APC Back-UPS BX2200MI-GR 2200VA, 1200W

Accessories included -
Active power - 1200 W
Alarm -

Alarm when on battery

Distinctive low battery alarm

Apparent power - 2200 VA
ARTIKEL1 - APC BACK-UPS 2200VA 230V AVR
ARTIKEL2 - SCHUKO SOCKETS
Backup time (100% load) - 1 min
Battery - Battery life (max) - 2 year(s)
Battery - Battery recharge time - 8 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Typical backup time at full load - 1 min
Battery - Typical backup time at half load - 8.5 min
BatteryType - Lead-acid
Brand - APC
BrandPartCode - BX2200MI-GR
Category - Root/Smarthome/Electricity/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Category_1 - Power
Category_2 - UPS
Charging time - 6 h
Chassis type - Tower
Color - Black
ControlPanel -

LED status display with On Line

On Battery

Depth - 390 mm
Depth, mm - 390
Description - APC BACK-UPS 2200VA, 230V, AVR, SCHUKO SOCKETS
Description - Seria APC Back-UPS BX to ekonomiczne rozwiązanie do ochrony zasilania w domu i biurze domowym. Szeroka gama serii VA z funkcjami premium dodatkowo umożliwia wykorzystanie możliwości pojedynczego zasilacza UPS
Design - Cable length - 1.2 m
Design - Certification - CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Design - Form factor - Compact
Design - International Protection (IP) code - IP20
Design - LED indicators - Yes
Design - Product colour - Black
dimension depth - 240 mm
dimension height - 490 mm
Dimensions - 190 x 140 x 390 mm
dimension weight - 9000 g
dimension width - 290 mm
ean - 731304410881
EAN - 0731304410881
EANCode - 0731304410881
Eans - 731304410881
EAN_code - 0731304410881
Environment requirements - Środowisko pracy: 0 - 40 °C Wilgotność względna podczas pracy: 0 - 95% Wysokość robocza: 0-3000 metrów Temperatura przechowywania: 15 - 40 °C Wilgotność względna przechowywania: 0-95%
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Low battery alarm
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 300 V
Features - Input operation voltage (min) - 140 V
Features - Input power factor - 0.54
Features - Noise level - 40 dB
Features - Output frequency - 50/60 Hz
Features - Output frequency regulation - 0.5 Hz
Features - Output operation voltage (max) - 230 V
Features - Output operation voltage (min) - 230 V
Features - Output power - 1200 W
Features - Output power capacity - 2.2 kVA
Features - Output voltage regulation - 10%
Features - Response time - 6 ms
Features - Surge energy rating - 273 J
Features - Surge protection - Yes
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
FormFactor - Tower
Form factor - Tower
GrossWeight - 8.000 kg
Gross Weight Kg - 13,3
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0731304410881
GTIN - 731304410881
guarantee - 24
guarantee_type - external
Height - 190 mm
Height - 290.000000
Height, mm - 190
HERSTELLER - APC
HSTNUMMER - BX2200MI-GR
I/O connectors - 1 x USB (Type B)
I/O connectors - 2 x RJ-45 (iLO Remote Management Network)
InputConnections - -
InputFrequency - 50/60 Hz +/- 5 Hz Auto-sensing
Input power ports - Wtyczka sieciowa
InputVoltage - 140 - 300V
InterfacePorts - -
Length - 495.000000
Logistics data - Harmonized System (HS) code - 85078000
LongDesc -
LongDesc - Automatic Voltage Regulation (AVR)Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.Dataline surge protectionProvides protection of connected equipment from power surges on the data lines.PowerChute Personal Edition OS CompatibilityThis software supports numerous operating systems and processors.USB connectionUse your PC to access additional power protection and management features for your UPS via a USB Port.Audible alarmsProvides notification of changing utility power and UPS power conditionsLED status displayQuickly understand unit and power status with visual indicators.Intelligent battery managementMaximizes battery performance, life, and reliability through intelligent, precision charging.Automatic self-testPeriodic battery self-test ensures early detection of a battery that needs to be replaced.Battery failure notificationProvides early-warning fault analysis on batteries enabling timely preventive maintenanceSurge only outletsProtect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.Battery and surge protected outletsBack up and protect your hardware and data during power outages, surges and spikes.Safety-agency approvedEnsures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.Battery-protected and surge-only outletsReserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment
LongProductName - 2200VA, 230V, AVR, 4x Schuko Sockets, Black
LongSummaryDescription - APC BX2200MI-GR. UPS topology: Line-Interactive, Output power capacity: 2.2 kVA, Output power: 1200 W. AC outlet types: Type F, Power plug: Type F, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 1 min, Typical backup time at half load: 8.5 min. Form factor: Compact, Product colour: Black, Cable length: 1.2 m. Width: 140 mm, Depth: 390 mm, Height: 190 mm
Manufacturer - APC
Manufacturer Code - BX2200MI-GR
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - BX2200MI-GR
Manufacturer_code - BX2200MI-GR
MANUFDATASHEET - https://www.apc.com/shop/us/en/products/APC-Back-UPS-2200VA-230V-AVR-4-Schuko-outlets/P-BX2200MI-GR
Name - APC Back-UPS BX MI 2200VA / 230V Schuko
Name - APC Back BX2200MI-GR
name - BX2200MI-GR Back-UPS 2200VA,230V,AVR,4 Schuko
No. of batteries - 1
Nominal input voltage, V - 230
Nominal output voltage, V - 230
Number of phases input - 1 (230V)
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -15 - 40 °C
Other features -
OutputConnections - -
OutputFrequency - 50/60 Hz +/- 1 Hz Sync to mains
Output power capacity (VA) - 2200
Output power ports - 4 x C/F type (Schuko)
OutputVoltage - -
PackageContents - -
Packaging data - Cables included - Input power cable
Packaging data - Manual - Yes
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - Type F
Ports & interfaces - Power plug - Type F
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port type - USB Type-B
PowerVAW - 2200 VA
PowerW - 1200 W
ProdDesc - APC Back-UPS 2200VA, 230V, AVR, Schuko Sockets
producer - APC
Producer - APC
ProducerCode - BX2200MI-GR
ProductName - BX2200MI-GR
ProductPicture - http://www.tdbaltic.ee/images/ds4/BX1200MI-01.jpg
ProductPicture2 - http://www.tdbaltic.ee/images/ds4/BX2200MI-02.jpg
ProductPicture3 -
ProductPicture4 -
RechargeTime - 8 h
RJ45 - -
Runtime - 9.5/2.25
ShortDescription -
Short description - APC Back-UPS BX 2200 VA BX2200MI-GR
ShortSummaryDescription - APC BX2200MI-GR, Line-Interactive, 2.2 kVA, 1200 W, Sine, 140 V, 300 V
SmartSlot - -
Software -
Special functions - AVR
Stck_Kart - 1
Stck_Pal - 30
Storno - N
Technical details - Sustainability certificates - RoHS
Title - APC BX2200MI-GR uninterruptible power supply (UPS) Line-Interactive 2.2 kVA 1200 W 4 AC outlet(s)
Topology - Line interactive
UPS Architecture - line-interactive
UPS devices and accessories - Yes
URL - https://www.apc.com/shop/uk/en/products/APC-Back-UPS-2200VA-230V-AVR-Schuko-Sockets/P-BX2200MI-GR
USB - -
vendpn - BX2200MI-GR
Warranty - 2 years
WarrantyInfo - 2 years
WaveformType - Stepped approximation to a sinewave
Weight - 12.3 kg
Weight - 12.300 kg
Weight - 13,60
Weight - 13.710000
Weight & dimensions - Depth - 390 mm
Weight & dimensions - Height - 190 mm
Weight & dimensions - Package depth - 495 mm
Weight & dimensions - Package height - 297 mm
Weight & dimensions - Package weight - 13.3 kg
Weight & dimensions - Package width - 235 mm
Weight & dimensions - Weight - 12.3 kg
Weight & dimensions - Width - 140 mm
Weight, kg - 12.3
Width - 140 mm
Width - 235.000000
Width, mm - 140
