Brand - Dahua Technology
BrandPartCode - DHI-LM24-A200Y
Category - Computer Monitors
Category Code - LC3
Data Sheet (Link) Energy Efficiency - https://eprel.ec.europa.eu/api/product/2139338/fiches?language=EN
Depth (without stand) Weight & dimensions - 41.3 mm
Description - LM24-A200YDahua 23.8 inch FHD Monitor
> Ultra-narrow bezel , elegant appearance, plastic base; > 178°H/178°V extra-wide viewing angle for overall viewing performance; > High fidelity digital processing for a brilliant and vivid video; > Support multiple signal inputs such as HDMI, VGA; > 100Hz high refresh rate, eliminates picture lagging;
Design - Feet colour - Black
Design - Frameless design - Yes
Design - Illuminated stand - No
Design - Market positioning - Office
Design - Product colour - Black
Display - Backlight type - Edge LED
Display - Colour depth - 8 bit
Display - Colour gamut standard - NTSC
Display - Contrast ratio (typical) - 3000:1
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 60.5 cm (23.8")
Display - Display diagonal (metric) - 61 cm
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - Full HD
Display - LED backlight - Yes
Display - Maximum refresh rate - 100 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 72%
Display - Panel type - VA
Display - Pixel density - 92.55 ppi
Display - Pixel pitch - 0.2745 x 0.2745 mm
Display - Response time - 10 ms
Display - Screen shape - Flat
Display - Supported graphics resolutions - 1920 x 1080 (HD 1080)
Display - Supported video modes - 1080p
Display - Touchscreen - No
Display - Viewable size, horizontal - 52.7 cm
Display - Viewable size, vertical - 29.6 cm
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display diagonal Display - 23.8 "
Display resolution Display - 1920 x 1080 pixels
Display technology Display - LCD
Energy consumption (SDR) per 1000 hours Power - 17 kWh
Energy efficiency class Energy Efficiency - E
EPREL Registration Number Energy Efficiency - 2139338
EPREL Version Number Energy Efficiency - 1
Ergonomics - Height adjustment - No
Ergonomics - Panel mounting interface - 75 x 75 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 15°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
HDMI Ports & interfaces - Yes
HDMI ports quantity Ports & interfaces - 1
HD type Display - Full HD
Height (without stand) Weight & dimensions - 320.4 mm
LongDesc -
LongProductName - 23.8", 1920 x 1080 FHD, VA, ELED, 16:9, 100 Hz, 250 cd/m², 3000:1, 8 bit, 10 ms, 72%NTCS, Black
LongSummaryDescription - Dahua Technology LM24-A200Y. Display diagonal: 60.5 cm (23.8"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 10 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Maximum refresh rate Display - 100 Hz
Model - DHI-LM24-A200Y
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Native aspect ratio Display - 16:9
Network - Bluetooth - No
Network - Wi-Fi - No
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Automatic brightness control - No
Other features - Compliance certificates - CE, Electromagnetic Compatibility (EMC)
Other features - E-manual - Yes
Packaging content - Cables included - HDMI
Packaging content - Power adapter included - Yes
Packaging content - Stand included - Yes
Packaging data - Package depth - 101 mm
Packaging data - Package height - 405 mm
Packaging data - Package weight - 3.75 kg
Packaging data - Package width - 612 mm
Panel mounting interface Ergonomics - 75 x 75 mm
Panel type Display - VA
Performance - AMD FreeSync - No
Performance - NVIDIA G-SYNC - No
Pixel pitch Display - 0.2745mm mm
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - Headphone out - No
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC adapter output voltage - 12 V
Power - Energy consumption (SDR) per 1000 hours - 17 kWh
Power - Energy efficiency class (HDR) - Not available
Power - Energy efficiency class (SDR) - E
Power - Energy efficiency scale - A to G
Power - External power adapter - Yes
Power - Input current - 2.5 A
Power - Power consumption (max) - 16 W
Power - Power consumption (off) - 0.1 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 16 W
Power consumption (standby) Power - 0.1 W
Power consumption (typical) Power - 30 W
ProductName - LM24-A200Y
Product Net Weight - 2.79 kg
Response time Display - 10 ms
ShortSummaryDescription - Dahua Technology LM24-A200Y, 60.5 cm (23.8"), 1920 x 1080 pixels, Full HD, LED, 10 ms, Black
Title - Dahua Technology LM24-A200Y computer monitor 60.5 cm (23.8") 1920 x 1080 pixels Full HD LED Black
Unit Box Height - 0.4
Unit Box Length - 0.61
Unit Box Width - 0.1
Unit Calculated Volume - 0.0244 cubm
Unit Calculated Weight - 3.75 kg
Units per Pallet - 0
URL - https://www.dahuasecurity.com/mena/products/All-Products/Display--Control/Monitors/Commercial-Series/LM24-A200Y=V1
Vendor Homepage - www.dahuasecurity.com/mena/products/All-Products/Display--Control/Monitors/Commercial-Series/LM24-A200Y=V1
VESA mounting Ergonomics - Yes
VGA (D-Sub) ports quantity Ports & interfaces - 1
Viewing angle, horizontal Display - 178 °
Viewing angle, vertical Display - 178 °
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 41.3 mm
Weight & dimensions - Height (without stand) - 320.4 mm
Weight & dimensions - Weight (with stand) - 2.79 kg
Weight & dimensions - Width (without stand) - 539.2 mm
Weight (without stand) Weight & dimensions - 2790 g
Width (without stand) Weight & dimensions - 539.2 mm
