Arctic Liquid Freezer III Pro 420 A-RGB White

Airflow Performance - 186 m³/h
Base plate material Design - Copper
Bearing type Performance - Fluid Dynamic Bearing (FDB)
Brand - ARCTIC
BrandPartCode - ACFRE00189A
Category - Computer Cooling Systems
category - Liquid Cooling|Sets & Bundles|AIO Liquid Coolers|420 mm AiOs
Category - Root/Electronics/PC parts/Cooling/Processor fans
Category1 - CPU Cooler
Category 1 - CPUs
Category 2 - CPU Kühler & Zubehör
Category Code - COC
Category_1 - Computer Cases and Cooling
Category_2 - Watercooling
category_en - Computers & Components > Computer components > Cooling systems
category_lv - Datortehnika > Datoru komponentes > Dzesēšanas sistēmas
category_ru - Datortehnika > Datoru komponentes > Dzesēšanas sistēmas
CnCode - 84145925
code - ACFRE00189A
Depth Weight & dimensions - 68 mm
Description - CPU Water Coolers
Outstanding cooling performance through liquid cooling. ARCTIC's Premium Liquid Freezer range offers impressively high performance at moderate prices without the complexity of conventional CPU water coolers. Completely maintenance-free, the all-in-one cooler with various models for smaller and larger cases covers all the most important current CPU sockets.
Description1 - ARCTIC water cooler Liquid Freezer III Pro 420 A-RGB White
Description2 - CPU Water CoolersOutstanding cooling performance through liquid cooling. ARCTIC's Premium Liquid Freezer range offers impressively high performance at moderate prices without the complexity of conventional CPU water coolers. Completely maintenance-free, the all-in-one cooler with various models for smaller and larger cases covers all the most important current CPU sockets.
description_en - Product Name • Arctic Liquid Freezer III Pro 420 A-RGB Overview • Wide compatibility CPU cooler with A-RGB lighting effects • Compatible with Intel Alder Lake and Raptor Lake LGA1700 processors • Compatible with the new socket LGA1851 of Arrow Lake • Compatible with AMD AM5 and AM4 Features • Multi-compatible with most common Intel and AMD sockets • New P14 Pro A-RGB fan: quieter and more powerful at low speeds, with greater performance reserves under load for maximum cooling without compromise • 38 mm radiator improves heat dissipation and holds more liquid than conventional 27 mm radiators • Requires at least 63 mm of clearance for installation • Two connection cables provide two control options: • Splitter cable allows the pump, VRM fan, and radiator fans to be controlled separately • All-in-one cable allows the pump, VRM fan, and radiator fans to be synchronized via a single PWM signal • Offset Mounting for Intel and AMD shifts the cold plate to the CPU hotspot for more efficient heat transfer • Intel Contact Frame provides optimized contact pressure distribution for longer CPU lifespan and improved heat dissipation • Integrated VRM Fan: PWM-controlled fan lowers the voltage regulator temperature, ensuring stable performance • Includes MX-6 Thermal Paste: apply in a cross pattern; the water pump’s cold plate distributes the paste evenly • New A-RGB fans allow for perfectly matched, multi-color lighting effects • Advanced A-RGB technology and customizable LEDs allow you to design your system with your own look Note • Some motherboards are incompatible with the Liquid Freezer III Pro due to oversized SSD coolers in the M.2_1 slot • Compatibility information: https://support.arctic.de/lf3-compatibility Specifications • Pump speed: 800 - 2800 RPM • Pump voltage / current: 12V DC / 0.35A • Plate material: copper • Tube length: 450 mm • Tube diameter: outer 12.4 mm, inner 6.0 mm • VRM fan speed: 400 - 2500 RPM • VRM voltage / current: 12V DC / 0.35A • Thermal paste: MX-6 (0.8g) • Fan: 3x P14 Pro A-RGB • Fan speed: 400 - 2500 RPM • Air flow: 110 CFM / 186 m³/h • Static pressure: 5.2 mm H2O • Connector: 4-Pin PWM+ 3-Pin A-RGB • Bearing: Fluid dynamic bearing • Fan voltage / current: 12V DC / 0.35A • LED: 12x A-RGB Gen2 • RGB voltage / current: 5V DC / 0.40A • Dimensions: 458 x 138 x 38 mm • Weight: 2358 g • Color: white body, optional lighting Compatibility • AMD AM4 • AMD AM5 • Intel LGA1851 • Intel LGA1700 • Intel 1700 Warranty
• 6 years
description_lv - Produkta nosaukums • Arctic Liquid Freezer III Pro 420 A-RGB Pārskats • Plašas saderības CPU dzesētājs ar A-RGB apgaismojuma efektiem • Savietojams ar Intel Alder Lake un Raptor Lake LGA1700 procesoriem • Savietojams ar jauno Arrow Lake ligzdu LGA1851 • Saderīgs ar AMD AM5 un AM4 Funkcijas • Multi-saderība ar visbiežāk sastopamajām Intel un AMD ligzdām • Jauns P14 Pro A-RGB ventilators: klusāks un jaudīgāks pie maziem ātrumiem, ar lielākām veiktspējas rezervēm zem slodzes maksimālai dzesēšanai bez kompromisiem • 38 mm radiators uzlabo siltuma izkliedi un satur vairāk šķidruma nekā parastie 27 mm radiatori • Uzstādīšanai nepieciešams vismaz 63 mm brīvs attālums • Divi savienojuma kabeļi nodrošina divas vadības iespējas: • Sadalītāja kabelis ļauj atsevišķi vadīt sūkni, VRM ventilatoru un radiatora ventilatorus • Viss vienā kabelis ļauj sinhronizēt sūkni, VRM ventilatoru un radiatora ventilatorus, izmantojot vienu PWM signālu • Intel un AMD nobīdes stiprinājums pārvieto auksto plati uz CPU karsto punktu, lai nodrošinātu efektīvāku siltuma pārnesi. • Intel Contact Frame nodrošina optimizētu kontaktu spiediena sadali, lai nodrošinātu ilgāku CPU kalpošanas laiku un uzlabotu siltuma izkliedi • Integrēts VRM ventilators: PWM kontrolēts ventilators pazemina sprieguma regulatora temperatūru, nodrošinot stabilu veiktspēju • Ietver MX-6 termisko pastu: uzklājiet krusteniski; ūdens sūkņa aukstā plāksne vienmērīgi sadala pastu • Jaunie A-RGB ventilatori nodrošina perfekti saskaņotus, daudzkrāsu apgaismojuma efektus • Uzlabotā A-RGB tehnoloģija un pielāgojamas gaismas diodes ļauj izveidot sistēmu atbilstoši savam izskatam Piezīme • Dažas mātesplates nav saderīgas ar Liquid Freezer III Pro, jo M.2_1 slotā ir pārāk lieli SSD dzesētāji. • Informācija par saderību: https://support.arctic.de/lf3-compatibility Specifikācijas • Sūkņa ātrums: 800 - 2800 RPM • Sūkņa spriegums / strāva: 12V DC / 0,35A • Plākšņu materiāls: varš • Caurules garums: 450 mm • Caurules diametrs: ārējais 12,4 mm, iekšējais 6,0 mm • VRM ventilatora ātrums: 400 - 2500 RPM • VRM spriegums / strāva: 12V DC / 0,35A • Termiskā pasta: MX-6 (0,8 g) • Ventilators: 3x P14 Pro A-RGB • Ventilatora ātrums: 400 - 2500 RPM • Gaisa plūsma: 110 CFM / 186 m³/h • Statiskais spiediens: 5,2 mm H2O • Savienotājs: 4 kontaktu PWM+ 3 kontaktu A-RGB • Gultnis: Šķidruma dinamiskais gultnis • Ventilatora spriegums / strāva: 12V DC / 0,35A • LED: 12x A-RGB Gen2 • RGB spriegums / strāva: 5V DC / 0,40A • Izmēri: 458 x 138 x 38 mm • Svars: 2358 g • Krāsa: balts korpuss, pēc izvēles apgaismojums Saderība • AMD AM4 • AMD AM5 • Intel LGA1851 • Intel LGA1700 • Intel 1700 Garantija
• 6 gadi
description_ru - Название продукта • Arctic Liquid Freezer III Pro 420 A-RGB Обзор • Широкая Совместимость процEUсорного кулера со световыми эффектами A-RGB. • Совместимость с процессорами Intel Alder Lake и Raptor Lake LGA1700. • Совместимость с новым разъемом LGA1851 Arrow Lake. • Совместимость с AMD AM5 и AM4. Особенности • МультиСовместимость с большинством распространенных разъемов Intel и AMD. • Новый вентилятор P14 Pro A-RGB: тише и мощнее на низких скоростях, с большим запасом производительности под нагрузкой для максимального охлаждения без компромиссов. • Радиатор диаметром 38 мм улучшает рассеивание тепла и удерживает больше жидкости, чем обычные радиаторы диаметром 27 мм. • Для установки требуется зазор не менее 63 мм. • Два соединительных кабеля обеспечивают два варианта управления: • Разветвительный кабель позволяет раздельно управлять насосом, вентилятором VRM и вентиляторами радиатора. • Универсальный кабель позволяет синхронизировать насос, вентилятор VRM и вентиляторы радиатора с помощью одного ШИМ-сигнала. • При смещенном монтаже для процEUсоров Intel и AMD холодная пластина смещается к горячей точке процессора для более эффективной теплопередачи. • Intel Contact Frame Обеспечивает оптимизированное распределение контактного давления для увеличения срока службы процессора и улучшения рассеивания тепла. • Встроенный вентилятор VRM: вентилятор с ШИМ-управлением снижает температуру регулятора напряжения, обEUпечивая стабильную работу. • В комплект входит термопаста MX-6: наносите крEUт-накрEUт; Холодная пластина водяного насоса равномерно распределяет пасту • Новые вентиляторы A-RGB обеспечивают идеально подобранные многоцветные световые эффекты. • Усовершенствованная технология A-RGB и настраиваемые светодиоды позволяют придать системе индивидуальный вид. Примечание • Некоторые материнские платы нEUовмEUтимы с Liquid Freezer III Pro из-за слишком большого размера SSD-кулеров в слоте M.2_1. • Информация о Совместимости: https://support.arctic.de/lf3-compatibility. Технические характеристики • Скорость насоса: 800–2800 об/мин. • Напряжение/ток насоса: 12 В постоянного тока/0,35 А. • Материал пластины: медь • Длина трубки: 450 мм • Диаметр трубки: внешний 12,4 мм, внутренний 6,0 мм. • Скорость вентилятора VRM: 400–2500 об/мин. • Напряжение/ток VRM: 12 В постоянного тока/0,35 А. • Термопаста: MX-6 (0,8 г). • Вентилятор: 3x P14 Pro A-RGB • Скорость вентилятора: 400–2500 об/мин. • Расход воздуха: 110 куб. футов в минуту / 186 м³/ч. • СтатичEUкое давление: 5,2 мм H2O. • Разъем: 4-контактный ШИМ + 3-контактный A-RGB • Подшипник: гидродинамичEUкий подшипник • Напряжение/ток вентилятора: 12 В постоянного тока/0,35 А. • Светодиод: 12x A-RGB Gen2 • Напряжение/ток RGB: 5 В постоянного тока/0,40 А • Размеры: 458 х 138 х 38 мм. • ВEU: 2358 г. • Цвет: белый корпус, дополнительная подсветка. Совместимость • AMD AM4 • AMD AM5 • Intel LGA1851 • Intel LGA1700 • Интел 1700 Гарантия
• 6 лет
Design - Base plate material - Copper
Design - Display type - Not applicable
Design - Fan connector - 4-pin
Design - Illumination colour - Multi
Design - Illumination LED - Yes
Design - LED connector type - 3-pin + 3-pin
Design - Number of fans - 3 fan(s)
Design - Product colour - White
Design - Radiator material - Aluminum
ean - 4895265000362
EAN - 4895265000362
Eans - 4895265000362
EAN_code - 4895265000362
Fan connector Design - 4-pin
Fan current Power - 0.35 A
Fan diameter Performance - 14 cm
Fan voltage Power - 12 V
gross_weight - 3.2 kg
GTIN - 4895265000362
Height Weight & dimensions - 138 mm
Illumination colour Design - Multi
Illumination LED Design - Yes
LED connector type Design - 3-pin + 3-pin
LED voltage Power - 5 V
LongDesc - CPU Water CoolersOutstanding cooling performance through liquid cooling. ARCTIC's Premium Liquid Freezer range offers impressively high performance at moderate prices without the complexity of conventional CPU water coolers. Completely maintenance-free, the all-in-one cooler with various models for smaller and larger cases covers all the most important current CPU sockets.
LongProductName - 800–2800 RPM/400–2500 RPM, 110 cfm, 5.2 mmH2O, A-RGB, 2358 g, White
LongSummaryDescription - ARCTIC Liquid Freezer III Pro 420 A-RGB (White) - Multi Compatible All-in-One CPU Water Cooler with A-RGB. Type: All-in-one liquid cooler, Fan diameter: 14 cm, Rotational speed (min): 400 RPM, Rotational speed (max): 2500 RPM, Airflow: 186 m³/h, Maximum air pressure: 5.2 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Width: 458 mm, Depth: 68 mm, Height: 138 mm. Product colour: White
Manufacturer - Arctic
Manufacturer - ARCTIC
Manufacturer - Arctic Cooling
ManufacturerID - ACFRE00189A
Manufacturer_code - ACFRE00189A
Maximum airflow Performance - 110 cfm
Maximum air pressure Performance - 5.2 mmH2O
Model -
Model - ACFRE00189A
Model name - Liquid Freezer III Pro 420 A-RGB (White)
MPN - ACFRE00189A
Name - ARCTIC Liquid Freezer III Pro 420 A-RGB, water cooling white
name - Arctic Liquid Freezer III Pro A-RGB 420 AIO Cooler - 420mm, white
Name - Arctic Liquid Freezer III PRO ARGB - 420mm | biały
Name - CPU COOLER S_MULTI/ACFRE00189A ARCTIC
Name - K Cooler Wasserkühlung Arctic Liquid Freezer III Pro 420 A-RGB (White)
Number of fans Design - 3 fan(s)
Operating temperature (T-T) Performance - 0 - 40 °C
Package depth Weight & dimensions - 447 mm
PackageHeight - 336
Package height Weight & dimensions - 158 mm
PackageLength - 446
Package type Packaging content - Box
PackageWeight - 3362.5
Package weight Weight & dimensions - 2.98 kg
PackageWidth - 162
Package width Weight & dimensions - 328 mm
Packaging content - Package type - Box
Performance - Airflow - 186 m³/h
Performance - Bearing type - Fluid Dynamic Bearing (FDB)
Performance - Fan diameter - 14 cm
Performance - Maximum airflow - 110 cfm
Performance - Maximum air pressure - 5.2 mmH2O
Performance - Operating temperature (T-T) - 0 - 40 °C
Performance - Pulse-width modulation (PWM) support - Yes
Performance - Pump motor speed (max) - 2800 RPM
Performance - Pump motor speed (min) - 800 RPM
Performance - Rotational speed (max) - 2500 RPM
Performance - Rotational speed (min) - 400 RPM
Performance - Suitable location - Processor
Performance - Supported processor sockets - LGA 1700, LGA 1851, Socket AM4, Socket AM5
Performance - Type - All-in-one liquid cooler
Performance - VRM fan speed (max) - 2500 RPM
Performance - VRM fan speed (min) - 400 RPM
Power - Fan current - 0.35 A
Power - Fan voltage - 12 V
Power - LED voltage - 5 V
Power - Pump current - 0.35 mA
Power - Pump voltage - 12 V
Producer - Arctic
ProducerCode - ACFRE00189A
Product colour Design - White
ProductName - Liquid Freezer III Pro 420 A-RGB (White) - Multi Compatible All-in-One CPU Water Cooler with A-RGB
Product Net Weight ELKO Verified Logistics Data - 2.358 kg
Pulse-width modulation (PWM) support Performance - Yes
Pump current Power - 0.35 mA
Pump motor speed (max) Performance - 2800 RPM
Pump motor speed (min) Performance - 800 RPM
Pump voltage Power - 12 V
Radiator depth Weight & dimensions - 45.8 cm
Radiator height Weight & dimensions - 3.8 cm
Radiator material Design - Aluminum
Radiator width Weight & dimensions - 13.8 cm
Rotational speed (max) Performance - 2500 RPM
Rotational speed (min) Performance - 400 RPM
Shipping Box Depth ELKO Internal Logistics Data - 40.7 cm
Shipping Box Height ELKO Internal Logistics Data - 54.3 cm
Shipping Box Weight ELKO Internal Logistics Data - 13.5 kg
Shipping Box Width ELKO Internal Logistics Data - 34 cm
ShortDescription -
ShortSummaryDescription - ARCTIC Liquid Freezer III Pro 420 A-RGB (White) - Multi Compatible All-in-One CPU Water Cooler with A-RGB, All-in-one liquid cooler, 14 cm, 400 RPM, 2500 RPM, 186 m³/h, White
Suitable location Performance - Processor
Summary - ARCTIC Liquid Freezer III Pro 420 A-RGB (White) - Multi Compatible All-in-One CPU Water Cooler with A-RGB. Type: All-in-one liquid cooler, Fan diameter: 14 cm, Rotational speed (min): 400 RPM, Rotational speed (max): 2500 RPM, Airflow: 186 m³/h, Maximum air pressure: 5.2 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Width: 458 mm, Depth: 68 mm, Height: 138 mm. Product colour: White
Supported processor sockets Performance - LGA 1700, LGA 1851, Socket AM4, Socket AM5
Title - ARCTIC Liquid Freezer III Pro 420 A-RGB (White) - Multi Compatible All-in-One CPU Water Cooler with A-RGB
title_en - ARCTIC Liquid Freezer III Pro 420 A-RGB CPU Liquid Cooler, White
title_lv - ARCTIC Liquid Freezer III Pro 420 A-RGB Šķidrās dzesēšanas sistēma priekš procesora, balts
title_ru - ARCTIC Liquid Freezer III Pro 420 A-RGB Жидкостная система охлаждения для процессора, белый
Tube diameter Weight & dimensions - 1.24 cm
Tube inner diameter Weight & dimensions - 6 mm
Tube length Weight & dimensions - 50 cm
Type Performance - All-in-one liquid cooler
Unit Box Height - 0.162
Unit Box Length - 0.447
Unit Box Width - 0.33
Unit Calculated Volume ELKO Internal Logistics Data - 0.01879 cubm
Unit Calculated Weight ELKO Verified Logistics Data - 3.38 kg
Unit Depth ELKO Verified Logistics Data - 44.7 cm
Unit Height ELKO Verified Logistics Data - 16.2 cm
Units per Pallet ELKO Verified Logistics Data - 0
Units per Shipping Box ELKO Verified Logistics Data - 4
Unit Width ELKO Verified Logistics Data - 33 cm
UPC - 840033403030
URL - https://www.arctic.de/en/Liquid-Freezer-III-Pro-420-A-RGB-White/ACFRE00189A
Vendor Homepage - https://www.arctic.de/en/Liquid-Freezer-III-Pro-420-A-RGB-White/ACFRE00189A
VRM fan speed (max) Performance - 2500 RPM
VRM fan speed (min) Performance - 400 RPM
Warranty - 24 months
WarrantyInfo - 6 Years
WEEE - DE83654239
weight - 2.3 kg
Weight - 3,10
Weight - 3.09
Weight & dimensions - Depth - 68 mm
Weight & dimensions - Height - 138 mm
Weight & dimensions - Package depth - 447 mm
Weight & dimensions - Package height - 158 mm
Weight & dimensions - Package weight - 2.98 kg
Weight & dimensions - Package width - 328 mm
Weight & dimensions - Radiator depth - 45.8 cm
Weight & dimensions - Radiator height - 3.8 cm
Weight & dimensions - Radiator width - 13.8 cm
Weight & dimensions - Tube diameter - 1.24 cm
Weight & dimensions - Tube inner diameter - 6 mm
Weight & dimensions - Tube length - 50 cm
Weight & dimensions - Weight - 2.36 kg
Weight & dimensions - Width - 458 mm
Weight Weight & dimensions - 2.36 kg
Width Weight & dimensions - 458 mm
