Axagon CLR-M2FAN active fan - M.2 SSD, 80mm SSD, copper body, silicone thermal pads, height 13mm

Accessories included - Radiator with a fan and a 38 cm long power cable Metal frame 3 pcs of heat conductive pads Mounting material and screwdriver Packed in a cardboard box
Box Weight Brutto (kg) - 0.15 kg
Brand - Axagon
BrandPartCode - CLR-M2FAN
Category - Computer Cooling Systems
category - PC Components|Drives|Accessories|Hard Drive Coolers
Category Code - HDA
code - CLR-M2FAN
Colour - Silver
Compatible with -
Cooling System Features - Aluminium Silicone Thermal Pads
Cooling System Type - SSD Cooler
Description - AXAGON CLR-M2FAN copper heatsink with fan for perfect cooling of high performance M.2 SSD disks, especially NVMe. The universal heatsink can be used for M.2 cards with size 22 x 80 mm. Supplied thermally conductive pads allow heatsink installation for all single-sided as well as double-sided M.2 SSD disks. Ribbed copper heatsink core with aluminum body is 8.6 mm high. Inside the body, there is a fan with PWM speed control, which is connected to the computer's motherboard with a 4-pin power connector. The fan speed can be automatically controlled by temperature, to save energy or to reduce noise. Copper heatsink with fan together with metal bracket assists in optimal dissipation of heat generated during the M.2 SSD operation. It also reduces the drive temperature by up to 30°C. This prolongs the M.2 SSD life and prevents disk slow down, so-called "Thermal Throttling". The heatsink can be used not only with M.2 AXAGON adapters, but also with M.2 (NGFF) slots on motherboards, etc. Thanks to the metal frame, the heatsink dissipates heat from both sides of the M.2 disk and thus achieves maximum cooling efficiency. Features:
Support of M.2 drives of any capacity.
Support of both single-sided and double-sided M.2 drives.
Support of M.2 drives, size 22 x 80 mm.
Support of SATA (AHCI) as well as NVMe (PCI-Express) M.2 drives.
Ribbed copper heatsink core, aluminum body.
Fan with PWM speed control, 4-pin power connector.
3 pcs thermally conductive pads can be deliberately combined and used for both single-sided and double-sided SSD disks with different height.
Compact dimensions 76 x 24 x 12 mm.
Weight 45 g. Package contains:
Heatsink with fan and fixed 38 cm long power cable,
metal bracket,
3 pcs thermally conductive pads,
mounting material and screwdriver,
packed in a cardboard box.   Review - https://www.hwcooling.net/en/axagon-clr-m2fan-active-ssd-cooler-for-closed-off-spaces-review/
Description - CLR-M2FAN heatsink for M.2 SSD Copper heatsink with fan for single-sided and double-sided M.2 SSD disks, size 2280, height 13 mm. AXAGON CLR-M2FAN copper heatsink with fan for perfect cooling of high performance M.2 SSD disks, especially NVMe. The universal heatsink can be used for M.2 cards with size 22 x 80 mm. Supplied thermally conductive pads allow heatsink installation for all single-sided as well as double-sided M.2 SSD disks. Ribbed copper heatsink core with aluminum body is 8.6 mm high. Inside the body, there is a fan with PWM speed control, which is connected to the computer's motherboard with a 4-pin power connector. The fan speed can be automatically controlled by temperature, to save energy or to reduce noise. Copper heatsink with fan together with metal bracket assists in optimal dissipation of heat generated during the M.2 SSD operation. It also reduces the drive temperature by up to 30°C. This prolongs the M.2 SSD life and prevents disk slow down, so-called "Thermal Throttling". The heatsink can be used not only with M.2 AXAGON adapters, but also with M.2 (NGFF) slots on motherboards, etc. Thanks to the metal frame, the heatsink dissipates heat from both sides of the M.2 disk and thus achieves maximum cooling efficiency.
Design - Base plate material - Aluminium
Design - Fan connector - 4-pin
Design - Material - Aluminium
Design - Number of fans - 1 fan(s)
Design - Product colour - Grey
Design - Radiator material - Copper
Designation - CE+WEEE
dimension depth - 25 mm
dimension height - 130 mm
Dimensions - 76 x 24 x 12 mm
dimension weight - 100 g
dimension width - 70 mm
ean - 8595247906588
External Color - Melna
Form Factor - M.2
GTIN - 8595247906588
guarantee - 24
guarantee_type - normal
Height (mm) - 13 mm
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/240311075403019309.jpg
Included Accessories - - passive heatsink
- 3 thermally conductive pads
- mounting material
- quick guide
LongDesc - AXAGON CLR-M2FAN copper heatsink with fan for perfect cooling of high performance M.2 SSD disks, especially NVMe. The universal heatsink can be used for M.2 cards with size 22 x 80 mm. Supplied thermally conductive pads allow heatsink installation for all single-sided as well as double-sided M.2 SSD disks.Ribbed copper heatsink core with aluminum body is 8.6 mm high. Inside the body, there is a fan with PWM speed control, which is connected to the computer's motherboard with a 4-pin power connector. The fan speed can be automatically controlled by temperature, to save energy or to reduce noise.Copper heatsink with fan together with metal bracket assists in optimal dissipation of heat generated during the M.2 SSD operation. It also reduces the drive temperature by up to 30°C. This prolongs the M.2 SSD life and prevents disk slow down, so-called "Thermal Throttling".The heatsink can be used not only with M.2 AXAGON adapters, but also with M.2 (NGFF) slots on motherboards, etc. Thanks to the metal frame, the heatsink dissipates heat from both sides of the M.2 disk and thus achieves maximum cooling efficiency.Features:• Support of M.2 drives of any capacity.• Support of both single-sided and double-sided M.2 drives.• Support of M.2 drives, size 22 x 80 mm.• Support of SATA (AHCI) as well as NVMe (PCI-Express) M.2 drives.• Ribbed copper heatsink core, aluminum body.• Fan with PWM speed control, 4-pin power connector.• 3 pcs thermally conductive pads can be deliberately combined and used for both single-sided and double-sided SSD disks with different height.• Compact dimensions 76 x 24 x 13 mm.• Weight 45 g.Package contains:• Heatsink with fan and fixed 38 cm long power cable,• metal bracket,• 3 pcs thermally conductive pads,• mounting material and screwdriver,• packed in a cardboard box. In the media:https://www.hwcooling.net/en/when-to-choose-which-axagon-ssd-cooler-a-little-guide/
LongProductName - CLR-M2FAN heatsink for M.2 SSD
LongSummaryDescription - Axagon CLR-M2FAN. Type: Heatsink/Radiator, Fan diameter: 2 cm. Width: 76 mm, Depth: 24 mm, Height: 12 mm. Product colour: Grey
Model - CLR-M2FAN
name - AXAGON CLR-M2FAN, activ e fan M.2 SSD, 80mm SSD
name - AXAGON CLR-M2FAN Kühler für M.2 2280 SSD
Other features -
Package Type - Box
Packaging content - Installation instruction - Yes
Packaging content - Package type - Box
Packaging content - Thermal pad included - Yes
Packs in Box - 1
Pack Weight Brutto (kg) - 0.05 kg
Pack Weight Netto (kg) - 0.15 kg
Parent Products - 2280 M.2 SSD
Performance - Compatible products - M.2 2280
Performance - Fan diameter - 2 cm
Performance - Pulse-width modulation (PWM) support - Yes
Performance - Quantity per pack - 1 pc(s)
Performance - Suitable location - Solid-state drive
Performance - Type - Heatsink/Radiator
Pieces in pack - 1
Power supply -
producer - AXAGON
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=220701063813838917&THEME=asbis&LANG=lv
ProductCategory - Cabinets
ProductCode - CLR-M2FAN
ProductDescription - AXAGON CLR-M2FAN active fan - M.2 SSD, 80mm SSD, copper body, silicone thermal pads, height 13mm
ProductName - CLR-M2FAN
Product Net Weight - 0.045 kg
ProductType - HDD Cabinet
Retail Packaging Net Weight Carton - 0.15 kg
Retail Packaging Net Weight Plastic - 0.15 kg
ShortSummaryDescription - Axagon CLR-M2FAN, Heatsink/Radiator, 2 cm, Grey
Technical details - Compliance certificates - RoHS
Title - Axagon CLR-M2FAN computer cooling system Solid-state drive Heatsink/Radiator 2 cm Grey 1 pc(s)
Unit Box Height - 0.13
Unit Box Length - 0.025
Unit Box Width - 0.07
Unit Calculated Volume - 0.0002275 cubm
Unit Calculated Weight - 0.09 kg
Units per Shipping Box - 1
URL - https://www.axagon.eu/en/produkty/clr-m2fan
Vendor - AXAGON
Vendor Homepage - www.axagon.eu/en/produkty/clr-m2fan?ami=222
vendpn - CLR-M2FAN
Warranty - 24 months
WarrantyInfo - 2 years
Warranty Products Returnable - Yes
Warranty Term (month) - 24 mēneši
Warranty validation Criteria - Serial Number
Weight - 45 g
Weight & dimensions - Depth - 24 mm
Weight & dimensions - Height - 12 mm
Weight & dimensions - Package depth - 67 mm
Weight & dimensions - Package height - 25 mm
Weight & dimensions - Package weight - 99 g
Weight & dimensions - Package width - 132 mm
Weight & dimensions - Weight - 45 g
Weight & dimensions - Width - 76 mm
