Intellinet PoE+/PoE Injector IEEE 802.3at/af 1 port, gigabit

Brand - Intellinet
BrandPartCode - 560566
Category - PoE Adapters
Category - Root/Electronics/Networks and communication/Network accessories/Accessories and switch modules
Certificates - Certification - FCC Class A Subpart B, CE, RoHS, UKCA, NDAA
Certificates - Compliance certificates - CE, RoHS, Federal Communications Commission (FCC)
Delivery set - - Adapter PoE Gigabit 1-Port
- Power cable
- Quick Installation Guide
Description - - Enables power over the POE Gigabit network;
- Output power up to 30 W;
- Compatible with IEEE 802.3af and 802.3at compliant devices (Access Pointy, VOIP phones, IP cameras);
- IEEE 802.3 at / af detection and protection against short circuit, overload and over voltage;
Designation - CE+WEEE
dimension depth - 73 mm
dimension height - 205 mm
Dimensions - 154 x 72 x 35 mm
dimension weight - 773 g
dimension width - 155 mm
ean - 766623560566
Eans - 0766623560566
Features - Housing material - Metal
Features - LED indicators - PoE, Power
Features - Power protection features - Over voltage, Overload, Short circuit
Features - Product colour - Black
GTIN - 0070090134732
GTIN - 070090134732
GTIN - 766623560566
GTIN - 0766623560566
GTIN - 0806294960095
GTIN - 806294960095
guarantee - 36
guarantee_type - external
Logistics data - Harmonized System (HS) code - 85044095
LongDesc - Reduce costs by using existing Cat5 cable to provide both power and data. The Intellinet Network Solutions 1-Port Gigabit High-Power PoE+ Injector allows you to connect your IEEE 802.3af/at-compliant products to a non-PoE LAN switch port. The PoE Injector can be used to connect a wireless access point, IP phone, network camera or any IEEE 802.3af/at-powered device (PD) to a switch. The device has an output power rating of up to 30 watts. That's enough for even power-hungry PoE devices. Reduce Wiring Costs No need to run AC power lines for your wireless access point, network camera or IP phone. Simply connect the PoE Injector to the LAN switch port, and use the existing Cat5 cabling to deliver DC power as well as transfer data. Protect Your Equipment Now that you are running DC power to your networked equipment through the Cat5e/6 cabling, you need to be sure that the products are protected from power problems. The PoE Injector was designed to protect equipment from short circuits (short GRND), current overloads and high voltages.
LongProductName - Gigabit High-Power PoE+ Injector, 1 x 30 W, IEEE 802.3at/af Power over Ethernet (PoE+/PoE)
LongSummaryDescription - Intellinet Gigabit High-Power PoE+ Injector, 1 x 30 W, IEEE 802.3at/af Power over Ethernet (PoE+/PoE). Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u. Product colour: Black, Housing material: Metal, LED indicators: PoE, Power. Input voltage: 100 - 240 V, Power consumption (max): 42 W. Compliance certificates: CE, RoHS, Federal Communications Commission (FCC), Certification: FCC Class A Subpart B, CE, RoHS, UKCA, NDAA. Width: 72 mm, Depth: 154 mm, Height: 35 mm
Name - Intellinet zasilacz - adapter POE Gigabit
name - PoE injector 1P / 802.3 AT / AF GIGA
Network - Cable types supported - Cat5, Cat5e
Network - Ethernet interface type - Gigabit Ethernet
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 5 - 45 °C
Operational conditions - Storage temperature (T-T) - -20 - 55 °C
Other features - Transmission Media:
- 100Base-TX Cat5 UTP / STP RJ45, 8 pin
- 1000Base-T Cat5e UTP / STP RJ45, 8 pin
Ports: - 1 x RJ-45 1000 Mbps data input port
- 1 x RJ-45 1000 Mbps data and power port
- 1 x port for external power supply
Security:
- Short circuit protection GND
- Overload protection for currents over 1.8 A
- High voltage protection over 58 V
Compatibility: Wireless Access Points (524735, 524711, 525251)
- PoE + IEEE 802.3at splitter (560443)
- Network Cameras (550932 NBCC30-IR, 550949 NFC30-IR, 550949 NFC30, 550987 NFD30, 551021 NFC31, 551045 NFC31-IR, 551229 NFD130-IR, 551236 NFD130-
Certificates: FCC Class A Part 15, CE 89/336 / EEC
Packaging content - Manual - Yes
Packaging content - Number of products included - 1 pc(s)
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Power - Input voltage - 100 - 240 V
Power - Power consumption (max) - 42 W
Power supply - - Input: 100-240 V AC, 50-60 Hz
- Power Consumption: 42 W (maximum)
producer - Intellinet
Producer - Intellinet
ProducerCode - 560566
ProductName - Gigabit High-Power PoE+ Injector, 1 x 30 W, IEEE 802.3at/af Power over Ethernet (PoE+/PoE)
ShortDescription - Umożliwia zasilanie urządzeń POE wprost z sieci Ethernet Gigabit
ShortSummaryDescription - Intellinet Gigabit High-Power PoE+ Injector, 1 x 30 W, IEEE 802.3at/af Power over Ethernet (PoE+/PoE), Gigabit Ethernet, 10,100,1000 Mbit/s, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, Cat5, Cat5e, Black, Metal
Title - Intellinet Gigabit High-Power PoE+ Injector, 1 x 30 W, IEEE 802.3at/af Power over Ethernet (PoE+/PoE)
URL - https://intellinetnetwork.eu/catalogsearch/result/?q=560566
vendpn - 560566
WarrantyInfo - 3 year
Weight - 0.79 kg
Weight & dimensions - Depth - 154 mm
Weight & dimensions - Height - 35 mm
Weight & dimensions - Weight - 790 g
Weight & dimensions - Width - 72 mm
