Accessories included -
ARTIKEL1 - RX1330 M5 E-2334 1X16GB
ARTIKEL2 - 4XSFF 1X500W (TITANIUM) TPM 2.0
Brand - Fujitsu
BrandPartCode - VFY:R1335SC033IN
Breite - 0
Category - Servers
Certificates - Certification - CB, GS, CE, NRTLc/us, FCC, ICES-003, NMB-003, VCCI, JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
Chipset type - Intel C256
Color - Not applicable
Controller - other information - Intel C256
CPU - other information - Intel Xeon E-2334
CPU frequency - 3.4 GHz
CPU model - E-2334
CPU series - Intel Xeon
Depth - 612 mm
Description - PRIMERGY RX1330 M5 The Fujitsu PRIMERGY RX1330 M5 is a single-processor 1U server designed for small businesses and branch offices that require reliability, performance and serviceability to support critical business needs and customer data.
Design - Bezel - Yes
Design - Chassis type - Rack
Design - Product colour - Black, Stainless steel
Design - Rack mounting - Yes
dimension depth - 900 mm
dimension height - 260 mm
dimension weight - 16000 g
dimension width - 580 mm
Disk controller - SATA
ean - 4065221880493
EANCode - 4065221880493
Expansion slots - 1 x PCIe 3.0 x 4
Expansion slots - 2 x PCIe 4.0 x 8
Expansion slots - PCI Express x4 (Gen 3.x) slots - 1
Expansion slots - PCI Express x8 (Gen 4.x) slots - 2
Expansion slots - PCI slots - 1
Form factor (width) - 2,5'' (SFF)
Graphics -
GRUPPE1 - Computer Systems
GRUPPE2 - Server
GTIN - 4065221880493
guarantee - 12
guarantee_type - normal
Hard drive cage interfaces - SAS
Hard drive cage interfaces - SATA
Height - 43 mm
HERSTELLER - FUJITSU
Hoehe - 0
Hot-plug fans support - No
Hot-plug power supply support - Yes
Hot-swapping support - Yes
Housing - Rack 1U
HSTNUMMER - VFY:R1335SC033IN
I/O connectors - 1 x 15-pin D-Sub
I/O connectors - 1 x RJ-45 (iLO Remote Management Network)
I/O connectors - 1 x USB (Type C)
I/O connectors - 2 x RJ-45 LAN
I/O connectors - 2 x USB 2.0
I/O connectors - 2 x USB 3.0
Kind of memory - ECC
Laenge - 0
LongDesc - BOOST YOUR PRODUCTIVITYWorkload optimized performance for space and power constrained environments from the edge to the data center.SCALE YOUR IT ACCORDING TO YOUR NEEDSThe PRIMERGY RX1330 M5 delivers the flexibility to increase compute, storage, and memory capacity based on various configuration options and different base units.SIMPLIFY YOUR ITNew iRMC S6 enhances server administrator productivity with a variety of user-friendly features for remote management. Moreover, Infrastructure Manager (ISM) enables organizations to have centralized control over the entire infrastructure using a single user interface.GROW YOUR BUSINESSThe variety of expansion options makes the RX1330 M5 an ideal rack server platform for growing businesses. Outstanding configuration flexibility caters to a variety of business requirements and a range of HPE Qualified Options to fit most needs.
LongProductName - PRIMERGY RX1330 M5 / SFF / Hot-Plug PSU 500W / Intel Xeon E-2334 / 1x 16GB DDR4-3200 U ECC / NO HDD / RMK / iRMCs6 eLCM Lic
LongSummaryDescription - Fujitsu PRIMERGY RX1330 M5 / SFF / Hot-Plug PSU 500W / Intel Xeon E-2334 / 1x 16GB DDR4-3200 U ECC / NO HDD / RMK / iRMCs6 eLCM Lic. Processor family: Intel Xeon E, Processor frequency: 3.4 GHz, Processor model: E-2334. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM, Memory layout (slots x size): 1 x 16 GB. Ethernet LAN, Cabling technology: 10/100/1000Base-T(X). Power supply: 500 W, Redundant power supply (RPS) support. Chassis type: Rack
Max. number of disks in current configuration - 4
Max memory size - 128 GB
Max supported number of processors - 1
Memory - ECC - Yes
Memory - Internal memory - 16 GB
Memory - Internal memory type - DDR4-SDRAM
Memory - Maximum internal memory - 128 GB
Memory - Memory clock speed - 3200 MHz
Memory - Memory layout (slots x size) - 1 x 16 GB
Memory - Memory slots - 4x DIMM
Memory frequency - 3200 MHz
Memory type - DDR4
Model - PRIMERGY RX1330 M5
Motherboard - D3929
name - Server PRIMERGY RX1330 M5 E-2334 VFY:R1335SC033IN
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Ethernet interface type - Gigabit Ethernet
Network - Ethernet LAN - Yes
Network - LAN controller - Intel I210
Network card - other information - Intel i210
Network interface - 2 x 10/100/1000 Mbit/s
Number of available memory slots - 3
Number of cores - 4C
Number of CPUs installed - 1
Number of fans - 5
Number of HDDs installed - 0
Number of memory slots used - 1
Number of power supplies installed - 1
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 5 - 45 °C
Optical disk drive - None
Performance - BIOS type - UEFI
Performance - Noise level - 22 dB
Performance - Remote administration - iRMC S6
Performance - Trusted Platform Module (TPM) - Yes
Performance - Trusted Platform Module (TPM) version - 2.0
Ports & interfaces - Ethernet LAN (RJ-45) ports - 3
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 4
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - Power supply - 500 W
Power - Power supply input frequency - 50 / 60 Hz
Power - Power supply input voltage - 100 - 240 V
Power - Redundant power supply (RPS) support - Yes
Power supply output current - 500 W
Processor - Execute Disable Bit - Yes
Processor - Idle States - Yes
Processor - Maximum number of SMP processors - 1
Processor - Motherboard chipset - Intel C256
Processor - Number of processors installed - 1
Processor - Processor boost frequency - 4.6 GHz
Processor - Processor cache - 8 MB
Processor - Processor cores - 4
Processor - Processor family - Intel Xeon E
Processor - Processor frequency - 3.4 GHz
Processor - Processor manufacturer - Intel
Processor - Processor model - E-2334
Processor special features - CPU configuration (max) - 1
Processor special features - Enhanced Intel SpeedStep Technology - Yes
Processor special features - Intel 64 - Yes
Processor special features - Intel Software Guard Extensions (Intel SGX) - Yes
Processor special features - Intel Trusted Execution Technology - Yes
Processor special features - Intel Virtualization Technology (VT-x) - Yes
Processor special features - Intel Virtualization Technology for Directed I/O (VT-d) - Yes
Processor special features - Intel VT-x with Extended Page Tables (EPT) - Yes
producer - Fujitsu
ProductName - PRIMERGY RX1330 M5 / SFF / Hot-Plug PSU 500W / Intel Xeon E-2334 / 1x 16GB DDR4-3200 U ECC / NO HDD / RMK / iRMCs6 eLCM Lic
RAID levels - 0
RAID levels - 1
RAID levels - 5
RAID levels - 10 (1+0)
RAM - other information -
RAM memory installed - 16 GB
ShortSummaryDescription - Fujitsu PRIMERGY RX1330 M5 / SFF / Hot-Plug PSU 500W / Intel Xeon E-2334 / 1x 16GB DDR4-3200 U ECC / NO HDD / RMK / iRMCs6 eLCM Lic, 3.4 GHz, E-2334, 16 GB, DDR4-SDRAM, 500 W, Rack
Software - Compatible operating systems - Windows Server 2022 Datacenter, Windows Server 2022 Standard, Windows Server 2022 Essentials, Windows Server 2019 Datacenter, Windows Server 2019 Standard, Windows Server 2019 Essentials, VMware vSphere 7.0, Red Hat Enterprise Linux 8
Software - Operating system installed - No
Stck_Kart - 1
Stck_Pal - 7
Storage - Hot-Plug support - Yes
Storage - Number of HDDs supported - 4
Storage - Optical drive type - No
Storage - RAID support - Yes
Storage - Supported HDD sizes - 2.5"
Storno - N
Sustainability - Sustainability certificates - RoHS, WEEE
Sustainability - Sustainability compliance - Yes
Title - Fujitsu PRIMERGY RX1330 M5 / SFF / Hot-Plug PSU 500W / Intel Xeon E-2334 / 1x 16GB DDR4-3200 U ECC / NO HDD / RMK / iRMCs6 eLCM Lic
Total number of memory slots - 4
Tower to rack conversion support - No
URL - https://www.fujitsu.com/global/products/computing/servers/primergy/rack/rx1330m5/
vendpn - VFY:R1335SC033IN
Warranty - 1 year on-site
WarrantyInfo - 1 Year
Weight - 13 kg
Weight & dimensions - Depth - 612 mm
Weight & dimensions - Height - 43 mm
Weight & dimensions - Weight - 13 kg
Weight & dimensions - Width - 482.6 mm
Width - 482.6 mm
