10/100/1000M LAN Ports - 16
Accessories included -
brand - MikroTik
category - MikroTik > Ethernet rūteri > Cloud Core Router
Category 1 - Netzwerk
Category 2 - Router
Category Code - ROU
Code - CCR2004-16G-2S+
Color - White
Description - CCR2004-16G-2S+ This powerful and affordable router crushes all previous CCR models in single-core performance. 16x Gigabit Ethernet ports, 2x10G SFP+ cages, active cooling and the best single-core performance per watt & best overall performance per watt among all the CCR devices. Like the other models in CCR2004 series, this CCR also features the Annapurna Labs Alpine v2 CPU with 4x 64-bit ARMv8-A Cortex-A57 cores running at 1,7GHz. But here’s the difference. This powerful router crushes all previous CCR models in single-core performance, and that is the most important aspect when it comes to heavy operations based on per-connection processing. Like queues, for example.But that’s not all! It also has the best single-core performance per watt and best overall performance per watt among all the CCR devices. Better for the planet, better for the bills, it’s a win-win! The new router has 18 wired ports, including 16x Gigabit Ethernet ports and two 10G SFP+ cages. It also has a RJ-45 console port on the front panel. Like all CCR devices, it comes in a classic white 1U rackmount case. Built-in dual redundant power supplies are included, so you have one less thing to worry about. And, of course, there is active cooling to keep things nice and cool. Each group of 8 Gigabit Ethernet ports is connected to a separate Marvell Amethyst family switch-chip. Each switch chip has a 10 Gbps full-duplex line connected to the CPU. The same goes for each SFP+ cage - a separate 10 Gbps full-duplex line. Boards come with 4GB of DDR4 RAM and 128MB of NAND storage. Please note, due to parts shortage these routers don't have USB port. There is an "r2" added in the serial number - for example, serial number 123407ABCDEF/313/r2 would mean that this is the version without the USB.
Description - Podobnie jak inne modele z serii CCR2004, ten CCR jest również wyposażony w procesor Annapurna Labs Alpine v2 z 4 64-bitowymi rdzeniami ARMv8-A Cortex-A57 pracującymi z częstotliwością 1,7 GHz. Ale oto różnica. Ten potężny router wyprzedza wszystkie poprzednie modele CCR jeżeli chodzi o wydajność jednordzeniową, a to jest najważniejszy aspekt, jeśli chodzi o duże operacje oparte na przetwarzaniu na połączenie. Jak na przykład kolejki. Ale to nie wszystko! Ma również najlepszą wydajność pojedynczego rdzenia na wat i najlepszą ogólną wydajność na wat spośród wszystkich urządzeń CCR.
Nowy router ma 18 portów przewodowych, w tym 16 portów Gigabit Ethernet i dwie klatki 10G SFP+. Posiada również pełnowymiarowy port konsoli USB i RJ-45 na przednim panelu. Jak wszystkie urządzenia CCR, jest dostarczany w klasycznej białej obudowie rack 1U. Wbudowane podwójne nadmiarowe zasilacze są dołączone, więc masz o jedną rzecz mniej do zmartwienia. Posiada aktywne chłodzenie.
Każda grupa 8 portów Gigabit Ethernet jest podłączona do oddzielnego układu przełączników rodziny Marvell Amethyst. Każdy układ przełącznika ma pełnodupleksową linię 10 Gb/s podłączoną do procesora. To samo dotyczy każdej klatki SFP+ oddzielnej linii pełnodupleksowej 10 Gb/s. Płyty są dostarczane z 4 GB pamięci RAM DDR4 i 128 MB pamięci NAND.
Idealne rozwiązanie typu wszystko w jednym dla małych i średnich firm. Łatwy i wydajny. Z nowym CCR2004 możesz przenieść swoją sieć biurową na wyższy poziom.
dimensionalWeight - 1740
dimension depth - 60 mm
dimension height - 470 mm
Dimensions -
Dimensions - 443 x 210 x 44 mm
dimension weight - 2600 g
dimension width - 300 mm
EAN - 4752224007704
ean - 4752224007704
Flash memory capacity - 128MB
Full Description Line - CCR2004-16G-2S+|Network Device Type Router|16x10/100/1000M|2xSPF+|Memory (RAM) 4GB|Flash memory capacity 128MB|Power supply requirements 100-240 V|Power consumption 48 Watts|Operating temperature range -20°C to +60°C|Dimensions 443 x 210 x 44 mm
guarantee - 12
guarantee_type - normal
Hard drive > Storage capacity - 128 MB
height - 0.08 m
I/O ports - 1 x Serial port (RJ-45 )
I/O ports - 1 x USB 3.0 Type A
I/O ports - 2 x 10Gbit SFP/SFP+
I/O ports - 16 x 10/100/1000 Mbit/s
length - 0.48 m
Link - https://help.mikrotik.com/docs/pages/viewpage.action?pageId=48660518
Link - https://mikrotik.com/product/ccr2004_16g_2splus#fndtn-specifications
Management, monitoring, configuration -
Manufacturer - MikroTik
Memory (RAM) - 4GB
Model - CCR2004-16G-2S+
mpn - CCR2004-16G-2S+
MPN - CCR2004-16G-2S+
Name - Mikrotik CCR2004-16G-2S+
Name - Mikrotik Cloud Core Router CCR2004-16G-2S+, 2x10G SFP+ ports, 16x Gigabit LAN ports, 1x RJ45 Serial port, 4 core CPU, 4 GB RAM, Dual redundant power supply, CPU and PCB temperature monitor, RouterOS L6 MikroTik Cloud Core Router CCR2004-16G-2S+ No Wi-Fi 1
name - MikroTik Router xDSL 16 GbE SFP+ CCR2004-16G-2S
Network architecture - GigabitEthernet
Network Device Type - Router
Networking > CPU frequency - 1700 MHz
Operating temperature range - -20°C to +60°C
Operational conditions > Operating temperature (T-T) - -20°C to 60°C °C
Other features - Architektura: 64-bitowe ARM Procesor: AL32400 Liczba rdzeni procesora: 4 Częstotliwość nominalna procesora: 1700 MHz Licencja RouterOS: 6 System operacyjny: RouterOS (tylko v7) Rozmiar pamięci RAM: 4 GB Rozmiar pamięci: 128 MB Typ pamięci: NAND MTBF: około 200 000 godzin w 25C Testowana temperatura otoczenia: -20°C do 60°C Przyspieszenie sprzętowe IPsec: Tak
Other features > USB ports quantity - 1
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 420 mm
Package features > Gross height (mm) - 55 mm
Package features > Gross width (mm) - 210 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 178 pc(s)
Package features > Paper/Pasteboard - 360 g
Package features > Plastic (No PET) - 40 g
Package features > Tare weight (kg) - 0.4 kg
Package features > Volume (m3) - 0.004851 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
PDF - https://www.blobs.lt/products/3/3/4/2/4/3/0eae3a9cf765dc49344b2a9f55f202d5/original.pdf
Ports & interfaces > SFP+ ports quantity - 2
Power > Power consumption (max) - 48 W
Power consumption - 48 Watts
Power supply - Liczba wejść AC: 2 Zakres wejścia AC: 100-240 Częstotliwość (Hz): 50/60 Maksymalny pobór mocy: 48 W Maksymalny pobór mocy bez załączników: 35 W Liczba wentylatorów: 2
Power supply requirements - 100-240 V
Processor > Processor model - AL32400
producer - Mikrotik
producerCode - CCR2004-16G-2S+
Producer product family - Cloud Core Router
Producer product name - CCR2004-16G-2S+
Product model code - CCR2004-16G-2S+
productName - Mikrotik CCR2004-16G-2S+ wired router 16 Gigabit Ethernet White
productSize - Normal
Security -
Shipping Box Depth Shipping/Package Box Dimensions - 47 cm
Shipping Box Height Shipping/Package Box Dimensions - 5.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 2.63 kg
Shipping Box Width Shipping/Package Box Dimensions - 29 cm
sizeX - 60
sizeY - 306
sizeZ - 474
Software -
Special functions -
SPF+ LAN Ports - 2
System Requirements -
Technical details > Gross weight - 3.3 kg
Technical details > Net weight - 2.90 kg
Technical details > Other features - Like the other models in CCR2004 series, this CCR also features the Annapurna Labs Alpine v2 CPU with 4x 64-bit ARMv8-A Cortex-A57 cores running at 1,7GHz. But here’s the difference. This powerful router crushes all previous CCR models in single-core performance, and that is the most important aspect when it comes to heavy operations based on per-connection processing. Like queues, for example.But that’s not all! It also has the best single-core performance per watt and best overall performance per watt among all the CCR devices. Better for the planet, better for the bills, it’s a win-win! The new router has 18 wired ports, including 16x Gigabit Ethernet ports and two 10G SFP+ cages. It also has a full-size USB and RJ-45 console port on the front panel. Like all CCR devices, it comes in a classic white 1U rackmount case. Built-in dual redundant power supplies are included, so you have one less thing to worry about. And, of course, there is active cooling to keep things nice and cool. Each group of 8 Gigabit Ethernet ports is connected to a separate Marvell Amethyst family switch-chip. Each switch chip has a 10 Gbps full-duplex line connected to the CPU. The same goes for each SFP+ cage - a separate 10 Gbps full-duplex line. Boards come with 4GB of DDR4 RAM and 128MB of NAND storage. So as you can see - no bottlenecks. As long as the CPU can handle the processing, all ports can reach wire speed. And this CPU is a beast that can handle a lot. If we look at the performance, you can see that it is trading blows with our CCR1009. Even surpassing it in CPU-heavy configurations! And if that wasn’t enough – it can even reach the performance of CCR1016. The best part? This brand new CCR is among the most affordable options out there - not only within the CCR series, but on the market in general.One of the most common ways to use this device would be: Gigabit Ethernet ports for the internal network; SFP+ ports for downlink and uplink. The perfect all-in-one solution for small and medium-sized businesses. Easy and efficient. With the new CCR2004, you can take your office network to the next level. Without breaking the bank.
Technical details > Software type - RouterOS 6 (v7 only)
Technical details > Warranty - 12 month(s)
title - MikroTik CCR2004-16G-2S+
Type - xDSL
Unit Box Height - 0.055
Unit Box Length - 0.47
Unit Box Width - 0.29
Unit Brutto Volume - 0.007496 cubm
Unit Gross Weight - 2.63 kg
Unit Net Weight - 2 kg
Vendor Homepage - mikrotik.com/product/ccr2004_16g_2s_
vendpn - CCR2004-16G-2S+
Warranty - 12
Warranty - 12 months
warrantyLength - 24
warrantyType - G
weight - 2.9 kg
Weight - 2.65
weight - 2632
width - 0.3 m
Wireless LAN features > Wi-Fi band - No Wi-Fi
