ARTIKEL1 - CORE I7-13700F 2.10GHZ
ARTIKEL2 - SKTLGA1700 30.00MB CACHE BOXED
Artikuls - BX8071513700FSRMBB
Brand - Intel
BrandPartCode - BX8071513700F
Breite - 0.11
Cache - 30MB
Category - Processors
category - Processors (CPU) Socket 1700 (Intel)
Category - Root/Electronics/PC parts/Processors
Category 1 - CPUs
Category 2 - Intel CPUs
Category Code - CPU
Category_1 - Processors
Category_2 - Processors - Intel 1700
Clock speed - 2100 MHz
code - BX8071513700F
Compatible with -
Cooling Method - Cooling Fan
Core name - Raptor Lake
Core Name - Raptor Lake
Core Quantity - 16
CPU - INTEL Core i7-13700F
CPU application - Desktop
CPU Boost frequency - 5.2 GHz
CPU Cache Size - 30 MB
CPU code - Intel Core i7-13700F
CPU Family name - Core i7
CPU frequency - 2.1 GHz
CPU socket - LGA1700
Description - Boxed Intel® Core™ i7-13700F Processor (30M Cache, up to 5.20 GHz) FC-LGA16A
Description - Intel Core i7-13700F desktop processor 13th Gen Intel Core i7-13700F desktop processor, no GPU. Equipped with Intel Turbo Boost Max Technology 3.0 and support for PCIe 5.0 and 4.0, support for DDR5 and DDR4, the 13th Gen Intel Core i7 desktop processors are optimized for gaming and productivity and help deliver high performance. Discrete graphics card required. Compatible with motherboards based on Intel 700 and Intel 600 series chipsets. Base processor power 65 W.
dimensionalWeight - 206
dimension depth - 405 mm
dimension height - 115 mm
dimension weight - 2452 g
dimension width - 130 mm
ean - 5032037260237
EAN - 5032037260237
EAN Code - 5032037260237
EANCode - 5032037260237
Eans - 5032037260237
EAN_code - 5032037260237
ECC support - No
Efficient-core Base Clock Rate - 1.5 GHz
Efficient-cores Quantity - 8
Efficient-core Turbo Clock Rate - 4.1 GHz
Features - Enhanced SpeedStep TechnologyExecute Disable BitHyper-Threading TechnologyIntel Virtualization TechnologyStreaming SIMD Extensions 4.1Streaming SIMD Extensions 4.2Thermal Monitoring TechnologiesAdvanced Vector Extensions
Features - Commodity Classification Automated Tracking System (CCATS) - 740.17B1
Features - CPU configuration (max) - 1
Features - Direct Media Interface (DMI) Revision - 4.0
Features - Embedded options available - No
Features - Execute Disable Bit - Yes
Features - Export Control Classification Number (ECCN) - 5A992C
Features - Idle States - Yes
Features - Market segment - Desktop
Features - Maximum number of PCI Express lanes - 20
Features - PCI Express configurations - 1x16+1x4
Features - PCI Express configurations - 1x16+1x4, 2x8+1x4
Features - PCI Express configurations - 2x8+1x4
Features - PCI Express slots version - 4.0
Features - PCI Express slots version - 5.0
Features - PCI Express slots version - 5.0, 4.0
Features - Scalability - 1S
Features - Supported instruction sets - AVX 2.0
Features - Supported instruction sets - SSE4.1
Features - Supported instruction sets - SSE4.1, SSE4.2, AVX 2.0
Features - Supported instruction sets - SSE4.2
Features - Thermal Monitoring Technologies - Yes
Features - Use conditions - PC/Client/Tablet
Frequency speed - 3200/5600 MHz
Full Description Line - Desktop|Core i7|i7-13700F|Raptor Lake|2100 MHz|Number of cores 16|Cache 30MB|Socket LGA1700|Wattage 65 Watts|Turbo frequency 5200 MHz|Packing type BOX
Gewicht - 0.46
Graphics - Discrete graphics card - No
Graphics - Discrete graphics card model - Not available
Graphics - On-board graphics card - No
Graphics - On-board graphics card model - Not available
Gross Weight Kg - 0,46
GRUPPE1 - Memory & Processors
GRUPPE2 - Processors / Math Corp
GTIN - 0735858528276
GTIN - 735858528276
GTIN - 5032037260237
guarantee - 36
guarantee_type - normal
HERSTELLER - INTEL
Hoehe - 0.08
HSTNUMMER - BX8071513700F
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/230117150022021068.jpg
Instruction Set - 64 bit
Integrated graphics - No
L2 Cache Size - 24 MB
L3 cache - 30 MB
Laenge - 0.12
Logistics data - Harmonized System (HS) code - 8542310001
LongDesc - Intel® Virtualization Technology for Directed I/O (VT-d)Intel® Virtualization Technology for Directed I/O (VT-d) continues from the existing support for IA-32 (VT-x) and Itanium® processor (VT-i) virtualization adding new support for I/O-device virtualization. Intel VT-d can help end users improve security and reliability of the systems and also improve performance of I/O devices in virtualized environments.Intel® Virtualization Technology (VT-x)Intel® Virtualization Technology (VT-x) allows one hardware platform to function as multiple “virtual” platforms. It offers improved manageability by limiting downtime and maintaining productivity by isolating computing activities into separate partitions.Intel® 64Intel® 64 architecture delivers 64-bit computing on server, workstation, desktop and mobile platforms when combined with supporting software.¹ Intel 64 architecture improves performance by allowing systems to address more than 4 GB of both virtual and physical memory.CacheCPU Cache is an area of fast memory located on the processor. Intel® Smart Cache refers to the architecture that allows all cores to dynamically share access to the last level cache.Intel® AES New InstructionsIntel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.Idle StatesIdle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.Intel® Turbo Boost TechnologyIntel® Turbo Boost Technology dynamically increases the processor's frequency as needed by taking advantage of thermal and power headroom to give you a burst of speed when you need it, and increased energy efficiency when you don’t.Max Turbo FrequencyMax Turbo Frequency is the maximum single-core frequency at which the processor is capable of operating using Intel® Turbo Boost Technology and, if present, Intel® Turbo Boost Max Technology 3.0 and Intel® Thermal Velocity Boost. Frequency is typically measured in gigahertz (GHz), or billion cycles per second.Execute Disable BitExecute Disable Bit is a hardware-based security feature that can reduce exposure to viruses and malicious-code attacks and prevent harmful software from executing and propagating on the server or network.Intel® Hyper-Threading TechnologyIntel® Hyper-Threading Technology (Intel® HT Technology) delivers two processing threads per physical core. Highly threaded applications can get more work done in parallel, completing tasks sooner.Instruction SetAn instruction set refers to the basic set of commands and instructions that a microprocessor understands and can carry out. The value shown represents which Intel’s instruction set this processor is compatible with.Intel® VT-x with Extended Page Tables (EPT)Intel® VT-x with Extended Page Tables (EPT), also known as Second Level Address Translation (SLAT), provides acceleration for memory intensive virtualized applications. Extended Page Tables in Intel® Virtualization Technology platforms reduces the memory and power overhead costs and increases battery life through hardware optimization of page table management.Enhanced Intel SpeedStep® TechnologyEnhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.Secure KeyIntel® Secure Key consists of a digital random number generator that creates truly random numbers to strengthen encryption algorithms.Intel® Speed Shift TechnologyIntel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.Intel® Deep Learning Boost (Intel® DL Boost) on CPUA new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.Instruction Set ExtensionsInstruction Set Extensions are additional instructions which can increase performance when the same operations are performed on multiple data objects. These can include SSE (Streaming SIMD Extensions) and AVX (Advanced Vector Extensions).Intel® Turbo Boost Max Technology 3.0 FrequencyIntel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom. Intel® Turbo Boost Max Technology 3.0 frequency is the clock frequency of the CPU when running in this mode.Intel® Turbo Boost Max Technology 3.0Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.Thermal Monitoring TechnologiesThermal Monitoring Technologies protect the processor package and the system from thermal failure through several thermal management features. An on-die Digital Thermal Sensor (DTS) detects the core's temperature, and the thermal management features reduce package power consumption and thereby temperature when required in order to remain within normal operating limits.Intel® Volume Management Device (VMD)Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.Intel® Gaussian & Neural AcceleratorIntel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.Mode-based Execute Control (MBEC)Mode-based Execute Control can more reliably verify and enforce the integrity of kernel level code.Intel® Boot GuardIntel® Device Protection Technology with Boot Guard helps protect the system’s pre-OS environment from viruses and malicious software attacks.Intel® Control-Flow Enforcement TechnologyCET - Intel Control-flow Enforcement Technology (CET) helps protect against the misuse of legitimate code snippets through return-oriented programming (ROP) control-flow hijacking attacks.
LongProductName - Intel® Core™ i7-13700F Processor (30M Cache, up to 5.20 GHz)
LongSummaryDescription - Intel Core i7-13700F. Processor family: Intel® Core™ i7, Processor socket: LGA 1700, Processor manufacturer: Intel. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 5.0, 4.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.2 GHz. Package type: Retail box
Manufacturer - INTEL
Manufacturer - Intel
Manufacturer Code - BX8071513700F
Manufacturer Name - Intel
Manufacturer_code - BX8071513700F
Maximum TDP - 219 W
Max Memory Size - 128GB
Max Number of DMI Lanes - 8
Max Number of PCI Express Lanes - 20
Memory - Maximum internal memory supported by processor - 192 GB
Memory - Memory bandwidth (max) - 89.6 GB/s
Memory - Memory channels - Dual-channel
Memory - Memory types supported by processor - DDR4-SDRAM
Memory - Memory types supported by processor - DDR4-SDRAM, DDR5-SDRAM
Memory - Memory types supported by processor - DDR5-SDRAM
Memory - Non-ECC - Yes
Memory Channels Supports - 2
Memory type - DDR4/DDR5
Memory Types - DDR4/DDR5
Model number - i7-13700F
MPN - BX8071513700F
Name - Intel Core i7-13700F
Name - Intel Core i7-13700F, Processor - boxed
name - Intel Core i7-13700F 2,10 GHz (Raptor Lake) Sockel 1700 - boxed
Name - Intel S1700 CORE i7 13700F BOX GEN13
name - Processor Core i7-13700F BOX 2,1GHz, LGA1700
Number of cores - 16
Number of threads - 24
Operational conditions - Tjunction - 100 °C
Other features - L2 cache - 24576 KB
Other features - Maximum internal memory - 192 GB
Other information -
Package Type - Box
Packaging data - Package type - Retail box
Packing type - BOX/BOX
Packs in Box - 1
Pack Weight Brutto (kg) - 0.52 kg
Performance-core Base Clock Rate - 2.1 GHz
Performance-cores Quantity - 8
Performance-core Turbo Clock Rate - 5.1 GHz
Pieces in pack - 1
Processor - Box - Yes
Processor - Bus type - DMI4
Processor - Cooler included - Yes
Processor - Efficient-core base frequency - 1.5 GHz
Processor - Efficient-core boost frequency - 4.1 GHz
Processor - Efficient cores - 8
Processor - Maximum number of DMI lanes - 8
Processor - Maximum turbo power - 219 W
Processor - Memory bandwidth supported by processor (max) - 89.6 GB/s
Processor - Performance-core base frequency - 2.1 GHz
Processor - Performance-core boost frequency - 5.1 GHz
Processor - Performance cores - 8
Processor - Processor ARK ID - 230491
Processor - Processor base power - 65 W
Processor - Processor boost frequency - 5.2 GHz
Processor - Processor cache - 30 MB
Processor - Processor cache type - Smart Cache
Processor - Processor codename - Raptor Lake
Processor - Processor cores - 16
Processor - Processor family - Intel® Core™ i7
Processor - Processor generation - 13th gen Intel® Core™ i7
Processor - Processor manufacturer - Intel
Processor - Processor model - i7-13700F
Processor - Processor operating modes - 64-bit
Processor - Processor socket - LGA 1700
Processor - Processor threads - 24
Processor family - Intel Core i7
Processor special features - Enhanced Intel SpeedStep Technology - Yes
Processor special features - Intel 64 - Yes
Processor special features - Intel Turbo Boost Max Technology 3.0 - Yes
Processor special features - Intel Virtualization Technology (VT-x) - Yes
Processor special features - Intel Virtualization Technology for Directed I/O (VT-d) - Yes
Processor special features - Intel VT-x with Extended Page Tables (EPT) - Yes
Processor special features - Intel® AES New Instructions (Intel® AES-NI) - Yes
Processor special features - Intel® Boot Guard - Yes
Processor special features - Intel® Control-flow Enforcement Technology (CET) - Yes
Processor special features - Intel® Deep Learning Boost (Intel® DL Boost) - Yes
Processor special features - Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 - Yes
Processor special features - Intel® Hyper Threading Technology (Intel® HT Technology) - Yes
Processor special features - Intel® OS Guard - Yes
Processor special features - Intel® Secure Key - Yes
Processor special features - Intel® Speed Shift Technology - Yes
Processor special features - Intel® Standard Manageability (ISM) - Yes
Processor special features - Intel® Thread Director - Yes
Processor special features - Intel® Turbo Boost Max Technology 3.0 frequency - 5.2 GHz
Processor special features - Intel® Turbo Boost Technology - 2.0
Processor special features - Intel® Volume Management Device (VMD) - Yes
Processor special features - Mode-based Execute Control (MBE) - Yes
producer - Intel
Producer - Intel
producerCode - BX8071513700F
ProducerCode - BX8071513700F
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=230105124845188389&THEME=asbis&LANG=lv
ProductCategory - Procesori
ProductCode - BX8071513700FSRMBB
ProductDescription - Intel CPU Desktop Core i7-13700F (2.1GHz, 30MB, LGA1700) box
ProductName - i7-13700F
productName - Intel Core i7-13700F processor 30 MB Smart Cache Box
productSize - Normal
ProductType - CPU Desktop
Product Type - CPU Desktop
Shipping Box Depth Shipping/Package Box Dimensions - 12.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 8 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.465 kg
Shipping Box Width Shipping/Package Box Dimensions - 10.5 cm
Short description - CPU Intel Core i7-13700F / LGA1700 / Box ### 16 Cores / 24 Threads / 30M Cache / without GPU
ShortDescription - Intel Core i7 | Socket 1700 | 2,1-5,20Ghz | Raptor Lake | brak rdzenia graficznego
ShortSummaryDescription - Intel Core i7-13700F, Intel® Core™ i7, LGA 1700, Intel, i7-13700F, 64-bit, 13th gen Intel® Core™ i7
sizeX - 122
sizeY - 106
sizeZ - 80
Socket - 1700
Socket - LGA1700
Stck_Kart - 0
Stck_Pal - 0
Storno - Y
Supported Memory Speed - 3200MHz(PC4-25600)/5600MHz(PC5-44800)
TDP - 65 W
Technical details - Launch date - Q1'23
Technical details - Status - Launched
Technical details - Target market - Gaming, Content Creation
Threads Quantity - 24
Title - Intel Core i7-13700F processor 30 MB Smart Cache Box
Turbo Clock Rate - 5.20 GHz
Turbo frequency - 5200 MHz
Unit Box Height - 0.08
Unit Box Length - 0.125
Unit Box Width - 0.105
Unit Brutto Volume - 0.00105 cubm
Unit Gross Weight - 0.465/0.465 kg
Unit Net Weight - 0.03 kg
URL - https://www.intel.com/
Vendor - INTEL
Vendor Homepage - ark.intel.com/content/www/us/en/ark/products/230491/intel-core-i713700f-processor-30m-cache-up-to-5-20-ghz.html
vendpn - BX8071513700F
Version - Box
Warranty - 36 months
WarrantyInfo -
warrantyLength - 36
Warranty Products Returnable - Yes
Warranty Term (month) - 36 mēneši
warrantyType - G
Warranty validation Criteria - Serial Number
Wattage - 65 Watts
Weight - 0,46
Weight - 0.46
weight - 460
Weight & dimensions - Processor package size - 45 x 37.5 mm
