Synology RackStation RS2423RP+, 2U 12-Bay

Accessories included - Main Unit X 1 Accessory Pack X 1 Power cable X 2 Quick Installation Guide X 1
Built-in RAM memory - 8 GB
Category Code - STS
Category_1 - Network and Servers
Category_2 - NAS
Code - RS2423RP+
CPU - AMD Ryzen V1780B
Description - Faster performance and responsiveness The RS2423+/RS2423RP+ offers exceptional performance with read/write speeds of more than 155,000/79,000 random read/write operations per second (IOPS) and up to 3,500/1,700 MB/s sequential read/write.1 These are excellent, cost-effective file management and sharing solutions for small and medium-sized businesses, with advanced backup features designed for businesses with growing data needs. Designed with reliability in mind The RS2423+ and RS2423RP+ units are equipped with one 10GbE RJ-45 port and Gigabit Ethernet ports, which can be connected using Link Aggregation to enable automatic network failover and load balancing. Two RS2423+/RS2423RP+ units can be paired using Synology High Availability to create a reliable server cluster with an active-passive architecture, maximising uptime. The RS2423RP+ is further equipped with redundant hot-swappable power supplies to protect service continuity in the event of a single power source problem. Space for expansion The 12-bay, 2U high RS2423+/RS2423RP+ can be easily adapted to your usage environment, whether you need higher performance, faster networking or more storage capacity. Versatile storage for businesses The RS2423+/RS2423RP+ server is ideal for small and medium-sized businesses and branch offices looking for a powerful, reliable and cost-effective storage solution for file management, data backup and surveillance. Data protection across multiple endpoints Design an effective backup strategy to maximise data and system availability with a range of native unlicensed solutions.
Description - RackStation RS2423RP+ Efficient storage for centralized data management “This products is eligible for Synology Extended Warranty Plus. You can purchase Extended Warranty Plus either from the DSM interface (version 7.1 and above) or from your Synology Account.” For this Synology product we are offering additional*, paid, support packages provided by Tehnogroup. Technogroup support packages includes services like on-site support, on-site post-warranty and NBD replacement.. Please contact your Account Manager for individual price offer. *Synology product price do not include additional support package costs
Design > Chassis type - Rack
dimension depth - 720 mm
dimension height - 255 mm
Dimensions - 88 mm x 482 mm x 578 mm
Dimensions - 88 x 482 x 578 mm
dimension weight - 16320 g
dimension width - 590 mm
Disk type - HDD
Disk type - SSD
EAN - 4711174724901
ean - 4711174724901
EAN_code - 4711174724901
Expansion slots - 1 x PCIe 3.0 x 8
Fan - 6 cm
File System - EXT4
Form factor (width) - 2,5'' (SFF)
Form factor (width) - 3,5'' (LFF)
Full Description Line - NAS Enterprise|CPU AMD Ryzen V1780B|Drives/bays 12|Rack 2U|2xUSB 3.2|3xRJ45|Memory 8 GB|DDR4|1xPCI-Express 3.0 8x|File System EXT4|Included Accessories Accessory Pack X 1AC Power Cord X 2Quick Installation Guide X 1|Power consumption 114.86 Watts|Power supply requirements 350 W
Gross Weight Kg - 17,85
guarantee - 60
guarantee_type - normal
HDD interface - SATA
Hot-swapping support - Yes
Housing - Rack 2U
I/O connectors - 2 x USB 3.0
I/O connectors - 3 x RJ-45 LAN
Included Accessories - Accessory Pack X 1
AC Power Cord X 2
Quick Installation Guide X 1
Link - https://www.synology.com/en-global/products/RS2423+
Management, monitoring, configuration -
Manufacturer - Synology
Manufacturer Code - RS2423RP+
Manufacturer Name - Synology
Manufacturer_code - RS2423RP+
Max. number of disks - 12
Max memory size - 32 GB
Memory - 8 GB
Memory > Internal memory type - DDR4
Memory > Internal RAM - 8 GB
Memory type - DDR4
Memory type - DDR4
Model - RS2423RP+
name - Server NAS RS2423RP+ 12x0HDD
Name - Synology RackStation RS2423RP+ (redundant power) 12-bay AMD Ryzen V1780B Processor frequency 3.6 GHz 8 GB DDR4
Name - Synology RS2423RP+, NAS
NAS features - Enterprise
Network architecture - GigabitEthernet
Network interface - 1 x 10Gbit/s 10GBase-T
Network interface - 2 x 10/100/1000 Mbit/s
Network protocols - SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Number of available memory slots - 1
Number of drives/bays - 12
Number of fans - 3
Number of HDDs installed - 0
Number of memory slots used - 1
Other disk parameters -
Other features -
Other features > Drive bays - 12
Other features > Ethernet LAN (RJ-45) ports - 3
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 100.00 mm
Package features > Gross height (mm) - 580.00 mm
Package features > Gross width (mm) - 500.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 2 pc(s)
Package features > Paper/Pasteboard - 450.00 g
Package features > Plastic (No PET) - 50.00 g
Package features > Tare weight (kg) - 0.50 kg
Package features > Volume (m3) - 0.03 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
PCI-Express 3.0 8x Expansion slots - 1
Ports & interfaces > Interface - 1x10GbE, 2x1GbE, 2xUSB 3.2
Power consumption - 114.86 Watts
Power supply - AC power input voltage: 100V to 240V AC Power frequency: 50/60 Hz, single phase
Power supply requirements - 350 W
Processor - AMD Ryzen V1780B 4-core 3.35 (base) / 3.6 (turbo) GHz
Processor > Processor family - AMD Ryzen
Processor > Processor frequency - 3.6 GHz
Processor > Processor model - V1780B
producer - Synology
Producer product family - RackStation
Producer product name - RS2423RP+ (redundant power) 12-bay
Rack 2U Mounting Type - Yes
RAID - Yes
RAID levels - 0
RAID levels - 1
RAID levels - 5
RAID levels - 6
RAID levels - 10 (1+0)
RJ45 Input/Output connectors - 3
Shipping Box Depth Shipping/Package Box Dimensions - 72 cm
Shipping Box Height Shipping/Package Box Dimensions - 25 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 16.35 kg
Shipping Box Width Shipping/Package Box Dimensions - 59 cm
Short description - Synology NAS Rack Station RS2423RP+ (12 Bay) 2U
Storage > RAID levels - 0,1,5,6,10,Hybr
Supported drives - 3.5" SATA HDD; 2.5" SATA SSD
Technical details > Gross weight - 12.40 kg
Technical details > Net weight - 11.90 kg
Technical details > Other features - System fans 3 x (60 x 60 x 38 mm)
Technical details > Warranty - 36 month(s)
Total number of memory slots - 2
Unit Box Height - 0.25
Unit Box Length - 0.72
Unit Box Width - 0.59
Unit Brutto Volume - 0.1062 cubm
Unit Gross Weight - 16.4 kg
Unit Net Weight - 11.9 kg
USB 3.2 Input/Output connectors - 2
Vendor Homepage - www.synology.com/en-my/products/RS2423RP+#specs
vendpn - RS2423RP+
Warranty - 36
Warranty - 36 months
Weight - 11.9 kg
Weight - 16,20
