MSI MAG CoreLiquid E240

Accessories included - Fan PWM Cable 1 to 2 x 1 Molex 4-Pin to 4-Pin Fan Cable x 1 Thermal paste x 1
Air flow - 75.04 cfm
Air flow rates - 75.04 cfm
Bearing type - Fluid
Brand - MSI
BrandPartCode - MAG CORELIQUID E240
Category - Computer Cooling Systems
Category - Root/Electronics/PC parts/Cooling/Processor fans
category - Watercooling All in One Sets - internal
Category Code - COC
code - 306-7ZW5E17-C24
Colour - Black
Cooler type - Liquid
Cooling technology - Liquid
CPU socket - LGA1150
CPU socket - LGA1151
CPU socket - LGA1155
CPU socket - LGA1156
CPU socket - LGA1200
CPU socket - LGA1700
CPU socket - Socket AM4
CPU socket - Socket AM5
Description - MAG CORELIQUID E240 cooling The enlarged copper base surface helps achieve the highest heat transfer with the latest generation of processors. Maximize micro channels for efficient heat dissipation 270 degree rotatable water block cap. The ARGB fan can change the lighting via MSI center. Increased fan efficiency for rapid heat dissipation. The pump separates cold and hot water areas to avoid mixing water temperatures and effectively reduce the heat source. The durable three-phase pump motor generates minimal vibrations, ensuring long-lasting operation. The path distributed by the heat sink quickly dissipates heat.
Description - The MAG CORELIQUID E Series, inspired by the passing of time and the shape of solar eclipse, is an innovative product that combines advanced cooling technology with a striking visual design. The MAG CORELIQUID E Series’ circular shape represents the cyclical nature of time and the continuous flow of energy.
Design - Fan connector - 4-pin
Design - Illumination colour - Multi
Design - Illumination LED - Yes
Design - LED backlighting type - ARGB
Design - Number of fans - 2 fan(s)
Design - Product colour - Black
Design - Radiator material - Aluminium
Design - Radiator material - Aluminum
dimensionalWeight - 2331
dimension depth - 145 mm
dimension height - 210 mm
Dimensions - Fan dimensions: 120x120x25mm Cable length (5V ARGB/PWM cable): 550/500 mm Heatsink size: 240mm Radiator dimensions: 277 x 119.2 x 27 mm Water cooling tube length: 400 mm
dimension weight - 1990 g
dimension width - 370 mm
ean - 4711377115728
Eans - 4711377115728
Fan - 12 cm
Fan light - Yes
Fan size group - 120mm
Fan speed - 600 ~ 1800rpm
Fan speed (max) - 600 rpm
Fan speed (min) - 2000 rpm
Full Description Line - MAG CORELIQUID E240|Liquid|LGA1150/LGA1151/LGA1155/LGA1156/LGA1200/LGA1700/SAM4/SAM5|Fan speed 600 ~ 1800rpm|Air flow 75.04 cfm|Fan light|Noise level, max 32.5 dB|Colour Black|Weight 1.4 kg
GTIN - 4711377115728
guarantee - 36
guarantee_type - normal
Logistics data - Harmonized System (HS) code - 84733080
LongDesc - MAG - Unite as OneThe MAG series fights alongside gamers in pursuit of honor. With added military-inspired elements in these gaming products, they were reborn as the symbol of sturdiness and durability.The MAG CORELIQUID E Series, inspired by the passing of time and the shape of solar eclipse, is an innovative product that combines advanced cooling technology with a striking visual design. The MAG CORELIQUID E Series’ circular shape represents the cyclical nature of time and the continuous flow of energy.ROTATABLE BLOCKHEADMount the cold plate at any orientation, turn the blockhead up to 270 degrees, and keep it upright.ACHIEVE FULL CPU COVERAGEBy enlarging the contact area between the coolant and the copper base of the water block, the MAG CORELIQUID E Series maximizes heat dissipation from the CPU. The enhanced density of the micro-channel design improves the efficiency of the water cooling system by enlarging the contact surface area.PUMP COOLING DESIGNEnsures that the cooled water temperature can be delivered to the desired location of the heat source, effectively reducing the temperature of the heat source.PUMP MOTOR RESONANCE ELIMINATIONA durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.HIGH THERMAL DISSIPATIONThe radiator has a 12 pathway designed to help rapidly dissipate heat.EVAPORATION PROOF TUBINGThe multi-layer structure effectively prevents the liquid from evaporating, while the reinforced mesh plastic tube enhances the durability of the exterior mesh.FAN CONSTRUCTIONThe fan's FDB bearing helps reduce noise level while minimizing vibrations.The fan blades are constructed of low impurity acrylic for better ARGB lighting presentation.INTEGRATING WITH THE SYSTEM ENVIRONMENTWith the MSI CENTER software, users can integrate MSI liquid cooling with MSI motherboard and adjust the speed of the cooling fan and pump through the motherboard. The MSI CENTER provides users with easy-to-use controls to fine-tune their hardware and achieve optimal computer performance.GLOW YOUR PCSplash on some color and vibrant RGB lighting effects using MSI Mystic Light with 16.8 million colors and fancy LED effects. MSI Mystic Light provides you complete control of RGB lighting of your PC in one software.
LongProductName - 240 mm, 4-pin, ARGB, 20 dBA, 3000 RPM, 120 x 120 x 25mm
LongSummaryDescription - MSI MAG CORELIQUID E240. Type: Liquid cooling kit, Fan diameter: 12 cm, Maximum airflow: 75.04 cfm. Product colour: Black
Model name - MAG CORELIQUID E240
name - MAG CORELIQUID E240 240mm 2xARGB FAN
Name - MSI MAG CORELIQUID E240
name - MSI MAG Coreliquid E240 Kompett-Wasserkühlung - 240 mm
Noise - 32.5 dB
Noise level, max - 32.5 dB
Number of fans - 2
Other features -
Performance - Fan's mean time to failure (MTTF) - 50000 h
Performance - Fan diameter - 12 cm
Performance - Fan noise level (max) - 32.5 dB
Performance - Fan noise level (min) - 11.2 dB
Performance - Fan speed (max) - 2000 RPM
Performance - Fan speed (min) - 600 RPM
Performance - Maximum airflow - 75,04 cfm
Performance - Maximum airflow - 75.04 cfm
Performance - Maximum air pressure - 2.52 mmH2O
Performance - Minimum airflow (imperial) - 25,5 cfm
Performance - Minimum airflow (imperial) - 25.5 cfm
Performance - Minimum air pressure - 0.31 mmH2O
Performance - Pulse-width modulation (PWM) support - Yes
Performance - Pump's mean time to failure (MTTF) - 200000 h
Performance - Pump connector - 4-pin
Performance - Pump motor speed - 3000 RPM
Performance - Pump noise level - 20 dB
Performance - Suitable location - Motherboard, Processor
Performance - Suitable location - Processor
Performance - Supported processor sockets - LGA 1150 (Socket H3)
Performance - Supported processor sockets - LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700
Performance - Supported processor sockets - LGA 1151 (Socket H4)
Performance - Supported processor sockets - LGA 1155 (Socket H2)
Performance - Supported processor sockets - LGA 1156 (Socket H)
Performance - Supported processor sockets - LGA 1200 (Socket H5)
Performance - Supported processor sockets - LGA 1700
Performance - Supported processor sockets - Socket AM4
Performance - Supported processor sockets - Socket AM5
Performance - Type - Liquid cooling kit
Power - Fan current - 0.25 A
Power - Fan power consumption - 3 W
Power - Pump current - 500 mA
Power - Pump power consumption - 4.8 W
Power - Pump power consumption - 6 W
producer - MSI
Producer - MSI
ProducerCode - 306-7ZW5E11-C24
producerCode - 306-7ZW5E17-C24
ProductName - MAG CORELIQUID E240
productName - MSI MAG CORELIQUID E240 Water Cooler
productSize - Normal
Radiator - Aluminium
Radiator material - Aluminum
Shipping Box Depth Shipping/Package Box Dimensions - 37 cm
Shipping Box Height Shipping/Package Box Dimensions - 14 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 2.01 kg
Shipping Box Width Shipping/Package Box Dimensions - 20.7 cm
ShortDescription - wentylator CPU - chłodzenie wodne |
ShortSummaryDescription - MSI MAG CORELIQUID E240, Liquid cooling kit, 12 cm, 75.04 cfm, Black
sizeX - 370
sizeY - 210
sizeZ - 150
Socket - LGA1150/LGA1151/LGA1155/LGA1156/LGA1200/LGA1700/SAM4/SAM5
Stand / CPU block - Copper
Title - MSI MAG CORELIQUID E240 computer cooling system Motherboard, Processor Liquid cooling kit 12 cm Black
Type of cooling - Active
Unit Box Height - 0.14
Unit Box Length - 0.37
Unit Box Width - 0.207
Unit Brutto Volume - 0.01072 cubm
Unit Gross Weight - 2.01 kg
Unit Net Weight - 1.4 kg
URL - https://www.msi.com/Liquid-Cooling/MAG-CORELIQUID-E240
Vendor Homepage - www.msi.com/Liquid-Cooling/MAG-CORELIQUID-E240/Overview
vendpn - MAG CORELIQUID E240
Warranty - 24 months
WarrantyInfo -
warrantyLength - 36
warrantyType - G
weight - 2000
Weight & dimensions - Cable length - 500 m
Weight & dimensions - Fan dimensions (W x D x H) - 120 x 120 x 25 mm
Weight & dimensions - Radiator depth - 11.9 cm
Weight & dimensions - Radiator height - 2.7 cm
Weight & dimensions - Radiator width - 27.7 cm
Weight & dimensions - Tube length - 40 cm
Weight & dimensions - Waterblock depth - 4.76 cm
Weight & dimensions - Waterblock width - 4.1 cm
