ARTIKEL1 - HX-24G FHD 250 CD
ARTIKEL2 - VA PANEL HDMI DVI VGA
Brand - AG Neovo
BrandPartCode - HX4GB011E0100
Breite - 0.51
Category - Surveillance Monitors
Design - Mounting type - Freestanding/Wall-mounted
Design - Product colour - Black
Design - Product type - CCTV monitor
Design - Tilt adjustment - Yes
Design - Tilt angle range - 3 - 21°
Display - Anti-glare screen - Yes
Display - Contrast ratio (typical) - 20000000:1
Display - Digital horizontal frequency - 24 - 84 kHz
Display - Digital vertical frequency - 50 - 75 Hz
Display - Display brightness - 250 cd/m²
Display - Display diagonal - 60.5 cm (23.8")
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display surface reflectivity (typical) - 1%
Display - Display type - LED
Display - Glass thickness - 3 mm
Display - Haze rate - 40%
Display - NTSC coverage (typical) - 72%
Display - Panel type - VA
Display - Pixel pitch - 0.274 x 0.274 mm
Display - Response time - 5 ms
Display - RGB colour space - NTSC
Display - Surface hardness - 3H
Display - Transmission rate - 97
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 4710739595949
Gewicht - 11.2
GRUPPE1 - Displays
GRUPPE2 - Lcd Monitor
GTIN - 4710739595949
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0.25
HSTNUMMER - HX4GB011E0100
Laenge - 0.67
LongDesc - The HX-24G is a 24-inch SDI monitor to broadcast live video footage over a long distance in a surveillance environment. With SDI input and output looping functionality, the monitor allows to receive real-time 1080p images from HD-SDI or 3G-SDI cameras and transmit the uncompressed videos in the light of ultra-low latency and signal interruption to multiple SDI monitors. The HX-24G fulfils the need for high-quality image details to real-time video surveillance monitoring such as official authorities, law enforcement, banks, casinos, jewellery and luxury stores, police patrol cars, private properties.Support HD-SDI and 3G-SDI StandardsThe HX-24G 24-inch SDI monitor supports both HD-SDI and 3G-SDI standards at Full HD image quality. Users don’t need to sacrifice the video quality and image details when zooming in the cameras during live video and playback mode to focus on their specific area of interest.Uncompressed and Ultra-low Latency Transmission via Long DistanceThe HX-24G supports multiple SDI video standards, including SD, HD and 3G-SDI formats. These standards support ultra-low latency and uncompressed transmission of HDTV signals up to 300 meters for live video monitoring.The maximum distances for SD-SDI, HD-SDI and 3G-SDI signal transmission via RG6 cables:3G-SDI: 100M / RG6 Coaxial CablesHD-SDI: 150M / RG6 Coaxial CablesSD-SDI: 300M / RG6 Coaxial CablesEasy Connection with SDI Loop Out for Multiple Monitor SetupsWith HX-24G’s SDI loop-out port, CCTV installers can quickly connect the SDI A/V source to extra SDI monitors without the need for a converter. It’s an ideal solution for CCTV HD-SDI camera and broadcast monitoring.Super ResolutionTo improving the clarity of security footage in real-time, the HX-24G monitor’s super-resolution technology can upscale and enhance the images to present more detail in layered texture horizontally and vertically. It essentially makes an image with a higher resolution in a more natural way.CCTV ModeAG Neovo’s pre-configured CCTV mode can maximise image clarity in low-light footage. Quickly fine-tune your video footage with adjustments for sharpness, saturation, contrast, brightness, and more. Don’t waste time testing and re-adjusting constantly, this product already has it all figured out!Night ModeWhile applying to critical surveillance, such as sailing in the dark seas, users have higher image clarity requirements for the monitors in low-light environments. Night Mode features dimming the backlight level in dark environments and remaining the clear viewing with high visibility for reliable navigation.LCD Screen Burn In PreventionAG Neovo’s patented Anti-Burn-in™ technology tackles LCD burn-in effect, prevents a ghost image on the screen. It assures an extended lifespan for the monitors and secures the user’s investment.Robust Design for Video SurveillanceA professional video surveillance monitor is built for 24/7 use in challenging conditions. The HX-24G SDI monitor fits with NeoV Optical Glass screen and durable metal casing to prevent scratching and high-velocity impacts, also providing enhanced heat dissipation to ensure proper operation.PID Command & Ctrl for RS232 System IntegrationPID Command & Ctrl software helps integrators easily control and integrate this 24-Inch SDI monitor via RS232 connections. Users can quickly find command codes for programming into external control systems for remote management, OSD-related settings, and easy control on deployed displays on its simple and intuitive interface.
LongProductName - 23.6" VA, LED, 1920 x 1080px, 250 cd/m², 5 ms, NTSC 72%, BNC, DisplayPort, HDMI, DVI-D, VGA, RS-232, USB, 2 x 2W, 8.1 kg
LongSummaryDescription - AG Neovo HX-24G. Product type: CCTV monitor, Mounting type: Freestanding/Wall-mounted, Product colour: Black. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, Display type: LED. Speaker power: 2 W, Panel mounting interface: 75 x 75,100 x 100 mm, Cable lock slot type: Kensington. Power source type: DC, Power supply type: External, Power consumption (typical): 21 W. Weight: 7.3 kg, Height: 352.6 mm, Depth: 56.2 mm
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Packaging content - AC adapter included - Yes
Packaging content - Cables included - AC, Audio, VGA
Packaging content - Quick start guide - Yes
Packaging content - Warranty card - Yes
Performance - Built-in speaker(s) - Yes
Performance - Cable lock slot - Yes
Performance - Cable lock slot type - Kensington
Performance - Number of built-in speakers - 2
Performance - Panel mounting interface - 75 x 75,100 x 100 mm
Performance - Speaker power - 2 W
Performance - VESA mounting - Yes
Ports & interfaces - 3.5 mm (1/8-inch) in - Yes
Ports & interfaces - Audio RCA inputs - 1
Ports & interfaces - Composite video in - 1
Ports & interfaces - Composite video out - 1
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DVI-D ports quantity - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - SDI inputs - 1
Ports & interfaces - SDI outputs - 1
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC adapter output current - 2.75 A
Power - AC adapter output voltage - 12 V
Power - Energy consumption (SDR) per 1000 hours - 21 kWh
Power - Energy efficiency class (SDR) - F
Power - Energy efficiency scale - A to G
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 21 W
Power - Power source type - DC
Power - Power supply type - External
ProductName - HX-24G
ShortSummaryDescription - AG Neovo HX-24G, CCTV monitor, Freestanding/Wall-mounted, Black, 3 - 21°, 60.5 cm (23.8"), 1920 x 1080 pixels
Stck_Kart - 1
Stck_Pal - 10
Storno - Y
Technical details - Sustainability certificates - CE, Low Voltage Directive (LVD), REACH, RoHS
Technical details - Sustainability compliance - Yes
Title - AG Neovo HX-24G CCTV monitor 60.5 cm (23.8") 1920 x 1080 pixels
URL - https://www.agneovo.com/uk/monitors/security-surveillance/hx-series/hx-24g
WarrantyInfo -
Weight & dimensions - Depth - 56.2 mm
Weight & dimensions - Depth (with stand) - 196 mm
Weight & dimensions - Height - 352.6 mm
Weight & dimensions - Height (with stand) - 392.8 mm
Weight & dimensions - Package depth - 249 mm
Weight & dimensions - Package height - 517 mm
Weight & dimensions - Package weight - 11.2 kg
Weight & dimensions - Package width - 672 mm
Weight & dimensions - Weight - 7.3 kg
Weight & dimensions - Weight (with stand) - 8.1 kg
Weight & dimensions - Width - 562.4 mm
Weight & dimensions - Width (with stand) - 562.4 mm
