10/100/1000/2500 Mbps ports - 1
Accessories included -
Application - Home and small office
brand - Ubiquiti
category - Ubiquiti > UniFi Cloud Gateways > Lielas tīkla ierīces
Category 1 - Netzwerk
Category 2 - Router
Category Code - WCO
Category_1 - Network and Servers
Category_2 - Network - Network Accessories
Certificates - CE FCC IC
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - Federal Communications Commission (FCC)
Certificates - Compliance certificates - Industry Canada (IC)
Certificates - Compliance certificates - National Defense Authorization Act (NDAA)
Chassis type - Rack
Description - Dream Machine Pro Max
Dream Machine Pro Max (UDM-Pro-Max) to zaawansowana brama chmurowa o przepustowości 10 Gb/s, zdolna obsłużyć ponad 200 urządzeń UniFi i ponad 2000 klientów. Posiada routing IPS o szybkości 5 Gb/s oraz nadmiarową pamięć masową NVR. Zwiększona moc obliczeniowa i pamięć zapewnia dwukrotnie większą wydajność niż standardowe urządzenia UniFi. Zawiera pełny pakiet aplikacji UniFi do zarządzania urządzeniami. Wyposażona w porty 10G SFP+ i porty LAN GbE RJ45, a także porty 2,5 GbE RJ45 WAN. Posiada dwa miejsca na dyski twarde 3,5" NVR z ochroną danych RAID oraz wbudowany dysk SSD 128 GB do nagrań z detekcji NVR. Wyposażona w ekran dotykowy o przekątnej 1,3 cala. Zwiększona moc obliczeniowa i pamięć wezględem UDM Pro/SE Zawiera pełny pakiet aplikacji UniFi do zarządzania urządzeniami Routing 5 Gb/s z IDS/IPS (1) 10G SFP+*, (8) portów GbE RJ45 LAN (1) 10G SFP+*, (1) 2,5 GbE RJ45 porty WAN (2) Wnęki na dyski twarde NVR 3,5" z ochroną danych RAID Wbudowany dysk SSD o pojemności 128 GB Ekran dotykowy 1,3"
Description - UBIQUITI Dream Machine Pro Max 10G Cloud Gateway with 200+ UniFi device / 2,000+ client support, 5 Gbps IPS routing, and redundant NVR storage. Enhanced computing power and memory for 2x the UniFi device and client capacity of Dream Machine Pro/SE Includes full UniFi application suite for device management 5 Gbps routing with IDS/IPS (1) 10G SFP+*, (8) GbE RJ45 LAN ports (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports (2) 3.5" NVR HDD bays with RAID data protection Built-in 128 GB SSD for NVR detection recordings
Design - Enclosure material - Aluminium/SGCC
Design - LED indicators - Activity
Design - LED indicators - Error
Design - LED indicators - Link
Design - LED indicators - Ready
Design - Mounting type - Rack mounting
Design - Product colour - Grey
Design - Rack capacity - 1U
Designation - CE+WEEE
dimensionalWeight - 5395
dimension depth - 520 mm
dimension height - 120 mm
Dimensions - 442.4 x 43.7 x 285.6 mm
Dimensions - 442.4 x 43.7 x 285.6 мм
dimension weight - 6000 g
dimension width - 410 mm
ean - 810084693254
EAN - 0810084693254
EAN_code - 0810084693254
Environment requirements - Temperatura pracy -10° do 40° C Wilgotność otoczenia podczas pracy 5 do 95%, bez kondensacji
Fan - No
Forwarding mode - Store-and-forward
Gross Weight Kg - 4,5
guarantee - 12
guarantee_type - normal
height - 0.148 m
L2 features -
L3 features -
length - 0.52 m
Management, monitoring, configuration - Ethernet Bluetooth
Management features - Multicast support - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Reset button - Yes
Manufacturer - Ubiquiti
Manufacturer Code - UDM-PRO-MAX
Manufacturer Name - Ubiquiti Networks
Manufacturer_code - UDM-Pro-Max
Model - UDM-Pro-Max
mpn - UDM-Pro-Max
MPN - UDM-PRO-MAX
name - Dream Machine Pro Max UDM-PRO-MAX
Name - Router UbiQuiti UniFi Dream Machine Pro Max - UDM-Pro-Max
Name - Ubiquiti Unifi Dream Machine Pro MAX, Gateway
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000 Mbit/s
Network - Ethernet LAN data rates - 2500 Mbit/s
Network - Port aggregation - Yes
Network architecture - GigabitEthernet
Number of 10/100/1000 Mbps ports - 8
Number of SFP+ ports - 8
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -10 - 40 °C
Other features -
Other functions -
Packaging content - Cables included - AC
Performance - Built-in processor - Yes
Performance - Control display unit - Yes
Performance - Display type - LCM
Performance - Flash memory - 32000 MB
Performance - Internal memory - 8000 MB
Performance - Number of processors installed - 1
Performance - Processor family - ARM Cortex
Performance - Processor frequency - 2000 MHz
Performance - Processor manufacturer - ARM
Performance - Processor model - Cortex-A57
Performance - SSD capacity - 128 GB
Ports & interfaces - Ethernet LAN (RJ-45) ports - 9
Ports & interfaces - SFP+ ports quantity - 2
Ports & interfaces - WAN connection - Ethernet (RJ-45), SFP+
Power - DC input voltage - 12 V
Power - Electromagnetic (EMP) protection - Yes
Power - Electromagnetic (EMP) protection (air) - 15 kV
Power - Electromagnetic (EMP) protection (contact) - 8 kV
Power - Electrostatic Discharge (ESD) protection (air) - 15 kV
Power - Electrostatic Discharge (ESD) protection (contact) - 8 kV
Power - Heat dissipation - 205 BTU/h
Power - Input current - 2 A
Power - Input frequency - 50/60 Hz
Power - Input voltage - 100 - 240 V
Power - Power consumption (max) - 60 W
Power - Power over Ethernet (PoE) - No
Power consumption - 100 W
Power supply - Universal AC input, 100240V AC, 2A Max., 50/60 Hz USP-RPS DC input, 11.5V DC, 8.7A
Power supply - Internal
producer - UBIQUITI
producerCode - UDM-Pro-Max
productName - Ubiquiti Dream Machine Pro Max gateway/controller 10, 100, 1000, 2500 Mbit/s
Product Net Weight - 4.7 kg
productSize - Normal
Protocols - DHCP server - Yes
Protocols - Routing protocols - BGP
Protocols - Routing protocols - OSPF
QoS -
Safety warning - Warnings - Do not open the appliance - risk of electric shock.
Safety warning - Warnings - Do not use in damp conditions.
Safety warning - Warnings - Make sure the unit is stably mounted and ventilated.
Security -
Security - Firewall security - Yes
Security - VLAN support - Yes
Short description - Ubiquiti UniFi Dream Machine Pro Max UDM-PRO-MAX (Sec. Gateway/Netw. Appliance) 3.5" HDD Bay for NVR Storage / Dual WAN Ports for
sizeX - 520
sizeY - 125
sizeZ - 415
Supported protocols and standards -
Switch class - Managed
Throughput - 5 GB/s
title - Ubiquiti UniFi Dream Machine Pro Max
Unit Box Height - 0.41
Unit Box Length - 0.52
Unit Box Width - 0.13
Unit Calculated Volume - 0.02973 cubm
Unit Calculated Weight - 6.45 kg
Units per Pallet - 0
Units per Shipping Box - 2
Vendor Homepage - eu.store.ui.com/eu/en/products/udm-pro-max
vendpn - UDM-PRO-MAX
VLAN -
Warranty - 12 months
warrantyLength - 24
warrantyType - G
Weight - 4.7 kg
Weight - 5,90
Weight - 5.96
weight - 6.6 kg
weight - 5970
Weight & dimensions - Depth - 285.6 mm
Weight & dimensions - Height - 43.7 mm
Weight & dimensions - Weight - 4.7 kg
Weight & dimensions - Width - 442.4 mm
width - 0.41 m
