Asus GeForce RTX 4060 Ti, 8GB GDDR6, Dual (DLSS 3), SSD Edition

Name: Asus GeForce RTX 4060 Ti, 8GB GDDR6, Dual (DLSS 3), SSD Edition
Brand: Asus
SKU: 1037679
Price: 539.32 EUR
Availability: OutOfStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 1037679 Product code: DUAL-RTX4060TI-O8G-SSD

Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

Dateks.lv website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 2 years (Warranty for business entities 1 year)

Compare

Main product parameters All parameters

GPU model: GeForce RTX 4060 Ti (8GB)
GPU core frequency: 2565 MHz
Power sockets: 1x 8-pin
RAM: 8 GB
Memory type: GDDR6
Cooling: Standard Cooler

Virtual reality

The GeForce emblem indicates that this graphics card is powerful enough to be compatible with the latest VR (Virtual Reality) devices such as Oculus Rift, HTC Vive (SteamVR), etc.

Basic information

GPU tips GeForce

GPU or the video card processor. This parameter determines whether the video card model is AMD Radeon or FirePro, NVIDIA GeForce or Quadro.

GPU series : Asus Dual

GPU model GeForce RTX 4060 Ti (8GB)

This is the main performance indicator of the graphics card because it indicates the model of this card. The performance of cards of the same model is very similar and usually very different from the cards of another model.

The main difference is the manufacturer. NVidia produces GeForce series cards and AMD produces Radeon series cards. There are considerable differences between both series, GeForce cards have more successful (more stable) drivers, which improve the compatibility of these cards with games and operating systems reducing the image defect (artefact) and the cases of "hanging" to the minimum. Radeon cards usually are cheaper and consume less energy (they are technologically superior), however there might be problems with drivers and the support of games.

The choice between Radeon or GeForce series is the question of preference, similar to the choice between AMD or Intel CPU, and not always there is 100% rational justification behind it, therefore we recommend to base your selection criteria just on the games that you want to play in the near future and to find a video review in YouTube (the graphic card model + the game title) that will demonstrate exactly how the particular card handles the relevant game. The result will be obvious and usually quite close to what you get when you buy the particular or similar model card.

For making the choice easier for our customers Dateks.lv has marked the graphic cards (models) that are the best choice for playing all the newest games at a reasonable quality level with a green tick "recommended".

GPU core frequency 2565 MHz

GPU speed or the graphic drive speed (MHz) indicates the clock frequency at which the most important component of the video card, i.e. the video processor, operates. The higher the drive speed, the more powerful the video card. The performance of the video card is also determined by the memory volume, type, bits and the drive model, therefore you should verify the capacity compliance of the other components upon buying a video card with a powerful drive.

Number of fans : 2

Length (mm) : 228

Stream processors / CUDA Cores : 4352

PCI-E version : 4.0 x16

Power consumption (TDP) : 160 W

Minimum power supply output : 650 W

Power sockets : 1x 8-pin

Random-access memory (RAM)

RAM 8 GB

The RAM capacity of the video card. This is an important parameter if you want to play games of high resolution or work with a high resolution monitor. A higher memory capacity means better performance and the support to higher resolution.

Currently 1GB is the optimum capacity of the video memory.

Memory type GDDR6

The type of the RAM of the video card determines the operation speed of the video card. The currently available video cards have DDRII, GDDRIII or GDDR4 memory. GDDR4 memory is the fastest memory type.

Memory type : 18000 MHz

Bus width 128 bit

The number of bits of the video card RAM determine what amount of information the video card memory can handle within a single clock cycle. A higher number of bits indicates higher performance of the video card.

Functionality

Cooling Standard Cooler

Two types of cooling are available, i.e. a radiator and a ventilator. The radiator based cooling is implemented without any moving parts (ventilator), therefore the video card does not emit any noise. The ventilator based cooling is more efficient, however, the video card emits certain noise during the computer operation.

Lighting : Nav

NVIDIA SLI (NVLink) support : Not

VR (Virtual Reality) Ready : Is

Low Profile support : No

Ports and equipment

HDMI port 1

HDMI is the digital image and sound transmission standard that allows to connect a TV set, monitor or projector supporting HDMI to the computer via the HDMI cable.

DisplayPort 3

DisplayPort digital connection for the transmission of the image and sound via a single wire at a high quality level. Contrary to the HDMI, this connection allows to connect several external monitors to the computer via a single connector.

DVI-D port : 0

DVI-I port : 0

D-SUB 0

D-SUB is the classic (analogous) connection plug of monitors, projectors and other external video devices. This standard is gradually disappearing from the market leaving the space for much higher quality HDMI or DisplayPort (digitālajiem) plugs.

Maximum number of screens : 4

More detailed specification

Additional information in manufacturers website Asus GeForce RTX 4060 Ti, 8GB GDDR6, Dual (DLSS 3), SSD Edition

Brand - ASUS
BrandPartCode - 90YV0JS0-M0NA00
Category - Graphics Cards
Category - Root/Electronics/PC parts/Graphic cards
Category_1 - Graphics Cards
Category_2 - Graphics Cards PCIe - Nvidia
Design - Cooling technology - ASUS Axial-tech
Design - Cooling type - Active
Design - Number of fans - 2 fan(s)
Design - Number of slots - 2.5
Design - Product colour - Black
Eans - 4711387370872
EAN_code - 4711387370872
GTIN - 4711387370872
LongDesc - Compact, cooler, fasterPowerful Graphics and Storage, All in OneThe ASUS Dual GeForce RTX™ 4060 Ti SSD graphics card takes compact gaming power and combines it with an all-new feature: a PCIe 4.0 M.2 slot integrated into the backside of the card, offering massive bandwidth for high-performance NVMe storage.Built-in M.2 SlotThe backside of this graphics card integrates an M.2 slot capable of PCIe 5.0 speeds, for high-performance NVMe storage devices up to 80 mm long—and the SSD transfers heat directly to the card’s own heatsink using a thermal pad, resulting in a highly compact and tidy solution.Axial-tech Fan DesignBetter, faster, strongerTwo tried-and-true Axial-tech fans feature a smaller hub that facilitates longer blades and a barrier ring to increase downward air pressure, while the right fan operates at higher speeds to guarantee SSD heat dissipation.Auto-Extreme TechnologyPrecision automated manufacturingAuto-Extreme Technology is an automated manufacturing process that sets new standards in the industry by allowing all soldering to be completed in a single pass. This reduces thermal strain on components and avoids the use of harsh cleaning chemicals, resulting in less environmental impact, lower manufacturing power consumption, and a more reliable product overall.GPU TWEAK IIIMonitor, tweak, and tuneThe ASUS GPU Tweak III utility takes graphics card tuning to the next level. It allows you to tweak critical parameters including GPU core clocks, memory frequency, and voltage settings, with the option to monitor everything in real-time through a customizable on-screen display. Advanced fan control is also included along with many more features to help you get the most out of your graphics card.144-hour Validation Program"Extensive" may be an understatementA 144-hour validation program puts cards through a series of stringent tests to ensure compatibility with the latest games.NVIDIA DLSS 3Max FPS. Max Quality. Powered by AI.DLSS is a revolutionary breakthrough in AI graphics that multiplies performance. Powered by the new fourth-gen Tensor Cores and Optical Flow Accelerator on GeForce RTX 40 Series GPUs, DLSS 3 uses AI to create additional frames and improve image quality.
LongProductName - Dual GeForce RTX 4060 Ti SSD OC Edition 8GB GDDR6 is designed for broad compatibility, with an M.2 SSD slot, 2.5-slot design, Axial-tech fan design, 0dB technology, and more
LongSummaryDescription - ASUS Dual -RTX4060TI-O8G-SSD. Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 4060 Ti. Discrete graphics card memory: 8 GB, Graphics card memory type: GDDR6, Memory bus: 128 bit. Maximum resolution: 7680 x 4320 pixels. OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 2 fan(s)
Manufacturer - Asus
Manufacturer_code - 90YV0JS0-M0NA00
Memory - Data transfer rate - 18 Gbit/s
Memory - Discrete graphics card memory - 8 GB
Memory - Graphics card memory type - GDDR6
Memory - Memory bus - 128 bit
Name - ASUS GeForce RTX 4060 Ti DUAL 8GB OC SSD DLSS 3
Name - ASUS GeForce RTX 4060 Ti DUAL OC SSD, graphics card (DLSS 3, 3x DisplayPort, 1x HDMI 2.1, M.2 PCIe 4.0 x4 (2280))
Packaging content - Manual - Yes
Packaging data - Package depth - 220.5 mm
Packaging data - Package height - 68 mm
Packaging data - Package type - Box
Packaging data - Package weight - 1.19 kg
Packaging data - Package width - 368 mm
Performance - Dual Link DVI - No
Performance - HDCP - Yes
Performance - HDCP version - 2.3
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 3
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1a
Ports & interfaces - Interface type - PCI Express 4.0
Power - Minimum system power supply - 650 W
Power - Supplementary power connectors - 1x 8-pin
Processor - CUDA - Yes
Processor - CUDA cores - 4352
Processor - Graphics processor - GeForce RTX 4060 Ti
Processor - Graphics processor family - NVIDIA
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Parallel processing technology support - Not supported
Processor - Processor boost clock speed - 2565 MHz
Processor - Processor frequency (OC mode) - 2595 MHz
Producer - Asus
ProducerCode - DUAL-RTX4060TI-O8G-SSD
ProductName - DUAL-RTX4060TI-O8G-SSD
ShortDescription - Chipset NVIDIA RTX 4060 Ti | 8GB |
ShortSummaryDescription - ASUS Dual -RTX4060TI-O8G-SSD, GeForce RTX 4060 Ti, 8 GB, GDDR6, 128 bit, 7680 x 4320 pixels, PCI Express 4.0
Title - ASUS Dual -RTX4060TI-O8G-SSD NVIDIA GeForce RTX 4060 Ti 8 GB GDDR6
URL - https://www.asus.com/motherboards-components/graphics-cards/dual/dual-rtx4060ti-o8g-ssd/
WarrantyInfo -
Weight - 1,30
Weight & dimensions - Depth - 123.2 mm
Weight & dimensions - Height - 49.6 mm
Weight & dimensions - Weight - 716 g
Weight & dimensions - Width - 227.2 mm

Basic information
	This product Asus GeForce RTX 4060 Ti, 8GB GDDR6, Dual (DLSS 3), SSD Edition	Asus GeForce RTX 4060, 8GB GDDR6, Dual OC (DLSS 3) + Receive an Eneba gift card worth €20 in partnership with ASUS	Asus GeForce RTX 4060, 8GB GDDR6, Dual EVO (DLSS 3) + Receive an Eneba gift card worth €20 in partnership with ASUS	Gigabyte GeForce RTX 4060 Ti, 8GB GDDR6, Eagle OC (DLSS 3)	Asus GeForce RTX 4060 Ti, 16GB GDDR6, Dual OC (DLSS 3) + Receive an Eneba gift card worth €40 in partnership with ASUS
Show similar specs. Hide similar specs.	539.32 €	367.45 €	367.45 €	503.29 €	567.43 €
GPU tips	GeForce	GeForce	GeForce	GeForce	GeForce
GPU series	Asus Dual	Asus Dual	Asus Dual	Gigabyte Eagle	Asus Dual
GPU model	GeForce RTX 4060 Ti (8GB)	GeForce RTX 4060	GeForce RTX 4060	GeForce RTX 4060 Ti (8GB)	GeForce RTX 4060 Ti (16GB)
GPU core frequency	2565 MHz	2505 MHz	2535 MHz	2550 MHz	2595 MHz
Number of fans	2	2	2	3	2
Length (mm)	228	228	227	272	228
Stream processors / CUDA Cores	4352	3072	3072	4352	4352
PCI-E version	4.0 x16	4.0 x8	4.0 x8	4.0 x16	4.0 x8
Power consumption (TDP)	160 W	105 W	115 W	160 W	165 W
Minimum power supply output	650 W	550 W	550 W	500 W	650 W
Power sockets	1x 8-pin	1x 8-pin	1x 8-pin	1x 8-pin	1x 8-pin
Random-access memory (RAM)
RAM	8 GB	8 GB	8 GB	8 GB	16 GB
Memory type	GDDR6	GDDR6	GDDR6	GDDR6	GDDR6
Memory type	18000 MHz	17000 MHz	17000 MHz	1800 MHz	18000 MHz
Bus width	128 bit	128 bit	128 bit	128 bit	128 bit
Functionality
Cooling	Standard Cooler	Standard Cooler	Standard Cooler	Standard Cooler	Standard Cooler
Lighting	Nav	Nav	Nav	Nav	Nav
NVIDIA SLI (NVLink) support	Not	Not	Not	Not	Not
VR (Virtual Reality) Ready	Is	Is	Is	Is	Is
Low Profile support	No	No	No	No	No
Ports and equipment
HDMI port	1	1	1	2	1
DisplayPort	3	3	3	2	3
DVI-D port	0	0	0	0	0
DVI-I port	0	0	0	0	0
D-SUB	0	0	0	0	0
Maximum number of screens	4	4	4	4	4
