Fractal Design Define 7 Mini, Black, Solid

category - Cases All Cases
Category - Root/Electronics/PC parts/Computer casings
Category_1 - Computer Cases and Cooling
Category_2 - Computer Cases
Chassis type - Mini Tower
code - FD-C-DEF7M-01
Code - FD-C-DEF7M-01
Color - Black
Cooling - Bottom fans diameters supported - 120
Cooling - Cooling - Yes
Cooling - Front fans diameters supported - 120
Cooling - Front fans diameters supported - 140 mm
Cooling - Front fans installed - 1x 140 mm
Cooling - Front radiator sizes supported - 120
Cooling - Front radiator sizes supported - 140
Cooling - Front radiator sizes supported - 240
Cooling - Front radiator sizes supported - 280
Cooling - Number of front fans supported (max) - 5
Cooling - Number of rear fans supported (max) - 1
Cooling - Number of top fans supported (max) - 2
Cooling - Rear fans diameters supported - 120 mm
Cooling - Rear fans installed - 1x 120 mm
Cooling - Rear radiator sizes supported - 120 mm
Cooling - Top fans diameters supported - 120
Cooling - Top fans diameters supported - 140 mm
Cooling - Top radiator sizes supported - 120
Cooling - Top radiator sizes supported - 240
Cooling > Front radiator sizes supported - 3x 120/ 2x 140 mm (1x Dynamic X2 GP-14 included) mm
Cooling > Rear fans diameters supported - 1x 120 mm (1x Dynamic X2 GP-12 included) mm
Cooling > Top radiator sizes supported - 120/240 mm (max 37 mm RAM with 121 mm wide radiator) mm
Description - Define 7 Mini oferuje ten sam stylowy wygląd i wiele poprawiających życie funkcji swojego starszego rodzeństwa, w opływowej formie. Kompaktowe, ale przestronne wnętrze pomieści płyty główne mATX i Mini ITX Miejsce na GPU do 331 mm z radiatorem 240 mm na górze lub 306 mm z wentylatorami o grubości 25 mm z przodu Obsługa 2 dysków 2,5 cala/3,5 cala i maksymalnie 4 dysków 2,5 cala (2 wsporniki 2,5 cala w zestawie)
Design - Anti-dust filter - Yes
Design - Cable management - Yes
Design - Form factor - Mini Tower
Design - LED indicators - Yes
Design - Material - Steel
Design - Maximum CPU cooler height - 16.7 cm
Design - Maximum graphics card length - 33.1 cm
Design - Maximum PSU length - 20 cm
Design - Number of 2.5" bays - 4
Design - Number of 3.5" bays - 2
Design - Number of expansion slots - 4
Design - Product colour - Black
Design - Reset button - Yes
Design - Side window - Yes
Design - Suitable for - Gaming
Design - Supported motherboard form factors - Mini-ATX
Design - Supported motherboard form factors - Mini-DTX
Design - Supported motherboard form factors - Mini-ITX
Design - Type - PC
Design > Anti-dust filter - Top, Front, Bottom and PSU
Design > Colour of product - Black Solid
Design > Form factor - mATX, Mini-DTX, Mini ITX
Design > Maximum CPU cooler height - 16.7 cm
Design > Maximum PSU length - 16.5 cm
Design > Side window - No
dimensionalWeight - 12238
dimension depth - 470 mm
dimension height - 480 mm
Dimensions - 399 x 205 x 406 mm
dimension weight - 9500 g
dimension width - 290 mm
Drive bays 2.5'' intern. - 2
Drive bays 3.5'' intern. - 2
Drive bays 5.25'' extern. - 0
EAN - 7340172702818
ean - 7340172702818
Eans - 7340172702818
EAN_code - 7340172702818
Fan - 12 cm
Fan - 14 cm
Features > Compatibility - Motherboard compatibility mATX / Mini-DTX / Mini ITX
Form-factor - Micro ATX
Form-factor - Mini ITX
Front panel connectors - 1 x headphones
Front panel connectors - 1 x USB 3.1 Typ C
Front panel connectors - 1x microphone
Front panel connectors - 2 x USB 2.0
Front panel connectors - 2 x USB 3.0
guarantee - 24
guarantee_type - normal
Link - https://www.fractal-design.com/products/cases/define/define-7-mini/black-solid/
Manufacturer - Fractal Design
Manufacturer_code - FD-C-DEF7M-01
name - Define 7 Mini Black Solid
name - Fractal Design Define 7 Mini, SF-Gehäuse - Black Solid
Name - Fractal Design Define 7 Mini black Solid, Tower Case (black)
Name - Fractal Design Define 7 Mini Czarna Solid
Name - Fractal Design | Define 7 Mini | Black Solid | mATX, Mini-DTX, Mini ITX | Power supply included No | ATX
No. of drive bays - 4
Other features - Zawartość opakowania: Define 7 Mini Instrukcja obsługi Pudełko na akcesoria Wentylowany panel górny
Other features > Dimensions (WxDxH) - 205 x 399 x 406 mm
Other features > Drive bays - Dedicated 2.5" - 4 (2 included); 3.5"/2.5" - 2 (included)
Other features > Expansion slots - 4
Other features > Power supply type - ATX
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 462.00 mm
Package features > Gross height (mm) - 471.00 mm
Package features > Gross width (mm) - 277.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 5 pc(s)
Package features > Paper/Pasteboard - 1100.00 g
Package features > PET - 13 g
Package features > Plastic (No PET) - 500.00 g
Package features > Tare other - 12 g
Package features > Tare weight (kg) - 1.60 kg
Package features > Volume (m3) - 0.06 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Manual - Yes
Packaging data - Accessories included - Accessory box
Packaging data - Package depth - 462 mm
Packaging data - Package height - 471 mm
Packaging data - Package weight - 9.05 kg
Packaging data - Package width - 277 mm
PDF - https://www.blobs.lt/products/3/9/7/2/7/3/34d40a44b08bf0383fe448602e8ee735/original.pdf
Ports & interfaces - Audio input - Yes
Ports & interfaces - Audio output - Yes
Ports & interfaces - Number of USB 3.0 ports - 2
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - 1
Ports & interfaces > Interface - Front interface 1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, 2x USB 2.0, Audio
Power supply - Power supply included - No
Power supply - Power supply location - Bottom
Power supply - Supported power supply form factors - ATX
Power supply > Power supply included - No
producer - Fractal Design
Producer - Fractal Design
producerCode - FD-C-DEF7M-01
ProducerCode - FD-C-DEF7M-01
Producer product name - Define 7 Mini
productName - Fractal Design - Define Mini Black Sol
productSize - Normal
ShortDescription -
sizeX - 465
sizeY - 470
sizeZ - 280
Storage - HDD/SSD combo cage - Yes
Storage - Supported HDD sizes - 2.5
Storage - Supported HDD sizes - 3.5
Technical details > Gross weight - 8.44 kg
Technical details > Net weight - 6.84 kg
Technical details > Other features - Room for GPUs up to 331 mm with a 240 mm radiator in the top, or 306 mm with 25 mm thick fans in the fronts
Technical details > Producer - Fractal Design
Technical details > Warranty - 24 month(s)
Technical_details - Type: Tower case Color: Black EAN: 7340172702818 Manufacturer No.: FD-C-DEF7M-01 Design: midi tower Mainboard form factor: µATX Material: steel Internal dimensions: maximum 331 mm : maximum 167 mm : ATX : maximum 165 mm Drive bays: 2 pieces : 2 pieces Slots: 4 pieces Front ports: 2x audio, 2x USB-A 2.0, 2x USB-A 3.2 Gen 1 (5 Gbps), 1x USB-C 3.2 Gen 2 (10 Gbps) : The designation USB 3.2 Gen 1 corresponds to the former designation USB 3.1 Gen 1 / USB 3.0. : The designation USB 3.2 Gen 2 corresponds to the former designation USB 3.1 Gen 2 / USB 3.1. Front: 1x Dynamic X2 GP-14 fan available, another 140 mm fan can be installed, alternatively 3x 120 mm fans can be installed Rear: 1x Dynamic X2 GP-12 fan available Notes: 2x 140mm or 2x 120mm fans can be installed on the top, 1x 120mm fan can be installed on the bottom of the case (requires removing the HDD cage), dust filters: top, front, bottom and power supply, space for cable management : 15-25 mm, rubberized cable grommets, tool-free push-to-lock closure: top, front and side panels Water cooling possible: Yes front: 120, 240 mm, 140, 280 mm (361 mm max. height, 146 mm max. width), top: 120, 240 mm (max. 37 mm RAM with 121 mm wide radiators), rear: 120 mm, Bottom: 120mm (requires HDD cage removal) Dimensions: Width: 205mm x Height: 406mm x Depth: 399mm Weight: 7.5kg
vendpn - FD-C-DEF7M-01
Warranty - 24
warrantyLength - 24
warrantyType - F
Weight - 7.49 kg
Weight - 9,45
weight - 9335
Weight & dimensions - Depth - 399 mm
Weight & dimensions - Height - 406 mm
Weight & dimensions - Weight - 7.49 kg
Weight & dimensions - Width - 205 mm
