Accessories included - Mounting plate Mounting screws
Antenna - Antenna gain level (max) - 6 dBi
Antenna - Antenna type - Internal
Antenna type - MU-MIMO
ARTIKEL1 - NWA220AX-6E WIFI 6E ACCESSPOINT
ARTIKEL2 - NWA220AX-6E-EU0101F
Brand - Zyxel
BrandPartCode - NWA220AX-6E-EU0101F
Category - Wireless Access Points
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Color - White
Description - Dizzying speed WiFi 6E, the new 6GHz band, presents a solution to meet the need for higher bandwidth networks. The BandFlex radio design of the NWA220AX-6E allows the access point to support either the 5GHz or 6GHz band depending on configuration, making it the most cost-effective choice to match existing 5GHz coverage as well as future 6Ghz usage. The NWA220AX-6E is an excellent choice for: High-density environments such as offices, campuses, shopping malls, convention centres or transport hubs to reduce WiFi congestion, reduce congestion and increase user experience. New technologies such as VR/AR, 8K video streaming or online gaming that promise ultra-fast speeds without lag. The device incorporates all the benefits of WiFi 6 capabilities, such as OFDMA, MU-MIMO, BSS Coloring technologies, and then moves them to the all-new interference-free 6GHz to deliver ultra-fast speeds and low-latency connections. Flexible BandFlex radio design The Zyxel NWA220AX-6E is a dual-band access point with a BandFlex radio design that can support either 5GHz or 6GHz depending on configuration. It is the most cost-effective choice to match existing 5 GHz coverage as well as future 6 GHz usage. 6E efficiency boost The high-gain 4x4 design transmitting from 6GHz helps increase the efficiency of beamforming and receive MIMO to extend coverage and maximise the performance of the new band. Manage it your way The NWA220AX-6E access point with NebulaFlex has flexible management options. In addition to management via the local interface, you can also use Nebula's cloud-based management interface.
Description - ZYXEL NWA220AX-6E, SINGLE PACK 802.11AXE AP, STANDALONE / NEBULAFLEX, EXCLUDE POWER ADAPTOR, EU AND UK, UNIFIED AP, ROHS
Design - LED indicators - Yes
Design - Placement - Ceiling
Design - Product colour - White
dimensionalWeight - 480
dimension depth - 200 mm
dimension height - 60 mm
Dimensions - 180 x 180 x 42 mm
Dimensions W x D x H, mm - 180 x 180 x 42
dimension weight - 620 g
dimension width - 190 mm
ean - 4718937628643
EANCode - 4718937628643
EAN_code - 4718937628643
Ethernet LAN (RJ-45) ports quantity - 2
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - Band steering - Yes
Features - Bandwidth - 0.16 GHz
Features - Fast roaming - Yes
Features - Maximum data transfer rate - 4800 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 575 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 4800 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11ax
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Frequency range, GHz - 2.4/5/6
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 4718937628643
guarantee - 24
guarantee_type - external
Height - 60.000000
HERSTELLER - ZYXEL
HSTNUMMER - NWA220AX-6E-EU0101F
I/O ports - 1 x 10/100/1000 Mbit/s
I/O ports - 1 x 10/100/1000/2500 RJ-45 port PoE
Length - 190.000000
LongDesc - AXE5400 WiFi 6E Dual-Radio Access Point Featuring 6 spatial streams (4x4 in 6 GHz/5 GHz selectable, 2x2 in 2.4 GHz) with the maximum data rate of 5.4 Gbps, the Zyxel NWA220AX-6E is the dual-radio access point with a BandFlex radio that can support either 5 GHz or 6 GHz by configuration, making it the most economical choice to fit into your existing 5 GHz coverage as well as futureproofing the use of 6 GHz. NWA220AX-6E includes all the benefits of WiFi 6 capabilities like OFDMA, MU-MIMO, BSS Coloring, and brings them into the brand-new, interference-free 6 GHz that more than doubles the WiFi capacity to deliver multi-gigabit speed, and low-latency connections. The brand-new, interference-free 6 GHz band presents a solution to quenching the thirst for today’s network hungry for more bandwidth, making it a perfect choice for high-density WiFi and emerging technology connectivity. To reach the full potential of the new band, Zyxel 6E Boost, using the high-gain 4x4 streams in 6 GHz, increases the maximum gains in transmit beamforming and receive MIMO to extend its range and ensure the highest performance is delivered. The NWA220AX-6E is ideal in high density environments such as transport hubs, exhibition halls, schools, offices, hotels, restaurants, or any other organizations that need to accommodate a large number of devices as it can offer the optimal premium service for everyone, every time they connect to WiFi. WiFi 6E — bringing WiFi 6 into 6 GHz spectrum WiFi 6E is the WiFi 6 extended into 6 GHz spectrum. It includes all the WiFi 6 features, plus the following: • 2.5X More Capacity: 2.5 times more spectrum with the extended 6 GHz band with no legacy devices • Superwide Channels: Utilizing up to seven additional superwide 160 MHz channels in 6 GHz for bandwidth-demanding applications like VR/AR, WiFi calling, and high-definition video streaming • No Interference: No interference from microwaves and the non-6E devices. Only Wi-Fi 6E capable devices can use the 6 GHz band. 4G/5G cellular network coexistence With the exponential growth of mobile devices in the wireless network, users start to experience degraded performance, such as ping drops and high latency; users have to reduce the use of their mobile devices in order to maintain a smooth, working wireless service. Thus, to enable 4G/5G cellular network coexistence and minimize interference from 4G/5G antennas or signal boosters, the NWA220AX-6E has built-in 4G/5G interference filters. As a result, the visible or invisible 4G/5G indoor antennas in the environment is no longer an issue when installing APs. NebulaFlex — simply manage it your way! The NebulaFlex provides extended flexibility, allowing users to easily switch among standalone, or our intuitive cloud-managed NCC (Nebula Control Center) modes any time according to your needs without additional cost while protecting wireless technology investments. The Nebula cloud management platform provides centralized control and visibility over all Nebula networking devices. Simply you only need to register the device on NCC, and it will automatically join, auto provision and begin to give real-time information. The intuitive platform allows you to group your access points together, control centrally, gain access to diagnostics tools and additional features like captive portal all under a single platform.
LongProductName - NWA220AX-6E, Single Pack 802.11axe AP, Standalone / NebulaFlex, exclude Power Adaptor, EU and UK, Unified AP, ROHS
LongSummaryDescription - Zyxel NWA220AX-6E-EU0101F. Maximum data transfer rate: 4800 Mbit/s, Maximum data transfer rate (2.4 GHz): 575 Mbit/s, Maximum data transfer rate (5 GHz): 4800 Mbit/s. Security algorithms: 802.1x RADIUS, EAP, WEP, WPA, WPA2-PSK, WPA3, WPA3-Enterprise. Output voltage: 12 V, Output current: 2 A, Power supply: 21 W. Placement: Ceiling, Product colour: White. Antenna type: Internal, Antenna gain level (max): 6 dBi
Management, monitoring, configuration - Operation mode Nebula cloud management Standalone ZON tool Discovering Zyxel switches, access points and gateways Centralised and batch configurations IP configuration IP renewal Rebooting a device Locating the device Access to the web-based graphical interface Software update Password configuration Web UI/CLI SNMP
Manufacturer - Zyxel
Manufacturer - ZYXEL COMMUNICATIONS A/S
ManufacturerPartNumber - NWA220AX-6E-EU0101F
Manufacturer_code - NWA220AX-6E-EU0101F
Name - Zyxel NWA220AX, access point
name - Zyxel NWA220AX-6E-EU0101F
Network architecture - GigabitEthernet
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operating frequency - 6 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - Antenna type 4x4 + 2x2 Double optimised antenna
2.4 GHz antenna gain: 3dBi peak gain 5 GHz: 5dBi peak gain 6 GHz: 6dBi peak gain Minimum receive sensitivity Rx to -101 dBm
Packaging content - Mounting kit - Yes
PeriodofWarranty - 3 Y
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - Output current - 2 A
Power - Output voltage - 12 V
Power - Power over Ethernet (PoE) - Yes
Power - Power supply - 21 W
Power supply - PoE (802.3)at: power draw 21W DC input : 12 VDC 2A
producer - Zyxel
producerCode - NWA220AX-6E-EU0101F
ProductName - NWA220AX-6E-EU0101F
productName - Zyxel NWA220AX-6E-EU0101F wireless access point 4800 Mbit/s White Power over Ethernet (PoE)
productSize - Normal
Security - Encryption WEP WPA WPA2-PSK WPA3 Authentication WPA WPA2 WPA3-Corporate EAP IEEE 802.1X RADIUS authentication Access management L2 isolation MAC address filtering Detection of rogue access points
Security - Auto Wireless Distribution System (WDS) - Yes
Security - MAC address filtering - Yes
Security - Security algorithms - 802.1x RADIUS
Security - Security algorithms - 802.1x RADIUS, EAP, WEP, WPA, WPA2-PSK, WPA3, WPA3-Enterprise
Security - Security algorithms - EAP
Security - Security algorithms - WEP
Security - Security algorithms - WPA
Security - Security algorithms - WPA2-PSK
Security - Security algorithms - WPA3
Security - Security algorithms - WPA3-Enterprise
ShortSummaryDescription - Zyxel NWA220AX-6E-EU0101F, 4800 Mbit/s, 575 Mbit/s, 4800 Mbit/s, 0.16 GHz, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Multi User MIMO
sizeX - 200
sizeY - 200
sizeZ - 60
Software -
Special functions - WLAN function: Bandwidth control WDS/Grid*2 Fast roaming - Pre-authentication, PMK and 802.11r/k/v caching DCS Load balancing Advanced cellular coexistence
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 10
Stck_Pal - 0
Storno - Y
System Requirements -
Technical_details - Type: Access Point EAN: 4718937628643 Manufacturer No.: NWA220AX-6E-EU0101F Design: wall mounting Connections: 2x (of which: 1x 10/100/1000, 1x 100/1000/2500) : Auto MDI/MDIX Wi-Fi: Wi-Fi 3 (802.11b), Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) - (2.4 GHz , 5GHz) : WPA, WPA2, WPA2-PSK, WPA3, WPA3-ENT : 575 MBit/s (WLAN 2.4 GHz), 4800 MBit/s (WLAN 5 GHz), 4800 MBit/s (WLAN 6 GHz) Routing & Switching: Smart Managed, Cloud Managed Feature: Band Steering, WDS/Mesh, Fast roaming: Pre-authentication, PMK caching and 802.11r/k/v, DCS, Load balancing, Advanced Cellular Coexistence Dimensions: Width: 180mm x Height: 180mm x Depth/Length: 42mm Weight: 650 grams
Title - Zyxel NWA220AX-6E-EU0101F wireless access point 4800 Mbit/s White Power over Ethernet (PoE)
URL - https://www.zyxel.com/
vendpn - NWA220AX-6E-EU0101F
WarrantyInfo -
warrantyLength - 60
warrantyType - F
Weight - 0,79
Weight - 0.790000
Weight - 650 g
weight - 790
Weight & dimensions - Depth - 180 mm
Weight & dimensions - Height - 42 mm
Weight & dimensions - Weight - 650 g
Weight & dimensions - Width - 180 mm
Weight, g - 650
Width - 200.000000
Wireless standard - 802.11 a
Wireless standard - 802.11 ac
Wireless standard - 802.11 ax
Wireless standard - 802.11 b
Wireless standard - 802.11 g
Wireless standard - 802.11 n
