Accessories included - Power cable (3 m) USB cable (3 m) HDMI cable (3 m) Stylus pens (2 pcs.) Remote control Quick start guide USB flash drive with software and drivers WiFi/Bluetooth module
Aspect ratio - 16:9
Bluetooth - Yes
Brightness - 350 cd/m²
Color - Black
Depth - 97 mm
Description - Capture attention, inspire with precision, and deliver presentations at a completely innovative level with the Avtek TS 8.1 Mate G.
Android 14.0 offers fast components and a high-end operating system, making the monitor much more fluid and allowing you to install increasingly demanding applications.
The ability to write in two colors simultaneously deliver a colorful presentation and capture the attention of students or colleagues with the included dual-sided pens.
A multitude of available ports makes the monitor even more adaptable to any environment and connect to more devices.
The built-in WiFi/Bluetooth module allows for convenient, quick connection to available networks and instant Bluetooth activation for file transfers or wireless connection to devices like speakers or headphones.
Precise touch control Zero Bonding technology makes using the monitor even more natural. The minimal space between the display and the protective glass allows the electronic ink to appear directly beneath the pen, minimizing parallax. This improves the writing experience, making the most frequently used functions of the interactive monitornotetaking, writing, and drawingmore enjoyable and intuitive.
The built-in wireless image transfer application allows for simultaneous connection to up to eight computers or mobile devices and displaying up to four images. Wireless image, sound, and touch transfer allows for even more convenient collaboration and eliminates the need to connect each computer directly to the monitor.
Over-the-Air software updates ensure the monitor always receives the latest features and applications as they are released over time. Users can easily install updates themselves when they are available, ensuring they won't miss out on future changes.
TS 8 monitors are 4K/UHD-ready. An advanced panel with a 3840 x 2160 resolution and a 60Hz refresh rate is responsible for displaying the image. Thanks to the unique shared USB ports on the front of the monitor, once connected, a USB drive will be accessible both in Android and the built-in OPS computer, without the need to switch between ports.
The annotation tool allows you to annotate any image or use the monitor as an interactive whiteboard. This tool also allows you to use a stopwatch, timer, spotlight, and voting system.
The voting tool, accessible from a handy shortcut bar on any source, allows you to ask any question, collect answers, and quickly summarize them. This is true regardless of whether you're displaying a presentation, an Android browser, or an external source such as a laptop.
The monitor locking feature is a solution designed for school environments and is useful in crowded spaces. USB Disk Lock allows you to lock the monitor and unlock it only by inserting a key (USB drive) with the appropriate unlock file. Using the monitor locking app, you can secure it similarly to a phone with a code. Both solutions protect the device and its data from unauthorized use.
Avtek TouchScreen monitors include interactive Note software for Windows, which allows for both lesson preparation and business presentation management. Note supports the same file format as the Android whiteboard application, allowing you to start editing the same file on the monitor and then finish it in the Windows Note application.
In addition to Note software, the monitor comes with two additional programs: Connect and Capture. The former allows for communication between the mobile device and a PC, enabling, among other things, two-way image transfer and presentation control. This makes remote control of the monitor from a computer simple and intuitive.
Capture is a useful tool for recording and editing presentations and lectures. It allows you to record your Windows desktop and the image from a connected camera (or both simultaneously). Capture also offers quick editing of materials, which can be saved as a single video file, uploaded to the cloud, or published on services like YouTube.
Interactive monitors are ideal for scenarios with diverse requirements, which is why OPS computers are available in several variants. For education and basic use, the economical i3 is ideal. For more advanced applications, the i5 version is designed, and for the most professional applications, the extremely powerful Intel i7.
Avtek interactive monitors are designed for 24/7 operation. They ensure uninterrupted operation around the clock, offering exceptional durability and reliability.
NOTE: AVTEK TS 8.1 MATE G MONITORS ARE NOT INTENDED FOR LANDSCAPE OPERATION (INTERACTIVE TABLE MODE).
Designation - CE+WEEE
dimension depth - 2110 mm
dimension height - 1291 mm
dimension weight - 69500 g
dimension width - 225 mm
Display surface - Glare
ean - 5907731319751
guarantee - 60
guarantee_type - external
Height - 1160 mm
I/O connectors - 1 x Audio in
I/O connectors - 1 x Audio out
I/O connectors - 1 x DisplayPort
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x SPDIF out
I/O connectors - 2 x RJ-45 LAN
I/O connectors - 2 x USB (Type C)
I/O connectors - 2 x USB 2.0
I/O connectors - 3 x USB 3.0
I/O connectors - 4 x HDMI
Matrix type - IPS LCD
Model - MATE G 86
name - TOUCHSCREEN 8.1 MATE G 86 inches
Number of colors - 1,07 mld
Optional accessory - Mobile stand
Other features - System Version - Android 14 Google Certification - YES Panel - 86" IPS Aspect Ratio - 16:9 Panel Resolution - 4K/UHD (3840×2160) @60 Hz Viewing Angle - 178° Brightness - 350 cd/m Contrast Ratio - 5000:1 Display Colors - 1.07 billion Response Time - 6.5 ms RAM - 8GB ROM - 64GB Operating Time - 24/7 Panel Lifespan - 50,000 Hours Built-in Speakers - 50,000 Hours Warranty - 5 Years (including 2-year one-to-one warranty) Touch Technology - Infrared Touch Response Time - < 10 ms Input Method - Finger or any other object Touch Resolution - 32767 x 32767 Video Outputs - HDMI Video Inputs - DisplayPort, 3 x HDMI, VGA (from one of the inputs) Audio Inputs - 3.5 mm mini jack Communication Ports - 2 x USB 2.0, 3 x USB 3.0, 2 x USB Type-C Audio Output - 3.5 mm mini jack, SPDIF Monitor Dimensions - 1957 × 1160 × 97 mm Packaging Dimensions - 2110 × 1291 × 225 mm Weight - 53.55 kg Weight (with packaging) - 63.75 kg Included Accessories - Power Cord (3 m), Quick Start Guide, USB Cable, Stylus Pens (2 pcs), Remote Control, Wall Mount, WiFi/Bluetooth Adapter Optional Accessories - Mobile Stand
Power consumption - 245 W
producer - Avtek
Refresh rate - 60 Hz
Resolution - 3840 x 2160
Response time - 6.5 ms
Screen size (diag.) - 86''
Speakers built-in - Yes
Static contrast - 5 000:1
Touch screen - Yes
Transreflective technology - LED
TV tuner built-in - No
vendpn - 1TV352
VESA - 800 x 600
Viewing angle, horizontal - 178 °
Warranty - Warranty - 5 years (including 2 years one-to-one)
Web camera - None
Weight - 53.55 kg
Width - 1957 mm
WiFi - Yes
