10/100/1000/2500 Mbps ports - None
Accessories included -
Application - Medium and large companies
ARTIKEL1 - 24-PORT 10G L2+ MANAGED SWITCH
ARTIKEL2 - 24X10G 8X SFP+
Brand - TP-Link
BrandPartCode - SX3832
Breite - 0
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Certificates - CE, FCC, RoHS
Chassis type - Rack
Console port - Yes
Data transmission - Forwarding rate - 240 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 32000 entries
Data transmission - Packet buffer memory - 24 MB
Data transmission - Static route - Yes
Data transmission - Switching capacity - 640 Gbit/s
Description - SX3832
Omada L2+ Managed Switch, 24 10GBASE-T Ports, 8 10GE SFP+ Slots 24 RJ45 ports with speeds of 1/2.5/5/10 Gbps 8 SFP+ slots with speeds of 1/10 Gbps 640 Gbps switching capacity Centralized cloud management via the Omada app or web interface Autonomous management via web interface, CLI, SNMP, and RMON Static Routing for easy internal traffic management for improved performance VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM ERPS for fast protection and recovery in a ring topology Rugged metal housing and rack-mountable design
Design - Form factor - 1U
Design - LED indicators - Yes
Design - Number of fans - 2 fan(s)
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Stackable - Yes
Designation - CE+WEEE
dimension depth - 100 mm
dimension height - 530 mm
Dimensions - 440 x 220 x 44 mm
dimension weight - 3200 g
dimension width - 340 mm
ean - 8885020622652
EAN - 8885020622652
EANCode - 8885020622652
Environment requirements - Permissible operating temperature: -5~50 degrees Celsius Permissible storage temperature: -40~70 degrees Celsius Permissible air humidity: 10%~90%, non-condensing Permissible storage humidity: 5%~90%, non-condensing
Fan - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 240 Mpps
Gewicht - 4.44
Gross Weight Kg - 4,77
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0810142821445
GTIN - 810142821445
GTIN - 8885020622652
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - SX3832
Jumbo frame size - 9 KB
L2 features -
L3 features -
Laenge - 0
LongDesc - Omada 24-Port 10GBASE-TL2+ Managed Switch with 810GE SFP+ Slots- 24× 1/2.5/5/10 Gbps RJ45 Ports- 8× 10 Gbps SFP+ Slots- Centralized Management- Omada App- Zero-Touch Provisioning- Ethernet Ring Protection Switching- Static Routing- Traffic Separation
LongProductName - 24× 1/2.5/5/10 Gbps RJ45, 8× 1/10 Gbps SFP+, 640 Gbps, 32 K MAC, 9 KB Jumbo, 440 x 220 x 44 mm
LongSummaryDescription - TP-Link Omada 24-Port 10GBASE-T L2+ Managed Switch with 8 10GE SFP+ Slots. Switch type: Managed, Switch layer: L2/L2+. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45/USB Type-C. MAC address table: 32000 entries, Switching capacity: 640 Gbit/s. Networking standards: IEEE 802.3az. Rack mounting, Form factor: 1U
MAC address table size - 32000
Management, monitoring, configuration -
Management features - ARP inspection - Yes
Management features - Cloud-managed - Yes
Management features - Configuring Location Settings (CLI) - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2/L2+
Management features - Switch type - Managed
Management features - System event log - Yes
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - SX3832
Manufacturer Name - TP-LINK
Mean time between failures (MTBF) - 568258 h
MPN - SX3832
Multicast features - Multicast support - Yes
name - Managed Switch Omada 24-Port 10GBASE-T L2+ with 8 10GE SFP+ Slots SX3832
Name - TP-Link Omada Switch 24x GE SX3832 10GBASE-T L2+ Managed
Network - 10G support - Yes
Network - Broadcast storm control - Yes
Network - Ethernet LAN data rates - 10,100 Mbit/s
Network - Flow control support - Yes
Network - IP routing - Yes
Network - Networking standards - IEEE 802.3az
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - MAC address-based VLAN, Multicast VLAN, Private VLAN, Voice VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 24
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - 8
Number of PoE ports (PoE & PoE+) - None
Number of ports 25Gb - None
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - None
Operational conditions - Heat dissipation - 363.23 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Packaging content - Cables included - AC, LAN (RJ-45)
Packaging content - Quick start guide - Yes
Packaging content - Rack mount kit - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 10G Ethernet (100/1000/10000)
Ports & interfaces - Console port - RJ-45/USB Type-C
Ports & interfaces - SFP+ module slots quantity - 8
Ports & interfaces - USB Type-C ports quantity - 1
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 106.5 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption - 104.9 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power supply - 100-240 V AC~50/60 Hz
Power supply - External
producer - TP-LINK
ProductName - Omada 24-Port 10GBASE-T L2+ Managed Switch with 8 10GE SFP+ Slots
QoS -
Security - IP, MAC, and Port Binding: 512 entries; DHCP Snooping; ARP Inspection; IPv4 Source Address Protection: 96 entries IPv6, MAC, and Port Binding: 512 entries; DHCPv6 Snooping; ND Detection; ND Snooping; IPv6 Source Address Protection: 95 entries DoS Protection DHCP Filter Port Protection via Static/Dynamic/Fixed Configuration: Up to 64 MAC Addresses per Port Storm Control Broadcast/Multicast/Unicast: Control Mode (Kbps / Rate) 802.1X Authentication: Port-Based Authentication; MAC-Based Authentication; VLAN Assignment; MAB; Guest VLAN; Authentication and authorization via Radius AAA (including TACACS+) Port isolation Secure web management via HTTPS with SSLv3/TLS 1.2 encryption Secure CLI management with SSHv1/SSHv2 encryption Access control based on IP/port/MAC
Security - Access Control List (ACL) - Yes
Security - Authentication - Auto VLAN, MAC-based authentication, Port-based authentication
Security - Authentication type - AAA, RADIUS, TACACS+
Security - DHCP features - DHCP relay, DHCP server, DHCP snooping, DHCPv6 snooping
Security - IGMP snooping - Yes
Security - Loop protection - Yes
Security - SSH/SSL support - Yes
Short description - TP-LINK Switch SX3832 24x10GBASE-T 8x 10GE SFP+ Managed Omada SDN
ShortSummaryDescription - TP-Link Omada 24-Port 10GBASE-T L2+ Managed Switch with 8 10GE SFP+ Slots, Managed, L2/L2+, 10G Ethernet (100/1000/10000), Rack mounting, 1U
Stackability - No
Stck_Kart - 1
Stck_Pal - 0
Storno - Y
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Managed
Switch layer - L2
Throughput - 640 GB/s
Title - TP-Link Omada 24-Port 10GBASE-T L2+ Managed Switch with 8 10GE SFP+ Slots
URL - https://www.tp-link.com/my/business-networking/omada-switch-l3-l2-managed/sx3832/
vendpn - SX3832
VLAN -
WarrantyInfo -
Weight - 4.85
Weight & dimensions - Depth - 220 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Width - 440 mm
