TP-LINK Router TP-Link Archer BE550

3G/4G USB modem compatibility WAN connection - No
AC adapter included Packaging content - Yes
Accessories included - Wi-Fi 7 Archer BE550 Router Power Supply RJ45 Ethernet Cable Quick Installation Guide
Antenna - Built-in
Antenna - Antenna design - Internal
Antenna design Antenna - Internal
Automatic channel selection Network - Yes
Brand - TP-Link
BrandPartCode - ARCHER BE550
Built-in FTP server Network - Yes
Cables included Packaging content - LAN (RJ-45)
Category - Wireless Routers
Category Code - WRO
Certificates - CE FCC RoHS
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC), RoHS
Certificates - Compliance certificates - Federal Communications Commission (FCC)
Certificates - Compliance certificates - RoHS
Color - Black
Color - Gray
Compliance certificates Certificates - CE, Federal Communications Commission (FCC), RoHS
Data Act - Link
DC-in jack Ports & interfaces - Yes
Depth Weight & dimensions - 231.7 mm
Description - Archer BE550 BE9300 Tri-Band Wi-Fi 7 Router Redefining Wi-Fi routers: Featuring powerful Wi-Fi 7 performance, lightning-fast wired connections, and a brand new design. Blazingly fast 9.2Gbps Tri-Band Wi-Fi 7: Keeps your devices running at full speed. Enjoy smooth 4K/8K streaming, immersive AR/VR gaming, and blazing-fast downloads. Multi-Link Support (MLO): Increases throughput, reduces latency, and improves reliability for new applications. Full 2.5G Ports: One 2.5Gbps WAN port and four 2.5Gbps LAN ports break the 1G bottleneck to ensure maximum device performance. Maximum Coverage: Proprietary Wi-Fi optimization and optimally positioned antennas with Beamforming provide greater capacity, stronger, more reliable connections, and less interference. EasyMesh Compatible: Works with EasyMesh routers and range extenders to create a seamless mesh Wi-Fi network throughout your home, preventing drops and delays as signals switch. TP-Link HomeShield: Enhanced security protects against the latest cyber threats.
Description - Redefining Wi-Fi
Routers
BE9300 Tri-Band Wi-Fi 7 Router - Tri-Band WiFi 7 Speeds up to 9214 Mbps - Five 2.5G Ports - Enhanced Security with HomeShield - Powerful CPURedefining WiFi Routers: With powerful WiFi 7 performance, lightning-fast wired connections, and brand-new designBlazing-Fast 9214 Mbps Tri-Band WiFi 7: Enables your devices to run at full speed. Enjoy fluent 4K/8K streaming, immersive AR/VR gaming, and blazing-fast downloadsMulti-Link Operation (MLO): Increases throughput, reduces latency, and improves reliability for emerging applicationsFull 2.5G Ports: One 2.5 Gbps WAN port and four 2.5 Gbps LAN ports break through the 1G bottleneck, driving your devices to peak performanceMaximized Coverage: Proprietary WiFi optimization and optimally positioned antennas along with Beamforming deliver more capacity, stronger and more reliable connections, and less interferenceEasyMesh-Compatible: Works with EasyMesh routers and range extenders to form seamless whole home Mesh WiFi, preventing drops and lag when moving between signalsTP-Link HomeShield: Enhanced security defends against the latest cyber threats
Design - LED indicators - LAN, WAN
Design - Product colour - Black
Design - Product type - Tabletop router
Designation - CE+WEEE
DHCP client Protocols - Yes
dimensionalWeight - 1944
dimensionalWeight - 1989
dimension depth - 150 mm
dimension height - 280 mm
Dimensions - 76 x 231.7 x 203 mm
dimension weight - 2142 g
dimension width - 270 mm
DSL WAN WAN connection - No
Dynamic DNS (DDNS) Network - Yes
ean - 4895252500141
Environment requirements - Operating temperature: 0~40 Operating humidity: 10% ~ 90%, non-condensing
Ethernet LAN (RJ-45) ports Ports & interfaces - 5
Ethernet LAN data rates Network - 10,100,1000,2500 Mbit/s
Ethernet LAN interface type Network - 2.5 Gigabit Ethernet
Ethernet LAN Network - Yes
Ethernet WAN WAN connection - Yes
Features - Firmware upgradeable - Yes
GTIN - 0840030708367
GTIN - 840030708367
GTIN - 4895252500141
GTIN - 4895252503326
guarantee - 36
guarantee_type - normal
Height Weight & dimensions - 203 mm
I/O ports - 1 x 10/100/1000/2500 RJ-45 port (WAN)
I/O ports - 1 x USB 3.0
I/O ports - 4 x 10/100/1000/2500 RJ-45 port PoE
LED indicators Design - LAN, WAN
Logistics data - Country of origin - China
Logistics data - Customs product code (TARIC) - 8517620000
LongDesc - Exploring the New Era of Home WiFiBE9300 Tri-Band WiFi 7 RouterWiFi 7 — WiFi Like Never BeforeWiFi 7 offers accelerated throughput, lower latency, stronger anti-jamming, and higher efficiency. Join the league of pros and experience the sheer performance of the next generation of WiFi.Ultra-Fast 9328 Mbps 6-Stream Tri-Band WiFiEnjoy smooth 8K streaming, VR/AR, video conferencing, online gaming, and high-speed downloading.5× 2.5 Gbps Ports for Full Multi-Gigabit ConnectivityOne 2.5 Gbps WAN port maximizes home internet speeds with up to 2.5× the wired speed of a typical Gigabit Ethernet port. The additional four 2.5 Gbps LAN ports make Archer BE550 an ideal solution for future-proofing your home network.☆ Let’s begin the unprecedented smooth game!Flexibly Create Whole Home Mesh WiFiArcher BE550 is EasyMesh-compatible. If you have any dead zones at home, just add another EasyMesh router/range extender to further form your whole home multi-gigabit mesh WiFi. No more searching for a stable connection.Easy Setup and UseWhether you prefer the intuitive Tether app or TP-Link’s powerful web interface, you can set up your Archer BE550 in minutes. The Tether app allows you to manage network settings from any Android or iOS device.Protect Your ChildrenBlock inappropriate content for your children and customize a time range for better online habits.New Connection NotificationsYou will be notified by your phone when new devices connect. Kick off any suspicious connections and block them. It’s as simple as that.Easy Firmware UpgradesTired of upgrading firmware manually? OTA updates simplify firmware upgrades with a click in the management panel. To keep your security and functions always up to date, just turn on the auto schedule.VPN Clients and Server SupportedAllow devices in your home network to access remote VPN servers without needing to install VPN software on every device. Archer BE550 can run both the VPN and ordinary internet connections at the same time, delivering security and flexibility.Private IoT Network for More SecuritySet up a separate WiFi for IoT devices and overlay HomeShield and advanced WPA3 encryption to better protect the security of your home network and IoT devices.
LongProductName - 2.4 GHz (688 Mbps), 5 GHz (2880 Mbps), 6 GHz (5760 Mbps), 802.11 a/b/g/n/ac/ax/be, 1× 2.5 Gbps WAN, 4× 2.5 Gbps LAN, 76 × 231.7 × 203 m
LongSummaryDescription - TP-Link Archer BE9300 Tri-Band Wi-Fi 7 Router. WAN connection type: RJ-45. Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz), Top Wi-Fi standard: Wi-Fi 7 (802.11be), WLAN data transfer rate (max): 9300 Mbit/s. Ethernet LAN interface type: 2.5 Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000,2500 Mbit/s, VPN server: OpenVPN Server; PPTP VPN Server; L2TP VPN Server; WireGuard VPN Server. Security algorithms: WPA, WPA3, WPA2, WPA2-Enterprise, WPA-Enterprise, Firewall security: SPI Firewall. Product type: Tabletop router, Product colour: Black, LED indicators: LAN, WAN
Management, monitoring, configuration -
Management features - Bandwidth control - Yes
Management features - Cloud-managed - Yes
Management features - MIMO - Yes
Management features - MU-MIMO technology - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Reset button - Yes
Management features - Web-based management - Yes
MIMO Management features - Yes
Model - ARCHER BE550
Model name - ARCHER BE550
MU-MIMO technology Management features - Yes
name - Archer BE550 Router WiFi 7 BE9300
Name - WRL ROUTER 9300MBPS WI-FI 7/TRI-BAND ARCHER BE550 TP-LINK
Network - Automatic channel selection - Yes
Network - Built-in FTP server - Yes
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100,1000,2500 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000
Network - Ethernet LAN data rates - 2500 Mbit/s
Network - Ethernet LAN interface type - 2.5 Gigabit Ethernet
Network - Number of guest networks (2.4 GHz) - 1
Network - Number of guest networks (5 GHz) - 1
Network - Number of guest networks (6 GHz) - 1
Network - Port forwarding - Yes
Network - Port triggering - Yes
Network - Static route - Yes
Network - VPN server - OpenVPN Server; PPTP VPN Server; L2TP VPN Server; WireGuard VPN Server
Network architecture - GigabitEthernet
Number of antennas - 6
Number of guest networks (2.4 GHz) Network - 1
Number of guest networks (5 GHz) Network - 1
Number of guest networks (6 GHz) Network - 1
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operating frequency - 6 GHz
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features -
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 240 mm
Packaging data - Package height - 275 mm
Packaging data - Package weight - 2.11 kg
Packaging data - Package width - 145 mm
Parental control Security - Yes
Port forwarding Network - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - Ethernet LAN (RJ-45) ports - 5
Ports & interfaces - Number of Ethernet WAN ports - 1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB port - Yes
Port triggering Network - Yes
Power - Power source type - DC
Power source type Power - DC
Power supply -
producer - TP-LINK
producerCode - Archer BE550
Product colour Design - Black
ProductName - BE9300 Tri-Band Wi-Fi 7 Router
productName - TP-Link Archer BE9300 Tri-Band Wi-Fi 7 Router
Product Net Weight ELKO Verified Logistics Data - 1.11 kg
productSize - Normal
Product type Design - Tabletop router
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Protocols - Universal Plug and Play (UPnP) - Yes
Quick installation guide Packaging content - Yes
Reset button Management features - Yes
Safety warning - Warnings - Avoid contact with liquids as this may cause electric shock.
Safety warning - Warnings - Do not open the appliance housing - risk of electric shock.
Safety warning - Warnings - The product may emit radio waves that may interfere with other electronic devices.
Security - Network Security SPI Firewall Access Control IP and MAC Binding Application Layer Gateway HomeShield Security Real-time IoT Protection Malicious Site Blocking Intrusion Prevention System DDoS Prevention Home Network Scanner VPN Server OpenVPN Server PPTP VPN Server L2TP VPN Server VPN Client Open VPN Client PPTP VPN Client L2TP VPN Client WiFi Encryption WPA WPA2 WPA3 WPA/WPA2-Enterprise (802.1x)
Security - DMZ support - Yes
Security - Firewall - Yes
Security - Firewall security - SPI Firewall
Security - Guest access - Yes
Security - IGMP snooping - Yes
Security - Network address translation (NAT) - Yes
Security - Parental control - Yes
Security - Security algorithms - WPA
Security - Security algorithms - WPA, WPA3, WPA2, WPA2-Enterprise, WPA-Enterprise
Security - Security algorithms - WPA-Enterprise
Security - Security algorithms - WPA2
Security - Security algorithms - WPA2-Enterprise
Security - Security algorithms - WPA3
Shipping Box Depth ELKO Internal Logistics Data - 50 cm
Shipping Box Height ELKO Internal Logistics Data - 31.5 cm
Shipping Box Weight ELKO Internal Logistics Data - 9.15 kg
Shipping Box Width ELKO Internal Logistics Data - 29.5 cm
ShortSummaryDescription - TP-Link Archer BE9300 Tri-Band Wi-Fi 7 Router, Wi-Fi 7 (802.11be), Tri-band (2.4 GHz / 5 GHz / 6 GHz), Ethernet LAN, Black, Tabletop router
SIM card slot WAN connection - No
sizeX - 279
sizeX - 280
sizeY - 242
sizeY - 245
sizeZ - 144
sizeZ - 145
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11be
Standards - 802.11g
Standards - 802.11n
Standards - IPv4
Standards - IPv6
Summary - TP-Link Archer BE9300 Tri-Band Wi-Fi 7 Router. WAN connection type: RJ-45. Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz), Top Wi-Fi standard: Wi-Fi 7 (802.11be), WLAN data transfer rate (max): 9300 Mbit/s. Ethernet LAN interface type: 2.5 Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Product type: Tabletop router, Product colour: Black, LED indicators: LAN, WAN. Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
Sustainability - Sustainability certificates - CE
Sustainability - Sustainability certificates - Federal Communications Commission (FCC)
Sustainability - Sustainability certificates - RoHS
Sustainability - Sustainability compliance - Yes
Sustainability compliance Sustainability - Yes
System Requirements -
Technical details - Compliance certificates - CE
Technical details - Compliance certificates - Federal Communications Commission (FCC)
Technical details - Compliance certificates - RoHS
Title - TP-Link Archer BE9300 Tri-Band Wi-Fi 7 Router
Top Wi-Fi standard Wireless LAN features - Wi-Fi 7 (802.11be)
Type - xDSL
Unit Box Height - 0.24
Unit Box Length - 0.275
Unit Box Width - 0.145
Unit Calculated Volume ELKO Internal Logistics Data - 0.01162 cubm
Unit Calculated Weight ELKO Verified Logistics Data - 2.29 kg
Unit Depth ELKO Verified Logistics Data - 27.5 cm
Unit Height ELKO Verified Logistics Data - 24 cm
Units per Shipping Box ELKO Verified Logistics Data - 4
Unit Width ELKO Verified Logistics Data - 14.5 cm
Universal Plug and Play (UPnP) Protocols - Yes
URL - https://www.tp-link.com/uk/home-networking/wifi-router/archer-be550/
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity Ports & interfaces - 1
USB port Ports & interfaces - Yes
Vendor Homepage - https://www.tp-link.com/uk/home-networking/wifi-router/archer-be550/
vendpn - Archer BE550
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
WAN connection type WAN connection - RJ-45
Warranty - 36 months
WarrantyInfo -
warrantyLength - 36
warrantyType - G
weight - 2088
weight - 2120
Weight & dimensions - Depth - 203 mm
Weight & dimensions - Depth - 231.7 mm
Weight & dimensions - Height - 203 mm
Weight & dimensions - Height - 231.7 mm
Weight & dimensions - Weight - 1.16 kg
Weight & dimensions - Width - 76 mm
Wi-Fi band Wireless LAN features - Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards Wireless LAN features - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Width Weight & dimensions - 76 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 7 (802.11be)
Wireless LAN features - Wi-Fi band - Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi standards - Wi-Fi 6 (802.11ax)
Wireless LAN features - Wi-Fi standards - Wi-Fi 6E (802.11ax)
Wireless LAN features - Wi-Fi standards - Wi-Fi 7 (802.11be)
Wireless LAN features - WLAN data transfer rate (first band) - 574 Mbit/s
Wireless LAN features - WLAN data transfer rate (first band) - 688 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 9300 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 2880 Mbit/s
Wireless LAN features - WLAN data transfer rate (third band) - 5760 Mbit/s
WLAN data transfer rate (first band) Wireless LAN features - 574 Mbit/s
WLAN data transfer rate (max) Wireless LAN features - 9300 Mbit/s
WLAN data transfer rate (second band) Wireless LAN features - 2880 Mbit/s
WLAN data transfer rate (third band) Wireless LAN features - 5760 Mbit/s
