Chieftec Polaris Series, 1250W, 80PLUS Gold, ATX 3.0

Brand - Chieftec
BrandPartCode - PPS-1250FC-A3
Category - Power Supply Units
Category_1 - Power
Category_2 - Computer Power Supplies
Design - Cooling type - Active
Design - Fan diameter - 13.5 cm
Design - Fan diameter - 14 cm
Design - Product colour - Black
dimensionalWeight - 1628
EAN_code - 0753263078155
GTIN - 753263078155
GTIN - 0753263078155
LongDesc - The CHIEFTEC Polaris 3.0 series is designed to Intel’s ATX 3.0 standard and supports PCIe GEN 5 with 80 PLUS® GOLD certified efficiency, promising exceptional performance. Polaris 3.0 features state-of-the-art technical design including LLC half-bridge converter with DC- to-DC technology, as well as Japanese main capacitors to achieve low ripple and tight voltage regulation. The Polaris 3.0 135mm FDB silent fan optimizes the balance between cooling and noise with excellent durability. Fully modular cable management ensures a clean and convenient build inside any system.
LongProductName - POLARIS 3.0 1250W, ATX 3.0, PCIe GEN5, 80Plus Gold
LongSummaryDescription - Chieftec Polaris 3.0 1250W. Total power: 1250 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 65 cm, SATA power cable length: 100,550 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Width: 150 mm, Depth: 160 mm, Height: 86 mm
Manufacturer - Chieftec
Manufacturer_code - PPS-1250FC-A3
Name - Chieftec PPS-1250FC-A3 1250W, PC power supply (black, cable management, 1250 watts)
Packaging data - Package type - Box
Packaging data - Package weight - 3.35 kg
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - ATX version - 3.0
Performance - Bearing technology - FDB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - Cabling type - Modular
Ports & interfaces - EPS power connector (4+4 pin) - Yes
Ports & interfaces - EPS power connector (8-pin) - Yes
Ports & interfaces - Motherboard power cable length - 65 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 12
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - PCI Express power connectors (16-pin) - 1
Ports & interfaces - Peripheral (Molex) power cable length - 100,550 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Ports & interfaces - SATA power cable length - 100,550 mm
Power - AC input frequency - 50 - 60 Hz
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 120 W
Power - Combined power (+5V) - 120 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 1250 W
Power - Combined power (-12V) - 0.3 W
Power - Combined power (-12V) - 3.6 W
Power - Input current - 15 - 8 A
Power - Input current - 15-8 A
Power - Max output current (+3.3V) - 22 A
Power - Max output current (+5V) - 22 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 104.1 A
Power - Max output current (+12V1) - 104.1 A
Power - Max output current (-12V) - 0.3 A
Power - Max output current (-12V) - 3.6 A
Power - Peak power - 1250 W
Power - Power factor - 0.9
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current
Power - Power protection features - Over current, Over power, Over voltage, Short circuit, Under voltage
Power - Power protection features - Overheating
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 1250 W
producerCode - PPS-1250FC-A3
productName - Chieftec POLARIS PPS-1250FC-A3 power supply unit
ProductName - POLARIS 3.0 1250W
productSize - Normal
ShortSummaryDescription - Chieftec Polaris 3.0 1250W, 1250 W, 100 - 240 V, 50/60 Hz, 15-8 A, Active, 120 W
sizeX - 216
sizeY - 108
sizeZ - 349
Technical details - Sustainability certificates - CB, CE, EAC, Federal Communications Commission (FCC), RoHS
Technical details - Sustainability certificates - CE
Technical details - Sustainability certificates - ErP
Technical details - Sustainability certificates - RoHS
Technical details - Sustainability compliance - Yes
Technical details - Warranty period - 5 year(s)
Title - Chieftec Polaris 3.0 1250W power supply unit 20+4 pin ATX ATX Black
URL - https://www.chieftec.eu/products-detail/544/POLARIS_3.0_SERIES_/549/PPS-1250FC-A3
WarrantyInfo - 5 Years
warrantyLength - 24
warrantyType - G
Weight - 3,39
weight - 3388
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Depth - 160 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 3.01 kg
Weight & dimensions - Width - 150 mm
Weight & dimensions - Width - 160 mm
