Newstar Menu Board Wall Mount (vertical), 40-52"

Angle of rotation Ergonomics - 6°
Brand - Neomounts
BrandPartCode - NS-WMB200PBLACK
Cable management Ergonomics - Yes
Category - Signage Display Mounts
Category Code - SDM
Country of origin Other features - China
Description - NEWSTAR FLAT SCREEN WALL MOUNT FOR MENU BOARD - 2 SCREENS - PORTRAIT 40-50" BLACK
Description - The Neomounts menu board wall mount (vertical mounting), model NS-WMB200PBLACK is a tiltable wall mount for two flat screens up to 52" (132 cm). This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Neomounts tilt (0°/-5°/-10°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. Depth of this mount is 7,8 centimetres. Neomounts NS-WMB200PBLACK is suitable for 2 screens up to 52" (132 cm). The weight capacity of this product is 50 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 200x200 to 400x600 mm (vertical mounting). All installation material is included with the product.
Design - Housing material - Steel
Design - Product colour - Black
Distance to the wall (max) Ergonomics - 7.8 cm
Distance to the wall (min) Ergonomics - 7.8 cm
Ergonomics - Angle of rotation - 6°
Ergonomics - Cable management - Yes
Ergonomics - Distance to the wall (max) - 7.8 cm
Ergonomics - Distance to the wall (min) - 7.8 cm
Ergonomics - Height adjustment - 68 cm
Ergonomics - Height adjustment range - 0 - 680 mm
Ergonomics - Swivel angle - 6°
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle - 10°
Ergonomics - Tilt angle range - 0 - 10°
Ergonomics - Width adjustment - 110 cm
GTIN - 8717371447366
Harmonized System (HS) code Logistics data - 7326909890
Height - 165.000000
Height adjustment - No
Height adjustment Ergonomics - 68 cm
Height adjustment range Ergonomics - 0 - 680 mm
Height Weight & dimensions - 68 mm
Housing material Design - Steel
Length - 255.000000
Logistics data - Harmonized System (HS) code - 7326909890
Logistics data - Master (outer) case gross weight - 10.5 kg
Logistics data - Master (outer) case height - 540 mm
Logistics data - Master (outer) case length - 165 mm
Logistics data - Master (outer) case net weight - 10.5 kg
Logistics data - Master (outer) case width - 250 mm
Logistics data - Products per master (outer) case - 1 pc(s)
Logistics data - Products per pallet (EU) - 60 pc(s)
Logistics data - Quantity per master (outer) case - 1 pc(s)
LongDesc - The Neomounts menu board wall mount (vertical mounting), model NS-WMB200PBLACK is a tiltable wall mount for two flat screens up to 52" (132 cm). This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Neomounts tilt (0°/-5°/-10°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. Depth of this mount is 7,8 centimetres. Neomounts NS-WMB200PBLACK is suitable for 2 screens up to 52" (132 cm). The weight capacity of this product is 50 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 200x200 to 400x600 mm (vertical mounting).All installation material is included with the product.
LongProductName - Neomounts NS-WMB200PBLACK Menuboard wall mount 2 screens - 40-52" - max 50 kg/screen - VESA 200x200-400x600 - d 7,8 cm - tiltable - portrait - black
LongSummaryDescription - Neomounts NS-WMB200PBLACK Menuboard wall mount 40-52" - tiltable - portrait. Minimum screen size: 101.6 cm (40"), Maximum screen size: 132.1 cm (52"), Minimum VESA mount: 200 x 200 mm, Maximum VESA mount: 400 x 600 mm. Height adjustment range: 0 - 680 mm, Tilt angle range: 0 - 10°, Swivel angle: 6°. Product colour: Black
Manufacturer - Neomounts
ManufacturerPartNumber - NS-WMB200PBLACK
Master (outer) case gross weight Logistics data - 10.5 kg
Master (outer) case height Logistics data - 540 mm
Master (outer) case length Logistics data - 165 mm
Master (outer) case net weight Logistics data - 10.5 kg
Master (outer) case width Logistics data - 250 mm
Maximum screen size Mounting - 132.1 cm (52")
Maximum VESA mount Mounting - 400 x 600 mm
Maximum weight (capacity), kg - 50
Maximum weight capacity (per display) Mounting - 50 kg
Minimum screen size Mounting - 101.6 cm (40")
Minimum VESA mount Mounting - 200 x 200 mm
Motorized - No
Mounting - Maximum screen size - 132.1 cm (52")
Mounting - Maximum VESA mount - 400 x 600 mm
Mounting - Maximum weight capacity (per display) - 50 kg
Mounting - Minimum screen size - 101.6 cm (40")
Mounting - Minimum VESA mount - 200 x 200 mm
Mounting - Mounting type - Wall
Mounting - Number of displays supported - 2
Mounting - Panel mounting interface - 200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400,400 x 600,600 x 300,600 x 200,600 x 400
Mounting type Mounting - Wall
Number of displays supported Mounting - 2
Other features - Country of origin - China
Package depth Packaging data - 165 mm
Package height Packaging data - 540 mm
Package net weight Technical details - 10.5 kg
Package weight Packaging data - 10.5 kg
Package width Packaging data - 250 mm
Packaging data - Package depth - 165 mm
Packaging data - Package height - 540 mm
Packaging data - Package weight - 10.5 kg
Packaging data - Package width - 250 mm
Panel mounting interface Mounting - 200 x 200,200 x 300,200 x 400,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400,400 x 600,600 x 300,600 x 200,600 x 400
PeriodofWarranty - 5 Y
Product colour Design - Black
ProductName - Neomounts NS-WMB200PBLACK Menuboard wall mount 40-52" - tiltable - portrait
Products per master (outer) case Logistics data - 1 pc(s)
Products per pallet (EU) Logistics data - 60 pc(s)
Quantity per master (outer) case Logistics data - 1 pc(s)
Short summary - Neomounts NS-WMB200PBLACK Menuboard wall mount 2 screens - 40-52" - max 50 kg/screen - VESA 200x200-400x600 - d 7,8 cm - tiltable - portrait - black
ShortSummaryDescription - Neomounts NS-WMB200PBLACK Menuboard wall mount 40-52" - tiltable - portrait, 101.6 cm (40"), 132.1 cm (52"), 200 x 200 mm, 400 x 600 mm, 0 - 680 mm, 0 - 10°
Stand/mount type - Wall
Summary - Neomounts NS-WMB200PBLACK Menuboard wall mount 40-52" - tiltable - portrait. Minimum screen size: 101.6 cm (40"), Maximum screen size: 132.1 cm (52"), Minimum VESA mount: 200 x 200 mm, Maximum VESA mount: 400 x 600 mm. Height adjustment range: 0 - 680 mm, Tilt angle range: 0 - 10°, Swivel angle: 6°. Product colour: Black
Swivel angle Ergonomics - 6°
Technical details - Package net weight - 10.5 kg
Tilt - Yes
Tilt adjustment Ergonomics - Yes
Tilt angle Ergonomics - 10°
Tilt angle range Ergonomics - 0 - 10°
Title - Neomounts NS-WMB200PBLACK Menuboard wall mount 40-52" - tiltable - portrait
Turn - Yes
Unit Box Height - 0.25
Unit Box Length - 0.54
Unit Box Width - 0.17
Unit Calculated Volume - 0.02295 cubm
Unit Calculated Weight - 10.2 kg
Units per Shipping Box - 1
URL - https://www.neomounts.com/default.asp?pageid=44&artdetail=NS-WMB200PBLACK
Vendor Homepage - https://www.neomounts.com/default.asp?pageid=44&artdetail=NS-WMB200PBLACK
VESA-standard, mm - 200 x 200
VESA-standard, mm - 600 x 400
Warranty - 60 months
WarrantyInfo - 5 year
Weight - 10.380000
Weight & dimensions - Height - 68 mm
Weight & dimensions - Weight - 9.16 kg
Weight & dimensions - Width - 1100 mm
Weight & dimensions - Width adjustment range - 0 - 1100 mm
Weight Weight & dimensions - 9.16 kg
Wheels - No
Width - 545.000000
Width adjustment Ergonomics - 110 cm
Width adjustment range Weight & dimensions - 0 - 1100 mm
Width Weight & dimensions - 1100 mm
