processor model - V1780B
producer - Synology
Producer - Synology
producerCode - RS2423RP+
ProducerCode - RS2423RP+
productName - Synology RackStation RS2423RP+ NAS/storage server Rack (2U) Ryzen Embedded V1780B 8 GB DDR4 0 TB DiskStation Manager Black, Grey
productSize - Normal
RAID - Yes
RAID levels - 0
RAID levels - 1
RAID levels - 5
RAID levels - 6
RAID levels - 10 (1+0)
ShortDescription -
sizeX - 585
sizeY - 720
sizeZ - 245
Software - Operating system installed - DiskStation Manager
Software - Operating system version - 7.1.1
Storage - Hot-swap drive bays - Yes
Storage - Installed storage drive type - No
Storage - Number of storage drives supported - 12
Storage - Online RAID expansion - Yes
Storage - Online RAID migration - Yes
Storage - RAID levels - 0
Storage - RAID levels - 1
Storage - RAID levels - 5
Storage - RAID levels - 6
Storage - RAID levels - 10
Storage - RAID levels - JBOD
Storage - RAID support - Yes
Storage - Storage drives installed - No
Storage - Storage drive sizes supported - 2.5
Storage - Storage drive sizes supported - 3.5"
Storage - Supported file systems - BTRFS
Storage - Supported file systems - exFAT
Storage - Supported file systems - ext3
Storage - Supported file systems - ext4
Storage - Supported file systems - Fat
Storage - Supported file systems - HFS+
Storage - Supported file systems - NTFS
Storage - Supported storage drive interfaces - Serial ATA
Storage - Supported storage drive types - HDD & SSD
Storage - Total installed storage capacity - 0 TB
Sustainability - Sustainability compliance - Yes
Total number of memory slots - 2
vendpn - RS2423RP+
warrantyLength - 36
warrantyType - F
Weight - 11.9 kg
Weight - 16,20
Weight - 16.34
weight - 16320
Weight & dimensions - Depth - 578 mm
Weight & dimensions - Height - 88 mm
Weight & dimensions - Weight - 11.9 kg
Weight & dimensions - Width - 482 mm
